The ProLite TE8612MIS‑B4AG is an 86″ 4K UHD touch display designed to enhance collaboration in business and education environments. The Zero Airgap screen eliminates parallax, while the 40-point PureTouch-IR touchscreen ensures extreme precision. Equipped with Android 14 and the iiWare 13E interface, it is Google EDLA Certified , supports iiyama Share/EShare wireless sharing and allows remote management via iiyama DMS , making it a flexible tool for hybrid spaces, meeting rooms and modern classrooms.
BUSQUE INSTALADOR
LIQUIDACION TOTAL ×
CLEARANCE SALE!
Take advantage of our must-see outing offers.
Discover the promo >>
TE8612MIS‑B4AG – 86″ 4K UHD Touch Display for Smart Workstations
The 86″ 4K UHD ProLite TE8612MIS‑B4AG offers a premium interactive surface with advanced touch and a Zero Airgap display that eliminates parallax, ideal for education and business environments. Featuring Android 14 (iiWare) and Google EDLA certification, it provides direct access to the Play Store and Google/Microsoft apps. Remote management is possible via iiyama DMS, while wireless sharing is easy with iiyama Share/EShare. With 40-point PureTouch‑IR, writing or drawing is responsive and natural, with clear audio from the built-in 32W speakers and USB‑C connectivity for video, touch and single-cable charging. It supports Multi-Window, Standalone or OPS modes, ensuring flexibility and productivity in any situation.
Main features:
- 86" 4K (3840×2160) display with high brightness VA panel (400 cd/m²)
- PureTouch‑IR 40pt touchscreen with zero parallax and ±1.5mm accuracy
- Android 14 + iiWare system , Google EDLA Certified for apps and user profiles
- iiyama DMS: for remote management and centralized updates
- iiyama Share / EShare: for wireless sharing from 9 devices
- 32W stereo audio with integrated front speakers
- 65W USB-C for video/audio, touch, and power delivery via one cable
- Multi-Window mode for visual multitasking on a large screen
- Standalone or OPS slot operation, in continuous use 24/7
Further details
The iiyama ProLite TE8612MIS-B4AG 86" 4K UHD interactive display is the perfect solution for educational and corporate environments. Equipped with Android system with iiWare 13E interface and Google EDLA certification, it guarantees flexibility, security and compatibility with the main apps. The innovative 40-point PureTouch-IR touch technology ensures a natural writing experience, while wireless sharing and remote management make the device complete, efficient and easy to integrate into any workspace.
Official access to Google Play Store, Google apps and Microsoft 365.
Centralized management of remote displays, with secure and rapid updates.
Allows sharing of content from multiple devices without cables (up to 9 users).
Highly precise 40-point touchscreen with anti-reflective glass and zero parallax.
It works independently or with OPS module for versatility of use.
One cable for power, data, audio/video and touch control.
Technical data sheet
| Model | TE8612MIS-B4AG |
| DISPLAY CHARACTERISTICS | |
| Design | Thin bezel |
| Diagonal | 85.6", 217.4cm |
| Panel | IPS DLED |
| Touch Glass | Anti-Glare Coated Glass, Zero-Gap Air Bonding |
| Native resolution | 3840 x 2160 (8.3 MegaPixels 4K UHD) |
| Aspect ratio | 16:9 |
| Panel brightness | 400 cd/m² |
| Light transmittance | 92% |
| Static contrast | 1200:1 |
| Dynamic contrast | 4000:1 |
| Response time (GTG) | 6.5ms |
| Viewing areas | horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
| Colour support | 1.07B 8bit+FRC |
| Horizontal Sync | 30 - 135kHz |
| Viewable area W x H | 1895 x 1066mm, 74.6 x 42" |
| Bezel width (sides, top, bottom) | 16.5mm, 16.5mm, 30mm |
| Pixel pitch | 0.493mm |
| Bezel color and finish | black, matte |
| TOUCH | |
| Touch technology | PureTouch IR |
| Touchpoints | 40, 5pt writing (HID, only with supported OS) |
| Touch accuracy | +- 1.5mm |
| Touch method | stylus, finger, glove (Passive pen, Opaque objects) |
| Touch interface | USB |
| Supported operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| INTERFACES/CONNECTORS/CONTROLS | |
| Analog signal input | VGA x1 (max. 1920x1080 @60Hz) |
| Signal input | HDMI x2 (2.0, max. 3840x2160 @60Hz, YUV444 (HDMI x1 compatible ARC/ CEC) DisplayPort x1 (max. 3840x2160 @60Hz) USB-C x2 (3.2 (Gen 1, 5Gbit), 3840x2160 @60Hz - RGB444 - (Touch, 1x Front 65W PD, 1x Back 15W PD) |
| Audio input | Mini-jack x1 |
| Monitor control input | RS-232c x1 (DSUB 9pin) RJ45 (LAN) x1 (LAN Control) IR x1 |
| Digital signal output | HDMI x1 |
| Audio output | S/PDIF (Optical) x1 Mini-jack x1 (3.5mm) Speakers 2 x 16W (Front) |
| Monitor control output | OPS Slot x1 |
| HDCP | HDMI 1: 2.1, USB-C: 2.2 |
| USB ports | x5 (media playback / peripherals / storage – front side: 2x USB 3.2 (Gen 1, 5Gbit), 1x USB-C 3.2 (Gen 1, 5Gbit, 65W PD), side: 2x USB 3.2 (Gen 1, 5Gbit), back: 1x USB-C 2.0 (Gen 1, 5Gbit, 15W PD)) |
| RJ45 (LAN) | x2 (Auto switch for PC & Android, 1000MB) |
| FEATURES | |
| Integrated software | iiWare 13E (Android 14 OS) featuring Google EDLA, iiyama DMS, Note, File Manager, Cloud Drives, WPS Office, iiyama Share and EShare for wireless connection with Windows/iOS/Android devices |
| WiFi | yes (WiFi 6 Module OWM002 - Dual WiFi Bandwidth: 2.4GHz/5GHz, WiFi Standard: IEEE 802.11 a/b/g/n/ac/ax, Bluetooth Support: 2.1+EDR/ 3.0/ 4.x/ 5.0) |
| Adaptive Sync support | CPU: RK3576 Octa-core A72*4 + A53*4, GPU: Mali G52 MC3, RAM: 8GB, ROM: 128GB |
| Extra | WiFi 6 Module (OWM002), Slot for optional OPS Slot PC, 4x Touch pen |
| Kiosk mode | yes |
| Max. non-stop operating time | 24/7 |
| Media playback | yes |
| Glass thickness | 3mm |
| Glass hardness | 7H |
| Housing (bezel) | metal |
| OSD key lock | yes |
| GENERAL | |
| OSD languages | EN, DE, FR, ES, IT, CN, RU, JP, CZ, NL, PL, SV, FI, DA, NB |
| Control buttons | Power, Power Indicator, Remote Sensor, Light Sensor |
| User controls | general settings (input, volume, backlight), audio settings (volume, bass, treble, balance, sound mode, mute), screen settings (aspect ratio, pixel shift), display settings (brightness, contrast, hue, sharpness, display mode, color temp.), adjust settings (H-position, V-position, clock, phase, auto), settings (wireless & networks, personal, input & output, application, system) |
| Blue light reducer | yes |
| Plug&Play | DDC2B |
| Warranty | 5 years (for details and eligible countries please check the Warranty section of our website) |
| MECHANICAL | |
| Orientation | landscape |
| Fanless design | yes |
| VESA mounting | 800 x 600mm |
| Operating temperature range | 0°C - 40°C |
| Storage temperature range | - 20°C - 60°C |
| MTBF | 50,000 hours (excluding backlight) |
| ACCESSORIES INCLUDED | |
| Cables | Power, USB, HDMI |
| Touch pen | x4 (Dual function tips) |
| Guides | quick start guide, safety guide |
| Other | WiFi 6 Module (OWM002), Mounting bracket for NUC, Mounting bracket for webcam |
| Remote control | yes (batteries included) |
| POWER MANAGEMENT | |
| Power supply unit | internal |
| Power supply | AC 100 - 240V, 50/60Hz |
| Power usage | 181W typical, 0.5W stand by, 0.3W off mode |
| SUSTAINABILITY | |
| Regulations | CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, EPA 8.0 (RoHS) |
| REACH SVHC | above 0.1%: Lead |
| DIMENSION/WEIGHT | |
| Product dimensions W x H x D | 1957 x 1098 x 98mm |
| Box dimensions W x H x D | 2110 x 1291 x 225mm |
| Weight (without box) | 48.5kg |
| Weight (with box) | 64.5kg |
