Superior MotionProtect Plus G3 Fiber Wired IR Motion Detector with Microwave Sensor - Black

Superior MotionProtect Plus G3 Fiber Wired IR Motion Detector with Microwave Sensor - Black

ANUNCIOS

117716.09.BL1 # 117716 | Ajax Superior MotionProtect Plus G3 Fiber Wired IR motion detector with an additional K-band microwave sensor and an anti-masking system, for indoor use. Motion detection distance 15 meters. Connection with fiber line up to 2000 m. Pet Immune, Tamper Alarm, Smart Detect . Remote configuration and management . Temperature compensation. Grade 3 certified. IP50 protection, Black color .

Technical Data Sheet

referencia : 117716.09.BL1

brand : Ajax Systems

EAN: 4823114070761

Manufacturer Object ( [id] => 31 [name] => Ajax Systems [description] =>

Establecido en 2011, Ajax Systemconstruye sistemas inalámbricos de incendio y alarma con la tecnología inalámbrica JEWELLER que le permite monitorear de manera segura todos los dispositivos de red conectados. Ajax System ofrece soluciones para el hogar, la oficina o las actividades comerciales, gestionables a través de la App, siempre actualizadas y compatibles con los sistemas iOS y Android. Los sistemas de alarma de Ajax System son fáciles de instalar, de hecho sólo toma 15 segundos conectar la unidad de control a los sensores. Además, pueden integrarse con las cámaras de vigilancia, tienen un margen de error casi nulo y, en caso de peligro, en menos de 150 milisegundos envían una notificación (sms, push o call).

[short_description] =>

Ajax SystemsAjax Systems


Los sistemas de alarma Ajax system utilizan la última tecnología inalámbrica que hace que todos los productos sean fiables y estén siempre conectados. Además de su excelente rendimiento, los sistemas de alarma Ajax se distinguen por su diseño moderno y elegante.

[id_address] => [date_add] => 2019-01-15 15:51:16 [date_upd] => 2025-06-11 12:47:32 [link_rewrite] => ajax-systems [meta_title] => Sistemas de incendio y alarma de última generación - Ajax System [meta_keywords] => sistemi allarme ajax,sicurezza ajax,allarmi ajax,ajax security system,ajax security,ajax system [meta_description] => I sistemi allarme Ajax system sono dispositivi wireless affidabili e innovativi, non producono falsi allarmi e si installano in 15 secondi. Scoprili su Setik.biz! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 25 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
BUSQUE INSTALADOR


LIQUIDACION TOTAL ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

117716.09.BL1 | WIRED IR MOTION DETECTOR WITH AN ADDITIONAL K-BAND MICROWAVE SENSOR AND ANTI-MASKING SYSTEM

Ajax

The Ajax Superior MotionProtect G3 Fiber Black, 117716.09.BL1, is a professional-grade wired PIR motion detector designed to ensure maximum security in residential and commercial environments. Equipped with anti-masking technology and two-way encrypted fiber communication , it offers constant and reliable protection against intrusion, sabotage, or manipulation attempts.

Main specifications:

- Motion detection up to 15 m with a 90° angle

- Adjustable anti-masking system and SmartDetect algorithm

- Encrypted fiber communication up to 2,000 m

- Continuous self-diagnosis and real-time fault reporting

- Anti-tamper protection with three tampers

- Quick installation via QR code or fiber optic line

- Compatible with Ajax Superior hubs and modules

- Compact design in black with IP30 rating

Further details

Advanced communication on fiber optic lines:
The MotionProtect G3 Fibre uses a two-way wired fibre connection with data encryption and device authentication , ensuring stable and secure communication up to 2,000 metres . Thanks to Ajax technology, every sensor status is monitored in real time, minimising delays and interference. Installation via QR code or fibre line scanning allows for quick setup and remote management directly from the mobile or desktop app, always ensuring a secure and reliable connection even in the most complex installations.
Accurate and intelligent detection :
Equipped with a highly sensitive PIR sensor , the device detects motion up to 15 meters with a coverage angle of 90° horizontally and 72° vertically , ensuring complete protection of the rooms. The SmartDetect algorithm recognizes and filters false alarms, while the grade 3 anti-masking system detects attempts to cover, paint or obstruct the lens. The sensor is able to distinguish even slow or fast movements, ensuring maximum precision thanks to the infrared technology with proprietary mirror and the 24 GHz operating frequency.
Professional-grade sabotage protection :
Designed for complete security, the MotionProtect G3 Fibra integrates three tamper protections that detect unauthorized opening, short circuits, or tampering attempts. EN 50131 Grade 3 certification guarantees reliable performance even in high-security contexts, such as commercial or industrial environments. The sensor immediately notifies you of any faults or connection losses , ensuring constant monitoring and a timely response to any suspicious events.
Stable and efficient power supply:
The detector is powered directly from the Fiber line (7–30 V⎓) with a low power consumption of 90 mW , ensuring continuous operation even in the event of voltage fluctuations. Power can be managed via the Ajax Superior hub or the LineSupply Fiber module , ensuring reliability and autonomy over time. The low-power design not only increases the system's lifespan but also optimizes its overall efficiency, making it ideal for professional and long-term installations.

Technical data sheet

Model: Alarm 117716.09.BL1
General settings
Compliance with standards


EN 50131 (Big 3)

PD 6662:2017

INCERT (in progress)

SSF (in progress)

Limitations

Compatibility Hubs
Hybrid Hub (2G)

Hybrid Hub (4G)
Communication with a hub
Fiber communication technology

Communication range
up to 2000 m
up to 6550 ft
with U/UTP cat. 5 4x2x0.51cable

Motion detection
Sensitive elements 1 x PIR sensor
1 x K-band microwawe sensor
Operation frequency

24 GHz

Motion detection distance from 0.5 to 15 m
from 1.6 to 49 ft
Motion detection angle

Horizontal — 90°
Vertical — 72°

Motion detection speed

From 0.1 to 4 m/s
From 0.3 to 13.1 ft/s

Power supply
Detector power supply

7-30V DC
up to 90 mW

Enclosure
Color Black
Dimensions 120 × 62 × 52 mm
4.72" x 2.44" x 2.05"
Weight

TBC

INSTALLATION
Operating temperature range From −10°C to +40°C
From 14°F to 104°F
Operating humidity

Up to 75%

Protection class

IP30

Installation height 2.4 m
7.9 ft
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
