TP-Link MC110CS Media Converter: Ethernet-Fiber Connection up to 20 km

TP-Link MC110CS Media Converter: Ethernet-Fiber Connection up to 20 km

nuevo

The TP-Link MC110CS is a reliable media converter designed to convert 10/100Mbps Ethernet signals to single-mode fiber optics, ensuring stable and secure connections up to 20km . Compliant with IEEE 802.3, IEEE 802.3i and IEEE 802.3u standards, it ensures full compatibility with major corporate networks. It integrates a 10/100Mbps RJ45 port and a 100Mbps SC/UPC port, allowing for easy integration into existing infrastructures. Equipped with LEDs for real-time monitoring, it operates at full data forwarding speed and can also be installed on MC1400 chassis, guaranteeing efficiency, low power consumption and CE and FCC certifications.

Technical Data Sheet

referencia : MC100CS

brand : OMADA

EAN: 6935364030407

Manufacturer Object ( [id] => 53 [name] => OMADA [description] =>

Un aspecto clave de OMADA es su capacidad para ofrecer una gestión centralizada. Esto puede hacerse mediante un controlador de hardware dedicado, un controlador de software o el servicio en la nube Omada SDN, que permite la gestión centralizada de las redes. Las soluciones ofrecidas son escalables y flexibles, lo que las hace adecuadas tanto para pequeñas redes corporativas como para grandes despliegues multisede.

OMADA incluye soluciones inalámbricas con puntos de acceso Wi-Fi de alto rendimiento, que garantizan una cobertura fiable y de alta velocidad. Además, ofrece conmutadores gestionados y routers pasarela con funciones avanzadas de gestión del tráfico, seguridad y calidad de servicio (QoS).

La seguridad es otro de los puntos fuertes de las soluciones de OMADA, que incluyen funciones avanzadas como cortafuegos, VPN y control de acceso para proteger las redes corporativas. Además, la plataforma en la nube de OMADA permite la configuración y supervisión remota de las redes, ofreciendo una gran flexibilidad en la gestión de TI.

Para las empresas, OMADA proporciona una solución que puede reducir los costes operativos gracias a una gestión centralizada que simplifica el mantenimiento de la red. Los componentes de hardware de alta calidad garantizan un rendimiento estable y fiable, mientras que las interfaces intuitivas y las herramientas de gestión facilitan la administración de la red incluso al personal no técnico

Los principales productos de OMADA incluyen puntos de acceso para interiores y exteriores con tecnologías avanzadas como Wi-Fi 6, conmutadores gestionados con capacidades de Capa 2 y Capa 3, y dispositivos de seguridad y enrutamiento para la gestión del tráfico de red y la protección frente a amenazas. Las soluciones de OMADA se utilizan habitualmente en oficinas corporativas para gestionar redes internas, en escuelas y universidades para proporcionar conexiones Wi-Fi a estudiantes y personal, y en hoteles para ofrecer una conexión a Internet estable y rápida a los huéspedes.

[short_description] =>

Tp-Link Omada

OMADA es una marca de soluciones de gestión de redes empresariales de TP-Link. El sistema OMADA incluye tanto hardware como software diseñados para centralizar la gestión de redes inalámbricas, conmutación y pasarelas. Este enfoque está diseñado para mejorar el control y la gestión de las infraestructuras de red, especialmente en entornos empresariales.

[id_address] => [date_add] => 2024-06-13 09:45:42 [date_upd] => 2025-08-25 11:30:31 [link_rewrite] => omada [meta_title] => [meta_keywords] => [meta_description] => [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 25 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
BUSQUE INSTALADOR


LIQUIDACION TOTAL ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

MC100CS| FAST ETHERNET MEDIA CONVERTERS, MULTIMODE, SC, 100BASE-FX OMADA TP-LINK


Made Omada

The TP-Link MC110CS is a media converter designed to connect 10/100Mbps Ethernet networks to single-mode fiber optics, ensuring reliable and secure connections up to 20km. Compliant with IEEE 802.3, 802.3i, and 802.3u standards, it ensures maximum compatibility with existing network infrastructures. It integrates a 10/100Mbps RJ45 port and a 100Mbps SC/UPC port, operating at full data forwarding speed and with LED indicators for immediate monitoring. Thanks to its compact size, it can also be installed on MC1400 chassis, maintaining low power consumption and CE and FCC certifications for professional use.

Main specifications:

- 10/100Mbps RJ45 port + SC/UPC multimode fiber

- Transmission distance up to 20 km

- Compatible with IEEE 802.3 / 802.3i / 802.3u standards

- LED for real-time monitoring

- CE and FCC certifications, low power consumption (1.1W)

Further details

Standards Compatibility

It supports IEEE 802.3, IEEE 802.3i and IEEE 802.3u , ensuring full interoperability with major 10/100 Mbps Ethernet networks and ensuring reliable performance over time.
Interfaces
It features a 10/100Mbps RJ45 port for copper connections and a 100Mbps single-mode SC/UPC port, allowing direct and transparent conversion between copper and optical fiber.
Advanced features (Link Fault Passthrough and Far End Fault)
These advanced features allow you to detect and report link faults at both ends of the network, ensuring faster diagnoses and reducing downtime.
Fiber optic connections up to 20–60 km
Using single-mode fiber with a wavelength of 1310nm, the device enables long-range transmissions, ideal for campuses, network backbones and long-distance links.

Technical data sheet

Model MC100CS
MEDIA CONVERTER & MODULE
Standards & Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Basic features Auto-negotiation of Half-Duplex / Full-Duplex transfer mode
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends fiber distance up to 20km
Doors 1 1000M SC/UPC port
1 1000M RJ45 port (Auto MDI/MDIX)
Wavelength 1310nm
Network Media 10BASE-T UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media 100BASE-T UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media 100BASE-FX Multi-mode Fiber
Dimensions (L x W x H) 3.7*2.9*1.1in. (94.5*73.0*27.0mm)
Diet External Power Adapter
Maximum energy consumption 2.4W
LED PWR, Link/Act
Safety & Emissions FCC, CE, RoHS
Package Content Media Converter MC100CS
Power Adapter
Installation Guide
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
