DR3650v-4G | 4G+ CAT6 WI-FI 6 AX3000 GIGABIT ROUTER - TPLINK OMADA


Made Omada

The TP-Link Omada DR3650v-4G is an advanced desktop DSL gateway with 4G+ Cat6 connectivity up to 300 Mbps, ideal for ensuring high speeds, stability, and security in business and professional networks. With AX3000 WiFi 6, VDSL2 35b support up to 350 Mbps, and centralized management via Omada SDN cloud, it offers a scalable and reliable solution for offices and SMBs.

Main specifications:

- WiFi 6 AX3000: up to 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz)

- 4G+ Cat6 connectivity with dual Nano SIM slots for LTE failover

- DSL compatibility (VDSL2/ADSL2+/ADSL2) up to 350 Mbps

- 5 Gigabit RJ45 ports, 3 RJ11 ports, 1 USB 3.0 port

- Advanced VPNs (IPSec, OpenVPN, WireGuard, SSL) for complete security

- Centralized cloud management with Omada SDN

Further details

Wi-Fi 6 AX3000:
Speeds up to 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz, with MU-MIMO and Beamforming technologies for stable and high-performance connections.
4G+ Cat6 :
Up to 300 Mbps with dual Nano SIM slots for LTE failover, ensuring continuous and reliable connection.
RJ11 ports :
3 ports (2× FXS and 1× DSL) compatible with VDSL2 35b up to 350 Mbps for maximum telephone and DSL flexibility.
Nano SIM ports:
2 dedicated slots to ensure redundancy and mobile network stability.
Gigabit RJ45 ports :
5 high-speed ports for secure and high-performance LAN and WAN connections.
Versatile connectivity :
compatibility with DSL, 4G/LTE and WAN Ethernet, with load balancing and advanced VPN (IPSec, OpenVPN, WireGuard, SSL) for data protection.

Technical data sheet

Model DR3650v-4G
SAFETY
Access Control Source/Destination IP Based Access Control
Filtering WEB Group Filtering§
URL Filtering
Web Security§
ARP inspection Sending GARP Packets§
ARP Scanning§
IP-MAC Binding§
Attack defense TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN
HARDWARE FEATURES
Interface 1× Gigabit WAN/LAN Port
4× Gigabit LAN Ports
1× DSL Port
2× FXS Ports
1× USB 3.0 (supports USB LTE dongle and USB Storage)
Dual Nano SIM Slot (4G+ Cat6)
Key Reset Button
Diet 12VDC / 3.3A Power Adapter
Wi-Fi Frequency & Signal Rate 2.4 GHz: 574 Mbps
5 GHz: 2402 Mbps (HE160)
Flash 256 MB NAND
DRAM 512 MB DDR4
Dimensions (L x W x H) 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions are not included)
Antenna Wi-Fi: 3× 5GHz 5dBi & 2.4GHz 3.5dBi dual-band detachable antennas
LTE: 2× 4.0dBi omnidirectional detachable antennas
Mounting type Desktop / Wall / Rack mount (Purchase Rackmount Kit-D226 Separately)
Max Power Consumption Power adapter not included: 28,482 W (Full load + USB)
Power adapter included: 31.42 W (Full load + USB)
PERFORMANCES
GRE Unencrypted: 541.8Mbps
Encrypted: 289.2Mbps
WireGuard VPN 311.6Mbps
Concurrent sessions 150,000
New Sessions / Second 3,800
NAT (Static IP) 937.2 Mbps / 936.1 Mbps
NAT (DHCP) 945.8 Mbps / 940.6 Mbps
NAT (PPPoE) 942.9 Mbps / 942.9Mbps
NAT (L2TP) 837.4 Mbps / 881.5 Mbps
NAT (PPTP) 803.0 Mbps / 910.5 Mbps
IPsec VPN Throughput ESP-SHA1-AES256: 569.9Mbps
ESP-SHA256-AES256: 543.3Mbps
ESP-SHA384-AES256: 549.0Mbps
ESP-SHA512-AES256: 539.3Mbps
OpenVPN 129.3Mbps
L2TP VPN Throughput Unencrypted: 909.4 Mbps
Encrypted: 494.9Mbps
PPTP VPN Throughput Unencrypted: 897.5 Mbps
Encrypted: 190.8 Mbps
SSL VPN Throughput 126.7Mbps
66 Byte Packet forwarding rate 1,453,489 pps / 1,453,488 pps
1,518 Byte Packet forwarding rate 81,274 pps / 91,275 pps
WIRELESS FEATURES
Advanced features Seamless Roaming
Mesh (with EAP that supports Mesh)
OFDMA
Beamforming
Enable/Disable SSID Broadcast
Enable/Disable Wireless Radio
MU-MIMO
Load Balance
Automatic Channel Selection Algorithm
Airtime Fairness
Rate Limit: Based on SSID/Client
Transmit Power Control: Adjust transmit Power on dBm
Multiple SSIDs: 16 total (8 per radio)
Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
Guest Network Support
BASIC FUNCTIONS
WAN Connection Type Static IP
Dynamic IP
PPPoE (supports MRU Configuration)
PPTP
L2TP
MAC clone

