60831.174.BL1 | WIRELESS GRID-POWERED HEAT AND CARBON MONOXIDE FIRE DETECTOR

Ajax

The Ajax FireProtect 2 AC (Heat/CO) Jeweler, 60831.174.BL1, black, is a professional, mains-powered fire detector designed to provide continuous, highly reliable protection against dangerous overheating and carbon monoxide in residential and commercial environments. Thanks to the combination of advanced sensors and Ajax technology, the device ensures rapid detection, immediate notifications, and full operation even during power outages. Its elegant black design, continuous self-diagnosis, and integration with advanced security systems make it ideal for highly reliable, permanent installations.

Main specifications:

- Dual high-precision A1R heat sensors for rapid detection of critical temperature increases

- Chemical carbon monoxide sensor with operating life of up to 10 years

- 110–240 V mains power with sealed battery backup

- Two-way Jeweler radio communication with a range of up to 1700 m

- Intelligent interconnected fire alarms with primary and fallback modes

- Built-in 85 dB siren, status LED and continuous self-diagnosis

Further details

✅ Jeweler Communication:
The device uses two-way, encrypted Jeweller radio technology, which ensures stable and secure communication with the Ajax hub, with a range of up to 1700 meters in open terrain and continuous signal supervision for immediate transmission of fire alarms.
✅ Sensor type:
It integrates a combined detection system consisting of a dual-spectrum optical smoke sensor and dual heat sensors, offering complete protection against slow and fast-developing fires in a single professional solution.
✅ Carbon Monoxide (CO) Detection:
The highly reliable CO chemical sensor constantly monitors carbon monoxide concentration and generates an alarm at 50 ppm, before the first symptoms of poisoning appear, with a sensor operating life of up to 10 years.
✅ Dangerous temperature detection:
The A1R dual heat sensors constantly monitor the environment and activate the alarm when the temperature rises by 10°C within a minute or exceeds 64°C, ensuring timely warning even in the absence of smoke.
✅ Additional features :
It supports intelligent interconnected fire alarms with primary and fallback modes, automation scenarios, real-time notifications via the Ajax app, built-in 85 dB siren , LED status indicators and alarm sending to monitoring stations.
✅ Anti-sabotage protection :
It integrates anti-tampering and anti-removal systems that detect unauthorized attempts to open or detach from the support, immediately sending a signal to the system to maintain a high level of security of the system.
✅ Power supply:
It operates on 110–240 V AC power and a sealed backup battery , ensuring operational continuity even in the event of a power outage and ensuring reliable operation for the entire life of the device.

Technical data sheet

60831.174.BL1
Communication
Jeweler communication technology Proprietary wireless communication technology to transmit commands, alarms, and events.
Key features:
  • Two-way communication.
  • Advanced anti-sabotage.
  • Block encryption featuring a dynamic key.
  • Instant notifications.
  • Remote configuration via the Ajax apps.
Radio frequency bands 866.0 - 866.5 MHz
868.0 - 868.6 MHz
868.7 - 869.2 MHz
905.0 - 926.5 MHz
915.85 - 926.5 MHz
921.0 - 922.0 MHz
Depence on the sales reaction
Maximum effective radiated power (ERP) up to 20 mW
Automatic power control to reduce power consumption and radio interference.
Radio signal modulation GFSK
Radio signal range Up to 1,700 m
up to 5,500 ft
Between the detector and a hub (or radio signal range extender) in an open space.
Encrypted radio communication All the data stored and transmitted are protected by block encryption featuring a dynamic key.
Frequency hopping To prevent radio interference and jamming
Sensitive elements heat sensor
CO (carbon monoxide) sensor
Dangerous temperature detection
Sensitive element according to the requirements for Class A1 heat detectors
Requirements of EN 54-5 and BS 5446-2 standards
High temperature alarm at temperatures above 64 °C
at temperatures above 147 °F
Temperature spike alarm when the temperature rises more than 10°C 50°F in 1 minute or less
Carbon monoxide (CO) detection
Sensitive element chemical CO sensor
Alarm if accumulated dose of CO is exceeded more than 50 ppm (0.005%) — no more than in 90 minutes
more than 100 ppm (0.01%) — no more than in 40 minutes
more than 300 ppm (0.03%) — no more than in 3 minutes
CO concentration of 400 ppm (0.04%) within 3 hours can be life-threatening. The detector stops notifying about the dangerous level of carbon monoxide when the concentration drops to 50 ppm (0.005%) within one minute.
Sensor life 10 years
After 10 years of operation, the detector must be replaced with a new one.
Additional features
Built-in siren 85 dB volume at a distance of 3 meters
85 dB volume at a distance of 9 ft
Sound notification of alarms. Active until the reason for triggering is eliminated or until the user disables the notification.
Interconnected fire detectors alarm via primary interconnection
If one of the fire detectors in the system detects a threat, it sends an alarm to the hub. Within 20 seconds, the hub initiates an interconnected alarm and sends data to Ajax apps.
via fallback interconnection1
At the same time with notifying the hub, the initiating detector sends an alarm directly to other detectors. All connected detectors activate the buzzer within a minute. It will work even in the worst-case scenario of losing connection with the hub.
1 Fallback interconnected alarm is available only for FireProtect 2 detectors with firmware version 5.59.2.ХХ or later. Devices that support the fallback interconnected alarm are marked on the package with a “Fallback interconnect supported” label.
LED indication green is a power indication
A LED indicator on the device enclosure lights up once every 56 seconds. The indication meets the requirements of EN 50291
yellow is an indication of malfunctions
A LED indicator on the device enclosure lights up when malfunctions are detected. For example, in the case of discharged batteries, contamination of the smoke chamber, or end of the service life
red is an indication of fire alarms
A LED indicator on the device enclosure lights up when the detector registers a fire alarm
Button on the front panel of the detector In normal mode, when pressed, it starts the smoke chamber test. In the event of an alarm or malfunction, pressing turns off the detector sound notification.
External power supply 110–240 V~, 50/60 Hz
The phase and neutral cables from the external power supply should be connected to the WAGO terminals on SmartBracket mounting panel. To remove the detector from SmartBracket, there is no need to disconnect the power cables.
Recommendations The device is designed only for indoor installation
SmartBracket mounting panel allows adjusting the position of the detector after installation.
Sabotage protection
Tampering alarm Alerts of attempts to detach the detector from the surface or remove the mounting panel.
Protection against spoofing device authentication
Detection of communication failure within 15 minutes
The time to detect communication loss depends on the settings for the number of undelivered data packages (specified in the Jeweler or Jeweller/Fibra settings). The polling interval is fixed at 300 seconds.
Power supply
Main 110–240 V~, 50/60 Hz
Up to 2W of mains power consumption.
Backup 1 non-replaceable lithium battery
Allows the detector to operate autonomously without the main power source.
Enclosure
Color Black
Dimension 122 × 122 × 54 mm
4.80″ × 4.80″ × 2.13″
Weight 318 g
11.22 oz
Operating temperature range from 0 °C to +50 °C
from 32°F to 122°F
Operating humidity up to 80%
Complete set FireProtect 2 AC (Heat/Smoke) Jeweller
SmartBracket mounting panel
WAGO 221 3-conductor terminal — 2 pcs.
(pre-installed in SmartBracket)
Installation kit
Quick start guide
Warranty 24 months
