DS-PDD15AM-EG2 Triple Technology PIR Microwave Alarm Sensor 15m Internal Antimasking - Hikvision

DS-PDD15AM-EG2 Triple Technology PIR Microwave Alarm Sensor 15m Internal Antimasking - Hikvision

 
-35% nuevo

DS-PDT15AM-EG2 - is a triple-technology wired detector designed to ensure high standards of security in indoor environments, thanks to the combination of a PIR sensor and a 24GHz microwave for precise and reliable detection. It offers coverage of up to 15 meters with an 85.9° angle , ensuring effective monitoring of large areas. It integrates advanced functions such as anti-masking, anti-cloaking and anti-blocking , ideal for preventing tampering and sabotage attempts. The presence of digital temperature compensation and automatic sensitivity improves performance in any environmental conditions. The compact design and non-interference technology allow for quick and efficient installation. - Hikvision

Technical Data Sheet

referencia : DS-PDT15AM-EG2

brand : Hikvision

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Desde el año de su nacimiento, su prestigio ha crecido tanto que en 2015 se convertirá en la primera realidad mundial en materia de seguridad.

A partir de 2016 Hikvision expande su mercado convirtiéndose en Proveedor de Soluciones Totales para todo el mercado de la seguridad. Así entra en el mundo de la detección de intrusos y luego se acerca a las nuevas tecnologías e inteligencia al servicio de la humanidad ocupándose de IO, Visión Artificial, Robótica y Sistemas Automovilísticos. De líder en seguridad, Hikvision se convierte con compromiso, pasión y competencia en una empresa de alta tecnología con una visión 4.0, siempre apuntando alto.

Por lo tanto, Setik se siente honrado de ser un distribuidor de Hikvision. Como siempre, ofreceremos productos de última generación y el apoyo técnico y comercial adecuado.

[short_description] =>

Videosorveglianza Hikvision

Hikvision fue fundada en 2001 con el objetivo de crear y desarrollar soluciones profesionales completas de videovigilancia, convirtiéndose rápidamente en un líder en el mundo de la seguridad.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Seguridad hikvision [meta_keywords] => Seguridad hikvision [meta_description] => Hikvision fue fundada en 2001 y pronto se convirtió en líder del mundo de la videovigilancia. Descubra ahora los productos del catálogo! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 25 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
BUSQUE INSTALADOR

DS-PDT15AM-EG2 | WIRED DUAL-TECH AM DETECTOR

Hikvision

The Hikvision DS-PDD15AM-EG2 is a triple-technology wired detector designed for advanced security systems, combining a PIR sensor and a 24GHz microwave for precise and reliable detection. It guarantees coverage of up to 15 meters with an 85.9° angle , ideal for indoor environments such as homes and shops. It integrates advanced security functions such as anti-masking, anti-cloaking and anti-blocking , preventing sabotage attempts and false alarms. The presence of automatic sensitivity and digital temperature compensation ensures consistent performance in any environmental conditions. The compact design and non-interference technology allow for simple, quick and efficient installation.

Main specifications:

- Triple PIR + 24GHz Microwave technology for precise and reliable detection

- 15m / 85.9° coverage ideal for indoor environments

- Anti-masking, anti-cloaking and anti-blocking functions for maximum security

- Automatic sensitivity and digital temperature compensation for operational stability

- Non-interfering technology for quick installations even back-to-back

- Compact wired design with low power consumption and high reliability

Further details

✅ Detection Performance:
The detector uses a combination of PIR sensor and 24GHz microwave , offering coverage of up to 15 meters with an 85.9° angle and 52 detection zones , ensuring high accuracy and reduction of false alarms also thanks to automatic sensitivity and digital temperature compensation .
✅ Features :
It integrates advanced features such as anti-masking, anti-cloaking and anti-blocking , as well as digital processing and sealed optics , ensuring maximum protection against tampering and operational reliability in indoor environments.
✅ Interface:
Equipped with a normally closed (NC) alarm output and dedicated LED indicators (PIR, Microwave and Alarm) , it allows immediate monitoring of the device status and easy integration into security systems.
✅ Transmission :
Fully wired transmission system, designed to offer stable and continuous connection , ideal for professional installations where reliability and signal security are fundamental.
✅ Power supply:
It supports 9–16 VDC power supply with a typical value of 12V , featuring low power consumption (up to 25mA) , ensuring efficiency and constant operation over time.

Technical data sheet

DS-PDT15AM-EG2
General
Operation Temperature -10 °C to 55 °C (14 °F to 131 °F)
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Operation Humidity 10% to 90%
Dimensions (WxHxD) 65.7 mm (2.59") × 103.8 mm (4.09") × 45.5 mm (1. 79")
Weight 100g
Mounting Height 1.8 m to 2.4 m
Mounting Method Wall
Application Scenario Indoor
Bracket Optional wall & ceiling accessory
Detection Performance
Detection Method Passive Infrared; Microwave
Detection Range 15 m
Detection Angle 85.9°
Detection Zones 52
Detectable Speed 0.3～2m/s
Sensitivity Auto;Low
White Light Filter 6500lux
Microwave Frequency 24GHz(24.15～24.25GHz)
Digital Temperature Compensation Support
Creep Zone Protection Support
Features
Digital Processing Support
Sealed Optics Support
Tamper Protection Front
Anti-masking Support
Anti-cloaking Support
Anti-blocking Support

Interfaces
Alarm Output Normally Closed
LED Indicator Green(PIR), Orange(Microwave), Blue(Alarm)
Transmission
Transmission Method Wired
Electrical Characteristics
Power Supply 9 to 16 VDC
Typical Voltage 12 VDC
Power Consumption Maximum current：25mA@12VDC Quiescent current：17mA@12VDC
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
