TF1734MC-B8X – IIYAMA PROLITE 17" IPS MONITOR - 10 TOUCH PCAP TOUCH - IP65
The iiyama ProLite TF1734MC-B8X is a 17-inch open-frame touchscreen monitor designed for professional integration into interactive kiosks, retail systems, and self-service terminals. 10-point PCAP capacitive technology ensures precise and responsive control, while the edge-to-edge glass design with anti-fingerprint coating ensures elegance, durability, and ease of cleaning. IP65 front protection offers high resistance to dust and water, while the 6mm Through-Glass Touch function allows use even behind protective surfaces. The device also features a 1280x1024 resolution , HDMI, DisplayPort, and VGA inputs, and support for landscape, portrait, and face-up installations.
Main features:
- 17" Open Frame display with 1280 x 1024 resolution and up to 350 cd/m² brightness for clear and detailed images
- 10-point PCAP capacitive touch technology with high precision and support for use with fingers, stylus and latex gloves
- Touch Through-Glass function up to 6 mm to ensure touch functionality even behind protective glass
- IP65 front protection against dust and water jets, ideal for high-traffic public and commercial environments
- Edge-to-edge glass with anti-fingerprint and scratch resistance for greater durability
- Palm Rejection to avoid accidental touches and improve the user experience
- Full connectivity with HDMI, DisplayPort and VGA inputs for easy integration into existing systems
- Versatile installation in landscape, portrait and face-up modes, perfect for kiosks, lockers, information points and custom applications
Further details
Up to 6mm Through-Glass Touch keeps the touchscreen responsive even behind protective glass, making it ideal for kiosks, lockers, self-service terminals and high-wear public installations.
The IP65 front protection protects the monitor from dust and water jets , offering stable performance in the most demanding commercial, public and professional environments.
The monitor supports landscape, portrait and face-up installations, adapting to walls, counters, kiosks and custom interactive systems.
Optional Open Frame brackets facilitate secure integration of the monitor into dedicated frames, panels and custom solutions.
Technical data sheet
| Model | TF1734MC-B8X |
| DISPLAY CHARACTERISTICS | |
| Design | Edge to edge glass, Open Frame |
| Diagonal | 17", 43cm |
| Panel | TN |
| Native resolution | 1280 x 1024 @75Hz (1.3 megapixels) |
| Aspect ratio | 5:4 |
| Panel Brightness | 350 cd/m² |
| Brightness | 300 cd/m² with touch |
| Light transmittance | 85% |
| Static contrast | 1000:1 with touch |
| Response time (BTB) | 5ms |
| Viewing zone | horizontal/vertical: 170°/160°, right/left: 85°/85°, up/down: 80°/80° |
| Supports color | 16.7 million |
| Horizontal Sync | 31 - 80kHz |
| Viewable area W x H | 338 x 270mm, 13.3 x 10.6" |
| Pixel pitch | 0.264mm |
| Bezel color and finish | black, matte |
| TOUCH | |
| Touch technology | projective capacitive |
| Touch points | 10 |
| Touch accuracy | +- 2mm |
| Touch method | stylus, finger, glove (latex) |
| Touch interface | USB |
| Through-Glass | 6mm |
| Palm rejection | Yes |
| INTERFACES / CONNECTORS / CONTROLS | |
| Analog signal input | VGA x1 |
| Digital signal input | HDMI x1 DisplayPort x1 |
| FEATURES | |
| Extra | anti-fingerprint coating, touch through glass |
| Glass thickness | 3mm |
| 60950 Ball drop test | Yes |
| Water and dust protection | IP65 (front) |
| OSD key lock | Yes |
| GENERAL | |
| OSD languages | EN, DE, FR, ES, IT, PT, RU, JP, NL, PL |
| Control buttons | Menu, scroll up / ECO, scroll down / volume, select / input, power |
| User controls | picture (contrast, brightness, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (time out, position, H-position, V-position, Touch switch), option (reset, language, source select, display mode, factory) |
| Plug & Play | DDC2B |
| MECHANICAL | |
| Orientation | landscape, portrait, face-up |
| VESA mounting | 100 x 100mm |
| ACCESSORIES INCLUDED | |
| Cables | power (1.8m), USB (1.8m), HDMI (1.8m), DP (1.8m) |
| Guides | quick start guide, safety guide |
| Other | AC adapter |
| Cable cover | Yes |
| POWER MANAGEMENT | |
| Power Supply Unit | external |
| Power Supply | DC 12 V |
| Power Usage | 13W typical, 1.5W stand by, 0.3W off mode |
| SUSTAINABILITY | |
| Regulations | CE, EAC, VCCI-B, RoHS support, ErP, WEEE, cULus, REACH, UKCA |
| Energy efficiency class (Regulation (EU) 2017/1369) | AND |
| REACH SVHC | above 0.1%: Lead, Lead monoxide, Boric acid |
| DIMENSIONS & WEIGHT | |
| Product dimensions W x H x D | 369 x 307 x 47.5mm |
| Box dimensions W x H x D | 387 x 145 x 455mm |
| Weight (without box) | 3.6kg |
| Weight (with box) | 5.2kg |