Modify WAN Address

DHCP DHCP Server
DHCPv6 PD Server
DHCP Options Customization
DHCP Address Reservation
Multi-net DHCP
Multi-IP Interfaces
IPv6 StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
VLAN 802.1Q VLAN
IPTV IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
ADVANCED FEATURES
Advanced Routing

Static Routing
Policy Routing
RIP*5
OSPF*5

Bandwidth control IP-Based Bandwidth Control
Load balance Intelligent Load Balance
Application Optimized Routing
Link Backup (Timing, Failover)
Online Detection
NAT One-to-One NAT
Multi-Net NAT
Virtual Server
Port Triggering§
NAT-DMZ
FTP/H.323/SIP/IPSec/PPTP ALG
UPnP
Session Limit IP-based Session Limit
VPN
GRE

Only in Standalone Mode

SSL VPN

50 Tunnels

IPsec VPN

100 IPSec VPN Tunnels
LAN-to-LAN, Client-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
IPsec Failover
IKE v1/v2
MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
NAT Traversal (NAT-T)
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)

PPTP VPN PPTP VPN Server
PPTP VPN Client (10)*5
50 Tunnels
PPTP with MPPE Encryption
L2TP VPN L2TP VPN Server
L2TP VPN Client (10)*6
50 Tunnels
L2TP over IPSec
OpenVPN OpenVPN Server
OpenVPN Client (5)*6
55 OpenVPN Tunnels
"Certificate + Account" Mode
Full Mode
WireGuard VPN Yes
Authentication
Web Authentication No Authentication
Simple Password*2
Hotspot(Local User / Voucher* / SMS* / Radius*)
External Radius Sever
External Portal Server*
LDAP
MANAGEMENT
Omada App Yes
Centralized Management

Omada Cloud-Based Controller
Omada Hardware Controller
Omada Software Controller

Cloud Access Yes. Require the use of Omada Cloud-Based Controller.
Service Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
Maintenance Web Management Interface
Remote Management
Export & Import Configuration
Diagnostics (Ping & Traceroute)
NTP Synchronize§
Port Mirroring
CLI (only in Standalone Mode)
Syslog Support
TR-069 (data models of TR-098 and TR181 are supported)
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller.
Management Features Automatic Device Discovery
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration
OTHER
Network Services Enabled by Default Web Server
Manage and configure device through web (HTTP/HTTPS)
Port: 80/443 Protocol: TCP
TDP Server
Device discovery
Port: 20003 Protocol: UDP
VOIP Server
Monitor SIP messages
Port: 5060 Protocol: UDP
DHCP Server
Handle DHCP packets
Port: 67 Protocol: UDP
DNS
Handle DNS packets
Port: 53 Protocol: TCP/UDP
OTHER
Certification CE, RoHS
Package Contents

DR3650v-4G
Power Adapter
Ethernet Cable
Phone Cable
Rubber Feet
SIM Card Eject Pin
Quick Installation Guide

System requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11
MAC OS, NetWare, UNIX or Linux
Environment Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature: -40–70℃ (-40–158℉)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing
