The ES208GP is an 8-port Easy Managed Gigabit switch with PoE+ support on all ports designed for enterprise networks, IP video surveillance systems and professional installations. It integrates 8 RJ45 Gigabit PoE+ ports compliant with the 802.3af/at standard , ensuring power and data connectivity via a single Ethernet cable. Thanks to the total PoE budget of 64W with up to 30W per port , it can efficiently power access points, IP cameras and VoIP phones. It supports centralized cloud management via the Omada SDN platform , with monitoring and configuration via the web or dedicated app. Advanced functions such as VLAN, QoS, IGMP Snooping and automatic loop prevention ensure network stability and security, while the fanless design with metal structure guarantees silent operation and long-lasting reliability. Omada

Technical Data Sheet

referencia : ES208GP

brand : OMADA

EAN: 1210002609708

Manufacturer Object ( [id] => 53 [name] => OMADA [description] =>

Un aspecto clave de OMADA es su capacidad para ofrecer una gestión centralizada. Esto puede hacerse mediante un controlador de hardware dedicado, un controlador de software o el servicio en la nube Omada SDN, que permite la gestión centralizada de las redes. Las soluciones ofrecidas son escalables y flexibles, lo que las hace adecuadas tanto para pequeñas redes corporativas como para grandes despliegues multisede.

OMADA incluye soluciones inalámbricas con puntos de acceso Wi-Fi de alto rendimiento, que garantizan una cobertura fiable y de alta velocidad. Además, ofrece conmutadores gestionados y routers pasarela con funciones avanzadas de gestión del tráfico, seguridad y calidad de servicio (QoS).

La seguridad es otro de los puntos fuertes de las soluciones de OMADA, que incluyen funciones avanzadas como cortafuegos, VPN y control de acceso para proteger las redes corporativas. Además, la plataforma en la nube de OMADA permite la configuración y supervisión remota de las redes, ofreciendo una gran flexibilidad en la gestión de TI.

Para las empresas, OMADA proporciona una solución que puede reducir los costes operativos gracias a una gestión centralizada que simplifica el mantenimiento de la red. Los componentes de hardware de alta calidad garantizan un rendimiento estable y fiable, mientras que las interfaces intuitivas y las herramientas de gestión facilitan la administración de la red incluso al personal no técnico

Los principales productos de OMADA incluyen puntos de acceso para interiores y exteriores con tecnologías avanzadas como Wi-Fi 6, conmutadores gestionados con capacidades de Capa 2 y Capa 3, y dispositivos de seguridad y enrutamiento para la gestión del tráfico de red y la protección frente a amenazas. Las soluciones de OMADA se utilizan habitualmente en oficinas corporativas para gestionar redes internas, en escuelas y universidades para proporcionar conexiones Wi-Fi a estudiantes y personal, y en hoteles para ofrecer una conexión a Internet estable y rápida a los huéspedes.

[short_description] =>

Tp-Link Omada

OMADA es una marca de soluciones de gestión de redes empresariales de TP-Link. El sistema OMADA incluye tanto hardware como software diseñados para centralizar la gestión de redes inalámbricas, conmutación y pasarelas. Este enfoque está diseñado para mejorar el control y la gestión de las infraestructuras de red, especialmente en entornos empresariales.

[id_address] => [date_add] => 2024-06-13 09:45:42 [date_upd] => 2025-08-25 11:30:31 [link_rewrite] => omada [meta_title] => [meta_keywords] => [meta_description] => [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 25 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
BUSQUE INSTALADOR


ES208GP | 8-PORT EASY MANAGED GIGABIT SWITCH WITH 8 POE+ PORTS

Made Omada

The TP-Link Omada ES208GP is an 8-port Easy Managed Gigabit switch with full PoE+ support designed for enterprise networks, IP video surveillance systems, and professional infrastructures. It features 8 RJ45 Gigabit 802.3af/at PoE+ ports that allow you to directly power devices such as access points, IP cameras, and VoIP phones via a single Ethernet cable. Thanks to a total PoE budget of 64W with up to 30W per port , it ensures stable power and high performance. It supports centralized cloud management via the Omada SDN platform , with configuration and monitoring via the web or a dedicated app. Advanced features such as VLAN, QoS, IGMP Snooping, and automatic loop prevention improve network security and stability, while the fanless design with metal body ensures quiet operation and long-lasting reliability.

