AI IP camera ONVIF PoE 8MP 3.6mm Starlight Dahua


IPC-HFW3841E-SA Dahua AI Onvif PoE outdoor IP camera with Artificial Intelligence , 8 Megapixel 8MP , 1 / 2.8 "CMOS sensor with Starlight Technology , 3.6mm optics, H.265 + , triple stream. Smart IR illuminator 1 LED 30MT , Day / Night (ICR), WDR 120dB, Perimeter Protection, Smart Search, micro sd slot, cloud p2p , IP67 protection, SMD Plus

Reference: IPC-HFW3841E-SA

Brand: Dahua

EAN: 6939554993992

€155.06

€378.20 -59%
taxes included
Tax included
 Available
 Available

LO HAI TROVATO A MENO?

Scrivici dove e ti sconteremo la differenza fino a fine mese!

meno


EXTERNAL IP ONVIF CAMERA - 8MEGAPIXEL - 3.6MM - ARTIFICIAL INTELLIGENCE - DAHUA

Dahua ONVIF PoE IP Camera - AI Dahua Series
8Megapixel resolution - 3.6mm optics - CMOS 1 / 2.8 " Starlight - H.265 + compression
1 LED 30M IR Illuminator - Day / Night (ICR) - WDR 120dB - MicroSD Slot (Not Included) - Video Analysis
Artificial intelligence: Perimeter protection
Standard Video Analysis: Line Crossing, Intrusion

Tecnologia Intelligenza Artificiale

AI TECHNOLOGY | ARTIFICIAL INTELLIGENCE:
Artificial intelligence (AI) refers to the branch of science and engineering that produces intelligent machines, especially intelligent computer programs. In the security sector, on the other hand, the artificial intelligence used is the one that allows the creation of advanced devices for environmental analysis.

Product details

IPC-HFW3441E-SA Telecamera AI IP ONVIF PoE 2MP 2.8mm

  • Onvif PoE AI external IP camera - Dahua
  • 8Megapixel 8MP resolution
  • 3.6mm fixed lens
  • 1 / 2.8 ” CMOS sensor with Starlight Technology !
    Starlight technology: Color vision even at night!
  • Video compression up to H.265 +
  • Triple Stream
  • WDR 120dB - Day / Night (ICR), Defog
  • Smart IR illuminator 1 LED 30 meters
  • Artificial Intelligence : Line Pass Detection, Intrusion Detection (Supports Accurate Classification of Vehicles and Humans
  • Standard Video Analysis : Line Crossing, Intrusion
  • Remote viewing with DMSS / Cloud P2P
  • Micro SD memory slot (Up to 256GB - not included)
  • IP67 protection (indoor / outdoor)
  • Material: Metal
  • Power supply NOT included
  • 24 months warranty

Data sheet

Model IPC-HFW3841E-SA
Room
Image Sensor 1 / 2.8 ”8Megapixel progressive CMOS
Effective Pixel 3840 (H) × 2160 (V)
ROM / RAM 128MB / 512MB
Scanning System Progressive
Electronic Shutter speed Auto / Manual 1/3 s – 1 / 100,000 s
Min. Illumination

0.007 Lux @ F1.4

S / N Ratio

> 56 dB

IR Distance 30 m (98.4 ft)
IR On / Off Control Auto / Manual
IR LEDs 1 8IR LED)
Pan / Tilt / Rotation Range Pan: 0 ° –360 ° Tilt: 0 ° –90 ° Rotation: 0 ° –360 °
Lens
Lens Type Fixed focal
Mount Type M12
Focal Length 3.6mm
Max. Aperture F1.4
Field Of View Horizontal 85 ° × Vertical 45 ° × Diagonal 100 °
Iris Type Fixed
Close Focus Distance 2.4 m (7.9 ft)
Professional, Intelligent
Perimeter Protection Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec Smart H.265 + / Smart H.264 +
Video Frame Rate

Main stream: 3840 × 2160 @ (1–20 fps by default) 3840 × 2160 @ (1–25 / 30 fps when AI function disabled)
sub stream: 704 × 576 @ (1–25 fps) / 704 × 480 @ (1–30 fps)
third stream: 1920 × 1080 @ (1–25 / 30 fps)

Stream Capability 3 streams
Resolution 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Resolution

8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control CBR / VBR
Video Bit Rate H.264: 3 kbps – 8192 kbps
H.265: 3 kbps – 8192 kbps
Day / Night Auto (ICR) / Color / B / W
BLC Yes
HLC Yes
WDR 120 dB
Scene Self Adaption Yes
White Balance Auto / natural / street lamp / outdoor / manual / regional custom
Gain Control Auto / Manual
Noise Reduction 3D DNR
Motion Detection OFF / ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Smart IR Yes
Image Rotation 0 ° / 90 ° / 180 ° / 270 ° (Support 90 ° / 270 ° with 1080p resolution and lower.)
Mirror Yes
Privacy Masking 4 areas
Audio
Built-in MIC Yes
Audio Compression G.711a; G.711Mu; G726
Alarm
Alarm Event No SD card; Full SD card; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; SMD; safety exception
Network
Ethernet RJ-45 (10/100 Base-T)
SDK and API Yes
Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP

