DS-2DE7A225IWG1-E Speed Dome PTZ 2MP 4.8-120mm 25x Zoom AcuSense DarkFighter IR 200m PoE - Hikvision

DS-2DE7A225IWG1-E Speed Dome PTZ 2MP 4.8-120mm 25x Zoom AcuSense DarkFighter IR 200m PoE - Hikvision

 
Optic calculation
-35%

DS-2DE7A225IWG1-E - is a 2 MP PTZ Speed Dome IP camera with 1/2.8" Progressive Scan CMOS sensor and 4.8-120 mm motorized lens, equipped with 25x optical and 16x digital zoom for detailed control of large areas. It integrates DarkFighter , HIK AI-ISP and AcuSense technology with Deep Learning for intelligent classification of people and vehicles , as well as Face Capture and regional people counting. It offers IR up to 200 m , 360° Pan movement, 120 dB WDR , integrated dual microphone, speaker, Smart Tracking and audiovisual alarm. It also supports PoE 802.3bt / Hi-PoE , microSD up to 512 GB , H.265+ compression and IP67 and IK10 protection, ideal for professional outdoor video surveillance. Hikvision

Technical Data Sheet

referencia : DS-2DE7A225IWG1-E

brand : Hikvision

EAN: 6936422189594

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Desde el año de su nacimiento, su prestigio ha crecido tanto que en 2015 se convertirá en la primera realidad mundial en materia de seguridad.

A partir de 2016 Hikvision expande su mercado convirtiéndose en Proveedor de Soluciones Totales para todo el mercado de la seguridad. Así entra en el mundo de la detección de intrusos y luego se acerca a las nuevas tecnologías e inteligencia al servicio de la humanidad ocupándose de IO, Visión Artificial, Robótica y Sistemas Automovilísticos. De líder en seguridad, Hikvision se convierte con compromiso, pasión y competencia en una empresa de alta tecnología con una visión 4.0, siempre apuntando alto.

Por lo tanto, Setik se siente honrado de ser un distribuidor de Hikvision. Como siempre, ofreceremos productos de última generación y el apoyo técnico y comercial adecuado.

[short_description] =>

Videosorveglianza Hikvision

Hikvision fue fundada en 2001 con el objetivo de crear y desarrollar soluciones profesionales completas de videovigilancia, convirtiéndose rápidamente en un líder en el mundo de la seguridad.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Seguridad hikvision [meta_keywords] => Seguridad hikvision [meta_description] => Hikvision fue fundada en 2001 y pronto se convirtió en líder del mundo de la videovigilancia. Descubra ahora los productos del catálogo! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 25 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
BUSQUE INSTALADOR

DS-2DE7A225IWG1-E – 4.8-120mm 2MP VARIABLE LENS PTZ CAMERA – ARTIFICIAL INTELLIGENCE – DARKFIGHTER – 25x OPTICAL ZOOM

Hikvision

The Hikvision DS-2DE7A225IWG1-E is a 2 MP PTZ Speed Dome IP camera with 1/2.8" Progressive Scan CMOS sensor and 4.8-120 mm motorized lens, equipped with 25x optical and 16x digital zoom for the control of large areas. It integrates DarkFighter , HIK AI-ISP and AcuSense with Deep Learning for intelligent classification of people and vehicles . It offers IR up to 200 m , Pan 360° , WDR 120 dB , Face Capture up to 5 faces, regional people counting, Smart Tracking and audiovisual alarm. It also features a built-in dual microphone , speaker, PoE 802.3bt / Hi-PoE , microSD up to 512 GB and IP67 and IK10 protection.

Main features:

  • Resolution: 2 MP
  • Lens: 4.8-120 mm
  • Zoom: 25x optical
  • AI: AcuSense + Deep Learning
  • DarkFighter: low light vision
  • IR: up to 200m
  • PTZ: Pan 360°
  • Audio: dual microphone + speaker
  • Tracking: Smart Tracking
  • PoE: 802.3bt / Hi-PoE
  • Protection: IP67 + IK10

Further details

✅ Optics :
 4.8-120mm motorized lens with F1.6 maximum aperture , 25x optical zoom and 16x digital zoom, designed to obtain close-up details even at long distances and effectively monitor very large areas.
✅ Resolution:
 1 /2.8" Progressive Scan CMOS sensor with maximum resolution of 2 MP (1920 × 1080) and frame rate of up to 50/60 fps in certain configurations, for smooth and detailed Full HD images.
✅ Artificial Intelligence:
 It integrates Hikvision AcuSense and HIK AI-ISP , leveraging intelligent algorithms for human and vehicle target classification , improving alarm efficiency and reducing irrelevant events.
✅ DarkFighter:
 Powered by DarkFighter technology optimized for low-light surveillance , with sensitivity up to 0.005 Lux in color , 0.001 Lux in black and white and IR illumination up to 200 meters .
✅ PTZ Camera:
 Network Speed Dome PTZ camera with 360° continuous Pan rotation , Tilt from -15° to 90° with Auto Flip, Pan speed up to 160°/s and 300 presets , as well as 8 patrols, 4 pattern scans and 3D positioning.
✅ Audio:
 It integrates dual array microphones with a range of up to 8 meters and a built-in speaker up to 30 meters , as well as audio input/output, ambient noise filtering and support for multiple codecs for advanced audio management.
✅ Alarm:
 It has 2 alarm inputs and 1 alarm output and supports events such as motion detection, line crossing, intrusion and area entry/exit , triggering recording, notifications, audible warning, white light flashing and PTZ actions.
✅ Deep Learning Function:
 Deep Learning algorithms support Face Capture of up to 5 faces simultaneously and Regional People Counting of up to 8 areas , with analysis of density, anomalies in the number of people and waiting times.
✅ Smart Tracking:
 Smart Tracking function with manual tracking and Auto-Tracking , which allows the Speed Dome to dynamically follow subjects as they move within the video surveillance area.
✅ PoE :
 It supports IEEE 802.3bt Type 3 Class 6 and Hi-PoE power supply , allowing it to transmit power and data across the network infrastructure; it also supports 36 VDC power supply .
✅  Network:
 It has 10/100 Mbps Ethernet RJ45 port and supports IPv4/IPv6, HTTP/HTTPS, RTSP, TCP/IP and numerous network protocols, as well as ONVIF Profile S/G/T , ISAPI, SDK, Hik-Connect, HikCentral Pro and iVMS-4200, with up to 20 simultaneous live views .