Main specifications:

- 8 Gigabit RJ45 PoE+ 802.3af/at ports for high-speed network connections and power over Ethernet

- 64W total PoE budget with up to 30W per port to power access points, IP cameras and network devices

- Centralized cloud management via Omada SDN platform with monitoring and configuration via web or app

- Advanced network features such as VLAN, QoS, Port Isolation, IGMP Snooping and Cable Test for network performance and security

- Extended PoE support up to 250 m and Remote Camera Reboot function ideal for professional video surveillance systems

- Fanless design with metal frame and desktop or wall-mount installation for quiet operation and reliability.

Further details

8 High-Performance Gigabit PoE+ Ports :
The switch integrates 8 RJ45 Gigabit ports compatible with the 802.3af/at PoE+ standard , designed to ensure network connections up to 1 Gbps and power devices such as access points, IP cameras and VoIP phones directly via Ethernet cable.
High-efficiency 64W PoE power budget:
With a total PoE budget of 64W with up to 30W per port , the switch allows you to power multiple network devices simultaneously , simplifying your infrastructure and reducing the need for separate power supplies.
Easy to use with plug-and-play setup:
Designed for quick and intuitive installation , it supports plug-and-play for immediate connectivity and simple configuration of advanced features, making network management accessible even in complex professional environments.
Centralized Omada SDN Cloud Management:
With centralized cloud management via the Omada platform , you can monitor, configure and control your entire network infrastructure from a single web interface or app , with multi-site management and efficient remote control.
PoE up to 250 m for video surveillance installations:
With Extended PoE mode up to 250 m (820 ft), the switch allows you to power and connect devices even over long distances , making it ideal for IP video surveillance systems and network installations over large areas .

Technical data sheet

Model ES208GP
HARDWARE FEATURES
Interface 8× 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+)
1× 10/100/1000Mbps RJ45 Port
1× Gigabit SFP/RJ45 Combo Port
Auto-Negotiation/Auto MDI/MDIX
Number of fans Fanless
Installation Desktop/Wall Mount
Physical security lock
Diet DC Power Adapter (Output: 53.5V DC / 1.31A)
PoE ports Standard: 802.3af PoE and 802.3at PoE+ compliant
PoE Ports: 8 ports
PoE Budget: 64W available for all PoE+ ports, 30W max per port
Remote Camera Reboot†
Up to 820ft (250m) PoE transmission distance**
Dimensions (L x W x H) 6.2 × 4.0 × 1.0 in (158 × 100.7 × 25.4 mm)
Surge Protection Service port: ±6 kV
PERFORMANCES
Switching capacity 16 Gbps
Packet Forwarding Rate 14.904 Mpps
ARP Table 8 K
Buffer (packets) 4 Mbit
Jumbo frame 15 KB
SOFTWARE FEATURES
QoS (Quality of Service) Port-based/802.1p/DSCP QoS
8 priority queues
Priority Schedule Mode
SP (Strict Priority)
WRR (Weighted Round Robin)
Queue Weight Config
Bandwidth Control
Port/Flow-based Rating Limiting
Storm Control
Multiple Control Modes(kbps/ratio)
Broadcast/Multicast/Unknown-Unicast Control
L2 functionality

Static Link Aggregation
Loop Prevention / Loopback Detection
Flow Control
802.3x Flow Control
Mirroring
Port Mirroring
One-to-One
Many-to-One
Ingress/Egress/Both
Port Statistics
Port Mirror Status
Traffic Statistics
802.1ab LLDP

L2 Multicast

IGMP Snooping
IGMP v1/v2/v3 Snooping
Fast Leave

VLAN VLAN MTU
Port-Based VLAN
802.1Q VLAN Tag
Max 32 VLAN Groups
4K VID
Transmission method Store-And-Forward
MANAGEMENT
Omada App

Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Centralized Management Omada Cloud-Based Controller
Omada Hardware Controller
Omada Software Controller
Cloud Access Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller.
Management Features Web-based GUI
DHCP Client
Cable Diagnostics
Automatic Device Discovery†
Batch Configuration†
Batch Firmware Upgrading†
Unified Configuration†
OTHER
Certification CE, FCC, RoHS
Package Contents

ES208GP
Power Adapter
Power Cord
Mounting Brackets
Installation Guide
Rubber Feet
Screws

Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40 °C to 70 ℃ (-40 ℉ to 158 ℉)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing
