HAC-HDBW3802E-Z | 8MEGAPIXEL 3.7-11MM MOTORIZED HDCVI DOME CAMERA

Dahua

The Dahua HAC-HDBW3802E-Z is an 8MP 4K dome camera with a 1/2" sensor, 3x motorized optical zoom and IR night vision up to 50 m. Thanks to HDCVI technology, it transmits 4 signals on a single coaxial cable, supports dual HDCVI/CVBS video output and guarantees exceptional quality even in high-contrast light conditions, thanks to 120 dB WDR. Resistant to dust, water and vandalism (IP67/IK10), it is the ideal choice for 24/7 professional video surveillance .

Main specifications:

- 4K resolution (3840×2160) at 15fps

- 3.7–11 mm motorized lens, F1.5

- Smart IR night vision up to 50m

- 4 signals on 1 coaxial cable (video, audio, data, power)

- Dual HDCVI + CVBS video output

- IP67 and IK10 protection, dual DC/AC power supply

Further details

Resolution:
The camera offers 4K video quality with an effective resolution of 3840×2160 pixels at 15fps , thanks to a 1/2" 8 Megapixel CMOS sensor. This definition allows you to capture extremely detailed images for advanced professional surveillance .
Optics :
Equipped with a motorized lens with 3x optical zoom , it has a variable focal length from 3.7 mm to 11 mm , F1.5 aperture and a horizontal viewing angle ranging from 112° to 46°. This versatility allows for wide coverage and precise remote focusing.
4K Technology (4K Technology) :
4K technology represents a qualitative leap in video surveillance, offering an image four times more detailed than Full HD (1080p). This reduces the number of cameras needed to cover an area, optimizing project costs.
4 signals on a coaxial cable :
Thanks to HDCVI technology, video, audio, data, and power can be transmitted over a single coaxial cable. Two-way communication support allows for remote camera control and alarm management, simplifying installation and wiring.
Multiple outputs :
The camera supports simultaneous 4K HDCVI and analog CVBS output via two BNC connectors. This makes it compatible with new and existing devices, facilitating maintenance and testing during installation .
Long distance transmission :
HDCVI guarantees stable real-time transmission up to 700 meters over RG59 coaxial cable and up to 300 meters over UTP cable , without loss of video quality. Ideal for large systems where a significant distance between the camera and the recorder is required .
Wide Dynamic Range (WDR) :
With a true 120dB WDR, the camera perfectly handles high-contrast light situations (for example, bright entrances and shadowed areas), ensuring always balanced images, both in bright and dark areas.
Protection :
The rugged aluminum body combined with IP67 (waterproof and dustproof) and IK10 (vandal-proof) certifications make it suitable for outdoor or high-risk environments. Furthermore, it supports dual power supplies (DC 12V/AC 24V) and unstable voltages, with lightning protection up to 4KV.
Detailed diagram with dimensions of the Dahua HAC-HDBW3802E-Z camera

Technical data sheet

Model

HAC-HDBW3802E-Z

Room
Image Sensor 1/2" CMOS
Effective Pixels 3840(H)×2160(V), 8MP
Scanning System Progressive
Electronic Shutter Speed 1/1s~1/100.00s
Min. Illumination

0.01Lux/F1.5(Color), 30IRE,0lux/F1.5(B/W)

S/N Ratio More than 65dB
IR Distance Up to 50m (164 feet)
IR On/Off Control Auto/Manual
IR LEDs 3
Lens
Lens Type Motorized lens / Auto iris
Mount Type Board-in
Focal Length 3.7-11mm
Max. Openings F1.5
Angle of View H: 112°~46°
Focus Control Auto / Manual
PTZ
Pan/Tilt/Rotation Range Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360°
Video
Resolution

8MP (3840×2160)

Frame rate

PAL:3840×2160@12.5fps,2560x1440@25fps;

NTSC:3840×2160@15fps,2560x1440@30fps;

Video Output

1-channel HDCVI 4K video output & 1-channel CVBS video output

Day/Night Auto (ICR) / Manual
OSD Menu Multi-language
BLC Mode BLC / HLC / WDR
WDR 120dB
Gain control AGC
Noise reduction 2D/3D
White balance Auto / Manual
Smart IR Auto / Manual
Certification
Certifications

CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface
Audio Interface 1-channel audio in
Alarm I/O

2/1

Electrical
Power Supply 12V DC ±25%/24V AC ±25%
Power Output DC 12V/Max 4W
Power consumption Max 12.4W
Environmental
Operating Conditions

-30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH

* Start up should be done at above -30°C (-22°F)

Strorage Conditions -30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH
Ingress Protection IP67&IK10
Construction
Casing Aluminum
Dimensions Φ159.1mm×117.9mm (Φ6.26"×4.64")
Net Weight 0.90kg (1.98lb)
Gross Weight

1.20kg (2.65lb)

All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
