DS-2CD2H46G2H-IZSY 4MP DarkFighter with Varifocal Lens 2.8-12mm F1.0, WDR 120dB, IP67 IK10 - Hikvision

DS-2CD2H46G2H-IZSY 4MP DarkFighter with Varifocal Lens 2.8-12mm F1.0, WDR 120dB, IP67 IK10 - Hikvision

 
Optic calculation
BEST SELLER -35% nuevo

DS-2CD2H46G2H-IZSY(2.8-12mm) - is a 4MP (2688×1520) IP turret camera with 1/3" Progressive Scan CMOS sensor , designed for high-performance professional video surveillance. It integrates a 2.8–12 mm motorized varifocal lens with F1.0 aperture and horizontal FOV from 105.4° to 34.3° , ensuring maximum framing flexibility and excellent performance in conditions of 0.001 Lux thanks to Powered by DarkFighter technology. It offers 120 dB WDR , H.265+ compression, IR up to 40 m , as well as deep learning functions for people and vehicle classification and advanced perimeter protection. The structure is IP67, IK10 and NEMA 4X certified, with PoE support, microSD slot up to 512 GB and ONVIF compatibility, ideal for outdoor installations high reliability. Hikvision

Technical Data Sheet

referencia : DS-2CD2H46G2H-IZSY(2.8-12mm)

brand : Hikvision

EAN: 6936422162092

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Desde el año de su nacimiento, su prestigio ha crecido tanto que en 2015 se convertirá en la primera realidad mundial en materia de seguridad.

A partir de 2016 Hikvision expande su mercado convirtiéndose en Proveedor de Soluciones Totales para todo el mercado de la seguridad. Así entra en el mundo de la detección de intrusos y luego se acerca a las nuevas tecnologías e inteligencia al servicio de la humanidad ocupándose de IO, Visión Artificial, Robótica y Sistemas Automovilísticos. De líder en seguridad, Hikvision se convierte con compromiso, pasión y competencia en una empresa de alta tecnología con una visión 4.0, siempre apuntando alto.

Por lo tanto, Setik se siente honrado de ser un distribuidor de Hikvision. Como siempre, ofreceremos productos de última generación y el apoyo técnico y comercial adecuado.

[short_description] =>

Videosorveglianza Hikvision

Hikvision fue fundada en 2001 con el objetivo de crear y desarrollar soluciones profesionales completas de videovigilancia, convirtiéndose rápidamente en un líder en el mundo de la seguridad.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Seguridad hikvision [meta_keywords] => Seguridad hikvision [meta_description] => Hikvision fue fundada en 2001 y pronto se convirtió en líder del mundo de la videovigilancia. Descubra ahora los productos del catálogo! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 25 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
BUSQUE INSTALADOR

¡ENVÍO GRATIS! ×

FREE SHIPPING ON
THE ENTIRE CATALOGUE!
Code: FREE-WEEK-E
Only until 10:00 a.m. on 16/02

DS-2CD2H46G2H-IZSY(2.8-12mm) – VARIFOCAL LENS TURRET CAMERA 2.8-12mm 4MP - HUMAN AND VEHICLE DETECTION - DEEP LEARNING FUNCTION - DARKFIGHTER

Hikvision

The Hikvision DS-2CD2H46G2H-IZSY is a 4MP (2688×1520) turret IP camera with a 1/3" Progressive Scan CMOS sensor, designed for professional indoor and outdoor video surveillance. It integrates a 2.8-12 mm motorized varifocal lens with F1.0 aperture and a horizontal viewing angle of 105.4° to 34.3° , ensuring maximum installation flexibility and excellent performance down to 0.001 Lux thanks to DarkFighter technology. It offers 120 dB WDR , H.265+ compression, IR up to 40 m and deep learning functions for people and vehicle classification with advanced perimeter protection. The metal structure with IP67, IK10 and NEMA 4X certifications ensures resistance to water, dust and vandalism, with PoE support and a microSD slot up to 512 GB.

Main features:

- Resolution 4 MP (2688×1520)

