Ajax Superior StreetSiren DoubleDeck Fiber White Siren 113 dB IP54 with Brandplate and 2000 m Fiber Communication

Ajax Superior StreetSiren DoubleDeck Fiber White Siren 113 dB IP54 with Brandplate and 2000 m Fiber Communication

 
ANUNCIOS

143638.61.WH1 # 143638 | Ajax Superior StreetSiren DoubleDeck Fibra white is a professional wired siren for indoor and outdoor use with Fiber communication technology up to 2,000 m , designed for high-performance security systems. It offers adjustable sound power from 85 to 113 dB , integrated LED signals and configurable alarm duration from 3 seconds to 3 minutes, ensuring maximum deterrence. It integrates a customizable Brandplate for corporate branding, anti-sabotage tamper protection, device authentication and short circuit protection. Thanks to the integrated rechargeable backup battery , data encryption and IP54 protection degree, it ensures reliability, security and operational continuity in every professional installation. Ajax

Technical Data Sheet

referencia : 143638.61.WH1

brand : Ajax Systems

EAN: 4823114079535

Disponibilità: 1

Manufacturer Object ( [id] => 31 [name] => Ajax Systems [description] =>

Establecido en 2011, Ajax Systemconstruye sistemas inalámbricos de incendio y alarma con la tecnología inalámbrica JEWELLER que le permite monitorear de manera segura todos los dispositivos de red conectados. Ajax System ofrece soluciones para el hogar, la oficina o las actividades comerciales, gestionables a través de la App, siempre actualizadas y compatibles con los sistemas iOS y Android. Los sistemas de alarma de Ajax System son fáciles de instalar, de hecho sólo toma 15 segundos conectar la unidad de control a los sensores. Además, pueden integrarse con las cámaras de vigilancia, tienen un margen de error casi nulo y, en caso de peligro, en menos de 150 milisegundos envían una notificación (sms, push o call).

[short_description] =>

Ajax SystemsAjax Systems


Los sistemas de alarma Ajax system utilizan la última tecnología inalámbrica que hace que todos los productos sean fiables y estén siempre conectados. Además de su excelente rendimiento, los sistemas de alarma Ajax se distinguen por su diseño moderno y elegante.

[id_address] => [date_add] => 2019-01-15 15:51:16 [date_upd] => 2026-03-03 17:54:49 [link_rewrite] => ajax-systems [meta_title] => Sistemas de incendio y alarma de última generación - Ajax System [meta_keywords] => sistemi allarme ajax,sicurezza ajax,allarmi ajax,ajax security system,ajax security,ajax system [meta_description] => I sistemi allarme Ajax system sono dispositivi wireless affidabili e innovativi, non producono falsi allarmi e si installano in 15 secondi. Scoprili su Setik.biz! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 25 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
BUSQUE INSTALADOR

143638.61.WH1 | WIRELESS SIREN WITH A MOUNT FOR A CUSTOMIZABLE FRONT PANEL


Ajax

Ajax Superior StreetSiren DoubleDeck Fibra white is a professional wired siren for indoors and outdoors with Fiber technology up to 2,000 m , designed for high-performance security systems and encrypted data transmission. It offers adjustable sound power from 85 to 113 dB , integrated LED signals and configurable alarm duration from 3 seconds to 3 minutes, ensuring maximum deterrence. It integrates a customizable Brandplate for corporate branding, anti-sabotage tamper protection and device authentication against spoofing. Thanks to the rechargeable backup battery , advanced energy management and IP54 protection rating, it ensures reliability and operational continuity even in outdoor environments.

Main specifications:

- Wired fiber communication up to 2,000 m with encrypted data

- Adjustable volume 85–113 dB with integrated LEDs

- Customizable brandplate for company logo

- 100 automation scenarios and 100 security groups

- IP54 protection rating for indoor and outdoor use

Further details

✅ Fiber Communication:
It uses wired fiber technology with a range of up to 2,000 meters , encrypted data transmission , regular polling of device status and connection on U/UTP line, ensuring stability, security and immunity to interference .
✅ Main features :
Siren with adjustable volume 85–113 dB , audible and LED signals , group mode, system status indication and customizable Brandplate for professional branding, ideal for indoor and outdoor installations .
✅ Anti-sabotage protection :
 Equipped with anti-opening tamper , short circuit protection, anti-spoofing device authentication and resistant structure, ensuring maximum security against tampering .
✅ Power supply:
 Main power supply 7–26 V DC up to 1,130 mW via hub or Fiber LineSupply, with advanced power management and constant consumption monitoring.
✅ Notifications:
 Instant sending of alarms and events to Ajax apps and monitoring center via IP and cellular channels, with event logging of up to 1,000 logs in non-volatile memory.
✅ Compatibility:
Compatible with Ajax hubs equipped with Fiber technology , can be integrated into Superior professional systems and managed via the Ajax PRO app for remote configuration .

Technical data sheet

143638.61.WH1
Compatibility
Compatible hub models Hybrid Hub (2G)
Hybrid Hub (4G)
Communication
Fiber communication technology Proprietary wired communication technology.
Fiber combines the reliability of wires with the freedom of radio connection.
It features Two-way communication.
Advanced anti-sabotage.
Instant notifications.
Remote configuration via the Ajax apps.
Line connection 4-core cable
Fiber line length up to 2,000 m / up to 6,600 ft
When using the U/UTP cat.5 twisted pair.
Key features
Alarm type acoustic and LED
Buzzer and LED frame
Alarm volume from 85 to 113 dB at a distance of 1 m / 3.3 ft
Adjusted by PRO or user with admin rights in the Ajax app.
Alarm duration from 3 s to 3 min
Adjusted by PRO or user with admin rights in the Ajax app
Siren sound frequency 3.5 ± 0.5 kHz
Chime The siren makes a special sound to notify that the opening detectors are triggered when the system is disarmed.
Events indication Alerts
Entry/exit delays
Security mode
Security mode changing
After-alarm indication
Customized branded faceplate
Brandplate Security service providers can print their logo and contact information on the siren's front panel.
Brandplate is sold separately from street sirens. To place an order, reach out to your regional Ajax partner. You can also compose a faceplate design in the Brandplate constructor.
Anti-sabotage protection
Tampering alarm Sends notification if anyone tries to detach the siren from its surface or remove the device from the mounting panel.
Protection against forgery Device authentication
Power supply
Fiber line power supply 7−30 V⎓, up to 1.2 W
The siren is powered by the control panel.
Enclosure
Dimensions 198.5 × 198.5 × 59 mm
7.81″ × 7.81″ × 2.32″
Weight 516 g
18.20 oz
Operating temperature range from −25°C to +60°C
from −13°F to 140°F
Operating humidity up to 95%
Protection class IP54
Color White
Complete set Superior StreetSiren DoubleDeck Fiber
SmartBracket mounting panel
Installation kit
Quick start guide
Warranty 24 months