Cyber Security

Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP / MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Interoperability ONVIF (Profile S / Profile G / Profile T); CGI; P2P; Milestone; Genetec
Scene Self-adaptation Yes
User / Host 20 (Total bandwidth: 72M)
Edge Storage

FTP; SFTP; Micro SD card (support max. 256 G); NAS

Web Viewer IE: IE8; IE9; IE11 Chrome Firefox
Management Software Smart PSS; DSS; DMSS
Smartphone IOS, Android
Certification
Certifications CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30 / EU FCC: 47 CFR FCC Part 15, Subpart B UL / CUL: UL60950-1 CAN / CSA C22.2 No.60950-1-07
Port
Audio Input 1 channel (RCA port) (Only - AS supports)
Audio Output 1 channel (RCA port) (Only - AS supports)
Alarm Input 1 channel in: 5mA 3V – 5V DC (Only - AS supports)
Alarm Output 1 channel out: 300mA 12V DC (Only - AS supports)
Power
Power Supply 12V DC / PoE (802.3af)
Power Consumption

Basic power consumption: 3W (12V DC); 3.5W (PoE) Max. Power consumption (WDR + H.265 + IR LED intensity): 5.5W (12V DC); 6.3W (PoE)

Environment
Operating Conditions –40 ° C to + 60 ° C (–40 ° F to + 140 ° F) / Less than 95% RH
Storage Conditions –40 ° C to + 60 ° C (–40 ° F to + 140 ° F)
Ingress Protection IP67
Structure
Casing Metal
Dimensions 192.7 mm × 70.5 mm × 66.4 mm (7.6 "× 2.8" × 2.6 ") (L × W × H)
Net Weight 590 g (1.3 lb)
Gross Weight 780 g (1.7 lb)

Further details

Questo prodotto rispetta lo standard Onvif

All Onvif , the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif, it means having a camera for its own sake that can never be used together with recording systems

This camera is ONVIF compatible

PoE power supply The advantage of a PoE camera is obvious, it allows it to be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power supply system, a PoE camera guarantees constant voltages and simple installation

AI | Artificial intelligence
This camera features Artificial Intelligence on board
This means that it has a wide range of advanced features such as:

- Perimeter protection: Intrusion, Line crossing (classification of people & vehicles)

Codifica video Smart H.265+

Smart H.265 +

Smart H.265 + is the optimized implementation of the H.265 codec which uses a scene adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference frame and intelligent noise reduction useful for delivering high quality video without straining the network.

Smart H.265 + greatly reduces bit rate and storage requirements compared to standard H.265 compression

Video compressione Smart H.265+

Questa telecamera ha una risoluzione 8Mpx 3840 x 2160 This camera has a resolution of 8Megapixels :

1 / 2.8 ”8Megapixel progressive scan CMOS image sensor

1 / 2.8 "sensor with STARLIGHT technology.

Low brightness, color vision even in night mode



With this sensor it is possible to have color shots even in night mode.

Normally, when entering night mode, the color vision becomes black / white.

With the SENSOR present, night shots will be in color

Ottica fissa This camera features a fixed 3.6mm lens

Main stream 3840 × 2160 @ (1–20 fps by default), 3840 × 2160 @ (1–25 / 30 fps when AI function disabled)
sub stream 704 × 576 @ (1–25 fps) / 704 × 480 @ (1–30 fps)
third stream 1920 × 1080 @ (1–25 / 30 fps)

Illuminatore IR fino a 30mt

Infrared illuminator with 1 LED and maximum range 30 meters!

This camera is also equipped with SMART IR technology .
Through this technology, the light emitted by the LEDs is adapted according to the object framed.

Full HD

Remote visibility on mobile using Dahua's DMSS application.

ULTRA WDR up to 120dB
WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light / shadow contrast. Fundamental in the case of shots from the inside out, license plates, shaded spots or all situations where there is no homogeneity of light.
Day / Night Function Icon Day / Night: allows you to adapt the lens to night / day vision, and the relative automatic management of the IR illuminator, when present.
Example Day / Night function
Funzione IR Cut Filter

The IR CUT FILTER is a mechanical filter that allows a correct visualization of the images in daylight viewing conditions, filtering the typical infrared frequencies, thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.

Esempio Funzione IR Cut Filter

Funzione ROI This camera is equipped with the ROI function .

The images deriving from IP cameras are “compressed”, consequently the quality is set during the recording phase. Especially on cameras with a very high resolution, it is often necessary to reduce the quality in order to guarantee a reduced bandwidth occupation and to record a greater number of days or cameras.
The ROI allows you to define areas where you can set a higher quality (for example a door, the area where the plate usually passes, an exit, etc.). In that area I can set a higher quality thus guaranteeing a greater definition of the image.
Ultra Smart Funzione ROI
DEFOG Function Icon It allows you to clearly see images taken in particular climatic conditions: rain, smoke and fog
DEFOG function example image
DEFOG function example image
Protezione IP67 contro polveri e immersioni Protection level IP67 (Dust / Diving)

MicroSD Recording

Possibility to insert Micro SD up to maximum 256Gb - not included

12V 3A power supply Power supply NOT included
12V DC power supply
Italian Guarantee Icon This product is covered by a 24 month warranty.

Download

Download the English brochure
Schema dimensioni telecamera IPC-HFW3841E-SA Dahua