- 2.8-12 mm F1.0 motorized varifocal lens

- DarkFighter Technology 0.001 Lux

- 120dB real WDR and H.265+ compression

- IR up to 40m with Smart Supplement Light

- IP67, IK10, NEMA 4X protection

Further details

✅ Varifocal optics :
 2.8–12mm motorized varifocal lens allows precise framing adjustment with a horizontal viewing angle of 105.4° to 34.3° , F1.0 aperture and remote focus, ideal for professional indoor and outdoor installations.
✅ Resolution:
 4MP 2688×1520 1/3" Progressive Scan CMOS sensor ensures high definition images, sharp details and smooth recording up to 30 fps, optimized with H.265+ compression to reduce bandwidth and storage.
✅ DarkFighter :
Excellent low-light performance down to 0.001 Lux , with IR support up to 40m and Smart Supplement Light for advanced nighttime video surveillance.
✅ Human Detection and Vehicle Detection:
Deep Learning-based intelligent classification system that distinguishes people and vehicles, reducing false alarms and improving the effectiveness of perimeter security
✅ Motion Detection :
 Motion detection with alarm activation on specific targets, support for events such as line crossing, intrusion, region entrance and exiting , for complete protection of the monitored area.
✅ Deep Learning Function :
 Integrated smart functions for perimeter protection and face capture , with intelligent video analytics for professional security applications.
✅ I/O Alarm :
Management of 1 alarm input and 1 alarm output (24VDC/24VAC, 1A) with notifications via email, FTP/NAS and automatic recording activation.
✅  Network Protocol:
 Wide compatibility with TCP/IP, HTTPS, RTSP, ONVIF (Profile S, T, G), IPv4/IPv6 protocols, TLS 1.1/1.2/1.3 encryption, 802.1X authentication and integration with major VMS.

Technical data sheet

DS-2CD2H46G2H-IZSY(2.8-12mm)
Room
Image Sensor 1/3" Progressive Scan CMOS
Max. Resolution 2688 × 1520
Min. Illumination Color: 0.001 Lux @ (F1.0, AGC ON),B/W: 0 Lux with IR
Shutter Time 1/3 s to 1/100,000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV horizontal FOV 105.4° to 34.3°, vertical FOV 56.1° to 19.3°, diagonal FOV 125.8° to 39.4°
Lens Mount Ø14
Iris Type Fixed
Openings F1.0
Depth of Field 1 m to ∞
Illuminator
Supplement Light Type IR, White Light
Supplement Light Range Up to 40 m
Smart Supplement Light Yes
IR Wavelength 850mm
Video
Main Stream 50 Hz:
25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream

50Hz: 25fps (1280×720, 640×480, 640×360)
60Hz: 30fps (1280×720, 640×480, 640×360)
Third Stream

50Hz: 10fps (1920×1080, 1280×720, 640×480, 640×360)
60Hz: 10fps (1920×1080, 1280×720, 640×480, 640×360)
*Third stream is supported under certain settings.
Video Compression

Main stream: H.265/H.264/H.264+/H.265+,
Substream: H.265/H.264/MJPEG
Third stream: H.265/H.264,
*Third stream is supported under certain settings.
Video Bit Rate

32 Kbps to 8 Mbps
H.264 Type

Baseline Profile, Main Profile, High Profile
H.265 Type

Main Profile
Bit Rate Control

CBR,VBR
Region of Interest (ROI)

1 fixed region for main stream and sub-stream
Scalable Video Coding (SVC)

H.264 and H.265 encoding
Audio
Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate

64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate

8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise Filtering

Yes
Network
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Simultaneous Live View

Up to 6 channels
API ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
User/Host

Up to 32 users.
3 user levels: administrator, operator and user
Client

iVMS-4200,Hik-Connect,Hik-Central
Network Storage

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
Web Browser

Plug-in required live view: IE 10, IE 11,
Plug-ins required live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch

Yes
Image Settings

Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
Day/Night Switch

Day, Night, Auto, Schedule
Wide Dynamic Range (WDR)

120 dB
SNR ≥ 52 dB
Image Enhancement BLC, HLC, 3D DNR
Privacy Mask

4 programmable polygon privacy masks
Interface
Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512GB
Reset Key Yes
Audio 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarm 1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
Event
Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
Smart Event Face detection
Linkage Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture
Deep Learning Function
Face Capture Yes
Perimeter Protection Line crossing, intrusion
Support alarm triggering by specified target types (human and vehicle)
General
Power

12 VDC ± 25%, 0.9 A, max. 10.8 W,2-core terminal block,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 12.95W
Material

Base: Metal, cover: Metal
Dimension

Ø143.5 mm × 142.7 mm (Ø5.7" × 5.6")
Package Dimension

170 mm × 170 mm × 225 mm (6.7" × 6.7" × 8.9")
Weight

Approx. 1270 g (2.8 lb.)
With Package Weight

Approx. 1540 g (3.4 lb.)
Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function

Heartbeat, mirror, flash log, password reset via email, password protection, anti-banding
Approval
EMC CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
Safety CB: IEC 62368-1: 2014+A11,
Environment

CE-RoHS (2011/65/EU)
WEEE (2012/19/EU)
Reach: Regulation (EC) No 1907/2006,NEMA 4X (NEMA 250-2018)
Protection

IP67: IEC 60529-2013,IK10: IEC 62262:2002
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
