CAMERA LENS - 35mm FIXED LENS - 12MPX - IR CORRECTION - DAHUA - PFL35-L12M-AIR

Surveillance Camera Lens - Dahua - PFL35-L12M-AIR
12Megapixel - 35MM motorized lens - 1/1" sensor - C mount
IR Correction - Motorized Zoom - Motorized Focus - Quality Product - Made of Metal - Black Color - Ideal for use in video surveillance systems operating in low-light environments, for face capture and for high-definition image acquisition at night - P-Iris Control - Weight: 0.317 ± 0.005 kg - Product Dimensions: Ф50 mm × 76.1 mm
Product details
- Lens - Dahua - PFL35-L12M-AIR
- 1/1" sensor
- 12Megapixels
- Total focal length: 35mm
- Aperture: F1.4 ± 10%
- Ideal for face capture in low light conditions
- C attack
- IR correction, ideal for high definition shots in night environments
- Material: metal
- Color: Black
- Supported operating temperature: –30°C to +70°C
- Product net weight: 0.317 ± 0.005 kg
- Product size: Ф50mm × 76.1mm

Technical data sheet
| Model | PFL35-L12M-AIR |
| General | |
| Image Sensor Size | 1.1" |
| Focal Length | 35mm |
| Pixel | 12MP |
| Max. Openings | F1.4 ± 10% |
| IR Correction | Yes |
| CRA | 8.3° |
| Total Optical Length | 88.5 mm ± 0.5 mm (3.72" ± 0.02") (in air) |
| Flange Back Focal Length | 17.53 mm ± 0.2 mm (0.69" ± 0.01") (in air) |
| Mechanical Back Focal Length. | 13.53 mm ± 0.2 mm (0.53" ± 0.01") (in air) |
| Field of View | 29.4° × 24.1° × 16.5° (@17.56 × 14.47 × 9.94 mm) |
| Distortion | –3.3% |
| Minimum Object Distance (MOD) | 3 m (3.28 ft) |
| Control Mode | |
| Zoom | Fixed |
| Focus Control | Manual |
| Iris Control | Manual |
| Port | |
| Port Type | C mount |
| Structure | |
| Product Dimensions | Ф50 mm × 76.1 mm (Ф1.97" × 2.99") |
| Appearance Color | Black |
| Casing | Metal |
| Net Weight | 0.317 kg ± 0.005 kg (0.7 lb ± 0.01 lb) |
| Gross Weight | 0.38 kg ± 0.010 kg (0.84 lb ± 0.02 lb) |
| Packaging Method | 30 pieces in one carton (4.88" × 3.23" × 3.5") (L × W × H) |
| Packaging Dimensions | Package: 124mm × 82mm × 89mm |
Further details

Download
Download Brochure English
