TP-Link Omada MC110CS Media Converter 10/100 Mbps Single-Mode Fiber 20 km

TP-Link Omada MC110CS Media Converter 10/100 Mbps Single-Mode Fiber 20 km

 
nuevo

MC110CS - The TP-Link Omada is a Fast Ethernet media converter designed to convert 10/100BASE-T copper connections to 100BASE-FX single-mode fiber optic connections, ideal for extending wired networks over long distances. It integrates 2 SC/UPC 100 Mbps ports and 1 RJ45 10/100 Mbps port , supporting transmissions of up to 20 km on single-mode fiber with a wavelength of 1310 nm . It offers full-speed forwarding, LED indicators for monitoring network activity and is compatible with the TP-Link MC1400 chassis . Its compact design, maximum consumption of 1.1 W and 9 V/0.6 A power supply make it an efficient solution for professional network infrastructures. Omada

Technical Data Sheet

referencia : MC110CS

brand : OMADA

EAN: 1210002611022

Manufacturer Object ( [id] => 53 [name] => OMADA [description] =>

Un aspecto clave de OMADA es su capacidad para ofrecer una gestión centralizada. Esto puede hacerse mediante un controlador de hardware dedicado, un controlador de software o el servicio en la nube Omada SDN, que permite la gestión centralizada de las redes. Las soluciones ofrecidas son escalables y flexibles, lo que las hace adecuadas tanto para pequeñas redes corporativas como para grandes despliegues multisede.

OMADA incluye soluciones inalámbricas con puntos de acceso Wi-Fi de alto rendimiento, que garantizan una cobertura fiable y de alta velocidad. Además, ofrece conmutadores gestionados y routers pasarela con funciones avanzadas de gestión del tráfico, seguridad y calidad de servicio (QoS).

La seguridad es otro de los puntos fuertes de las soluciones de OMADA, que incluyen funciones avanzadas como cortafuegos, VPN y control de acceso para proteger las redes corporativas. Además, la plataforma en la nube de OMADA permite la configuración y supervisión remota de las redes, ofreciendo una gran flexibilidad en la gestión de TI.

Para las empresas, OMADA proporciona una solución que puede reducir los costes operativos gracias a una gestión centralizada que simplifica el mantenimiento de la red. Los componentes de hardware de alta calidad garantizan un rendimiento estable y fiable, mientras que las interfaces intuitivas y las herramientas de gestión facilitan la administración de la red incluso al personal no técnico

Los principales productos de OMADA incluyen puntos de acceso para interiores y exteriores con tecnologías avanzadas como Wi-Fi 6, conmutadores gestionados con capacidades de Capa 2 y Capa 3, y dispositivos de seguridad y enrutamiento para la gestión del tráfico de red y la protección frente a amenazas. Las soluciones de OMADA se utilizan habitualmente en oficinas corporativas para gestionar redes internas, en escuelas y universidades para proporcionar conexiones Wi-Fi a estudiantes y personal, y en hoteles para ofrecer una conexión a Internet estable y rápida a los huéspedes.

[short_description] =>

Tp-Link Omada

OMADA es una marca de soluciones de gestión de redes empresariales de TP-Link. El sistema OMADA incluye tanto hardware como software diseñados para centralizar la gestión de redes inalámbricas, conmutación y pasarelas. Este enfoque está diseñado para mejorar el control y la gestión de las infraestructuras de red, especialmente en entornos empresariales.

[id_address] => [date_add] => 2024-06-13 09:45:42 [date_upd] => 2025-08-25 11:30:31 [link_rewrite] => omada [meta_title] => [meta_keywords] => [meta_description] => [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 25 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
BUSQUE INSTALADOR


MC110CS| FAST ETHERNET MEDIA CONVERTERS, MULTIMODE, SC, 100BASE-FX


Made Omada

The TP-Link Omada MC110CS is a Fast Ethernet media converter designed to convert 10/100BASE-T copper links to 100BASE-FX single-mode fiber optic connections, allowing you to extend your network up to 20 km . It integrates 2 100 Mbps SC/UPC ports and 1 10/100 Mbps RJ45 port , operates at 1310 nm and supports full-speed forwarding. LED indicators make it easy to monitor network activity, while compatibility with the MC1400 chassis simplifies installation in professional environments. A maximum power consumption of 1.1 W and a 9 V/0.6 A power supply contribute to efficient and reliable operation.

Main specifications:

  • Conversion: 10/100BASE-T ↔ 100BASE-FX
  • Ports: 2× SC/UPC + 1× RJ45
  • Speed: up to 100 Mbps
  • Fiber: single-mode
  • Distance: up to 20 km
  • Wavelength: 1310 nm
  • Monitoring: LED indicators
  • Compatibility: MC1400 chassis

Further details

✅ Standards Compatibility:

The TP-Link Omada MC110CS complies with IEEE 802.3, IEEE 802.3i and IEEE 802.3u standards, ensuring compatibility with Ethernet and Fast Ethernet networks based on copper and fiber optic links.
✅ Interfaces:
It integrates 2 SC/UPC 100 Mbps ports dedicated to optical fiber and 1 RJ45 10/100 Mbps port for Ethernet connection on twisted pair cable, facilitating the conversion between copper and fiber network.
✅ Advanced features:
It supports full wire-speed forwarding , features LED indicators for easy network activity monitoring, and is compatible with the MC1400 chassis for streamlined deployment in professional infrastructures.
✅ Fiber optic connections:
It uses single-mode optical fiber with a 100 Mbps SC/UPC interface, supporting links up to 20 km and operating at a wavelength of 1310 nm , ideal for extending Fast Ethernet networks over long distances.

Technical data sheet

Model MC110CS
MEDIA CONVERTER & MODULE
Standards & Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Basic features Auto-negotiation of Half-Duplex / Full-Duplex transfer mode
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends fiber distance up to 20km
Doors 1 1000M SC/UPC port
1 1000M RJ45 port (Auto MDI/MDIX)
Wavelength 1310nm
Network Media 10BASE-T UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media 100BASE-T UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media 100BASE-FX Single-mode Fiber
Dimensions (L x W x H) 3.7*2.9*1.1in. (94.5*73.0*27.0mm)
Diet External Power Adapter
Maximum energy consumption 2.4W
LED PWR, Link/Act
Safety & Emissions FCC, CE, RoHS
Package Content Media Converter MC110CS
Power Adapter
Installation Guide
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