Technical data sheet

DS-2DE7A225IWG1-E
Room
Image Sensor 1/2.8" Progressive Scan CMOS
Max. Resolution 1920 × 1080
Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @ (F1.6, AGC ON)
Shutter Time 1/3 s to 1/30,000 s
Day & Night IR cut filter
Zoom 25x optical, 16x digital
Slow Shutter Yes
Lens
Focal Length 4.8 mm to 120 mm
FOV Horizontal field of view: 55° to 2.65°
Vertical field of view: 33° to 1.5°
Diagonal field of view: 61.5° to 3.03°
Focus Auto, semi-auto, manual
Openings Max. F1.6
Zoom Speed Approx. 3.5 s
Illuminator
Supplement Light Type IR
Supplement Light Range IR Distance: up to 200 m
PTZ
Movement Range (Pan) 360°
Movement Range (Tilt) -15° to 90° (auto flip)
Pan Speed pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
Tilt Speed tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
Proportional Pan Yes
Presets 300
Preset Freezing Yes
Patrol Scan 8 patrols, up to 32 presets for each patrol
Pattern Scan 4 pattern scans
Park Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
3D Positioning Yes
PTZ Status Display Yes
Scheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
Power-off Memory Yes
Video
Main Stream 50Hz: 25fps (1920×1080, 1280×960, 1280×720),
60Hz: 30fps (1920×1080, 1280×960, 1280×720)
*High frame rate is supported under certain settings.
Sub-Stream 50Hz: 25fps (704×576, 640×480, 352×288)
60Hz: 30fps (704×480, 640×480, 352×240)
Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression

Main stream: H.265/H.264/H.264+/H.265+,
Substream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG
Video Bit Rate

32 Kbps to 16384 Mbps
H.264 Type

Baseline Profile, Main Profile, High Profile
H.265 Type

Main Profile
Scalable Video Coding (SVC)

H.264 and H.265 encoding
Bit Rate Control

CBR,VBR
Region of Interest (ROI)

8 fixed regions for each stream
Audio
Audio Compression G.711,G.722.1,G.726,MP2L2,PCM,MP3,AAC-LC
Audio Bit Rate 64 Kbps (G.711),16 Kbps (G.722.1),16 Kbps (G.726),32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),8 to 320 Kbps (MP3)
Audio Sampling Rate MP2L2: 16kHz,AAC-LC: 16kHz,PCM: 8kHz, 16kHz,MP3: 8kHz, 16kHz
Environment Noise Filtering Yes
Network
Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Simultaneous Live View

Up to 20 channels
API Open Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
User/Host

Up to 32 users.
3 user levels: administrator, operator and user
Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)
Client

iVMS-4200, HikCentral Pro, Hik-Connect
Network Storage

NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Web Browser

Chrome 80+, Firefox 80+, Safari 13+, Edge 89+
Image Settings

Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
Day/Night Switch

Day, Night, Auto, Schedule
Wide Dynamic Range (WDR)

120 dB
SNR ≥ 52 dB
Defog Digital defog
Image Stabilization EIS
Image Enhancement BLC, HLC, 3D DNR
Privacy Mask

24 programmable polygon privacy masks, mask color or mosaic configurable
Regional Focus

Yes
Regional Exposure

Yes
VR View

360° Real Scene Stitched Panoramic Image
Interface
Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512GB
Built-in Speaker 1 built-in speaker with effective distance reaching max. 30 meters
Audio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%;
1 output (line out), line level, output impedance: 600 Ω
Alarm 2 inputs, 1 output
Reset Key Yes
Built-in Microphone 2 built-in Microphone: Arrayed dual-microphone up to 8 meters
Event
Basic Event Motion detection, video tampering alarm, exception, alarm input and output
Smart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection
Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan, tracking)
Deep Learning Function
Face Capture Detects up to 5 faces simultaneously.
Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the face
Regional People Counting Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 3 detection modes: people density detection, number of people exception detection, waiting time exception detection
Supports searching real-time number of people
Linkage and Tracking
Smart Tracking Manual tracking, auto-tracking
General
Power

36 VDC (Max. 48 W, including max. 9 W for IR and max. 2 W for heater),
PoE 802.3bt, type3, class6,
HI-PoE
Dimension

Ø 220 mm × 363.3 mm (Ø 8.66" × 13.91")
Weight

Approx. 5 kg (11.03 lb.)
Material

ADC12, PC+10%GF
Operating Conditions

-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
Demist

Yes
Approval
EMC CE-EMC (EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021+A2:2024, EN 61000-3-3:2013+A1:2019+A2:2021),RCM (AS/NZS CISPR 32: 2015)
Safety CB (IEC 62368-1:2014), CE-LVD (EN 62368-1:2014 + A11:2017)
Environment

CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
Protection

IP67 (IEC 60529-2013),IK10 (IEC 62262:2002),TVS 6000 V lightning protection, surge protection and voltage transient protection
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
