INSTALLER BUNDLE PROMO: DAHUA ASC22 ACCESS BUNDLE

Made by Dahua

The Dahua ASC22 Access Control range is designed to offer comprehensive, scalable, and professional solutions for access management in corporate, public, and residential environments. This selection includes models to suit every project requirement, with devices varying in the number of gates supported, reader type, and cabinet or single-card configuration. The ASC2202B-D and ASC2202B-S models are compact two-gate controllers for dual and single readers, respectively, ideal for simple yet reliable installations. For those requiring greater protection and ease of installation, the ASC2202C-D and ASC2202C-S versions offer the same functionality but integrated into a metal cabinet.

The options are further expanded with the ASC2204B-S model, which allows the management of four gates with a single reader, while the ASC2204C-D and ASC2204C-S allow the control of four gates with double or single readers, enclosed in a robust cabinet for greater physical protection and wiring organization. Finally, the ASC2208C-S controller represents the widest solution in the range, capable of managing up to eight gates with a single reader, designed for complex and structured systems that require high performance and long-term reliability.

Thanks to their modularity and compatibility with Dahua systems, ASC22 controllers ensure seamless integration with biometric readers, RFID readers, keypads, and centralized management software, offering advanced security, access tracking, and installation flexibility. Ideal for installers, system integrators, and industry professionals, the ASC22 range represents a strategic choice for those seeking modern, secure, and customizable access control.

✅ Promotion valid until the end of September

Product details

ASC2202B-D – 2-gate controller with double reader

  • Access controller for two gates and double reader

  • Supports cards, passwords, fingerprints
  • Interface to RS485 or Wiegand readers
  • Alarm functions: door timer, intrusion alarm, tamper, duress
  • Multi-port management via Smart PSS application
  • Watch Dog function to prevent device crashes
  • Supports up to 128 groups of preset schedules
  • Power supply DC 12V or PoE

ASC2202B-S – 2-gate controller, single reader

  • Access controller for two gates and single reader

    Supports cards, passwords, fingerprints

    Interface to RS485 or Wiegand readers

    Up to 100,000 Users, 3,000 Fingerprints, 100,000 Cards, 500,000 Records

    Support card reader tamper alarm, intrusion alarm, door sensor timeout alarm, duress alarm, illegal card threshold exceeded alarm, and incorrect password alarm

    Watch Dog function to prevent device crashes

    Supports up to 128 groups of preset schedules

    Power supply DC 12V or PoE

ASC2202C-D - 2-gate controller with double reader and cabinet

  • Access controller for two gates, Double gate control

    Supports cards, passwords, fingerprints Interface to RS485 or Wiegand readers

    4x Wiegand ports, 5x RS485 ports

    Up to 100,000 users and 500,000 events, Up to 100,000 access cards, 3,000 fingerprints

    Alarm: 6 inputs and 4 outputs: Anti-Passback, Tamper, Duress, Door Unlock Timeout, Intrusion, Illegal Card Exceeding Threshold, Duress Fingerprint

    Lock Control: 2 channels, Tamper

  • WatchDog function to prevent device crashes
  • Power supply 100-240 V AC

ASC2202C-S – 2-gate controller, single reader with cabinet

  • Access controller for two gates, Double gate control

  • Supports cards, passwords, fingerprints Interface to RS485 or Wiegand readers
  • 2x Wiegand ports, 3x RS485 ports
  • Up to 100,000 users and 500,000 events, Up to 100,000 access cards, 3,000 fingerprints
  • Alarm: 2 inputs and 2 outputs: Anti-Passback, Tamper, Duress, Door Unlock Timeout, Intrusion, Illegal Card Exceeding Threshold, Duress Fingerprint
  • Lock Control: 2 channels, Tamper, Buzzer
  • WatchDog function to prevent device crashes
  • Power supply 100-240 V AC

ASC2204B-S – 4-gate controller with single reader

  • Access controller with four gates and a single reader

  • Supports cards, passwords, fingerprints
  • Interface to RS485 or Wiegand readers
  • Up to 100,000 users and 500,000 events
  • Alarm functions: door timer, intrusion alarm, tamper, duress
  • WatchDog function to prevent device shutdown
  • Power supply DC 12V or PoE

ASC2204C-D – 4-gate controller with double reader and cabinet

  • Access controller for two gates, Control up to 4 (four) gates

  • Supports cards, passwords, fingerprints, remote control Interface to RS485 or Wiegand readers
  • 8x Wiegand ports, 9x RS485 ports
  • Up to 100,000 users and 500,000 events, Up to 100,000 access cards, 3,000 fingerprints
  • Alarm: 8 inputs and 8 outputs: Anti-Passback, Tamper, Duress, Door Unlock Timeout, Intrusion, Illegal Card Exceeding Threshold, Duress Fingerprint
  • Lock Control: 4 channels, Tamper, Buzzer

  • WatchDog function to prevent device crashes
  • Power supply 100-240 V AC

ASC2204C-S – 4-gate controller, single reader with cabinet

  • Access controller for two gates, Control up to 4 (four) gates

    Supports cards, passwords, fingerprints, remote control Interface to RS485 or Wiegand readers

    4x Wiegand ports, 5x RS485 ports

    Up to 100,000 users and 500,000 events, Up to 100,000 access cards, 3,000 fingerprints

    Alarm: 6 inputs and 4 outputs: Anti-Passback, Tamper, Duress, Door Unlock Timeout, Intrusion, Illegal Card Exceeding Threshold, Duress Fingerprint

    Lock Control: 4 channels, Tamper, Buzzer

    WatchDog function to prevent device crashes

    Power supply 100-240 V AC

ASC2208C-S – 8-gate controller with single reader and cabinet

  • Access controller with eight gates and a single reader

    Supports cards, passwords, fingerprints

    Interface to RS485 or Wiegand readers

    Users 100,000, Fingerprints 3,000, Cards 100,000, Records 500,000

    Alarm functions: Door timeout, Intrusion, Duress, Tampering

    WatchDog function to prevent device shutdown

    Power supply 100-240 V AC

Technical data sheet


✅ Bundle Composition

Product CodeDescriptionList Price (VAT excl.)
ASC2202B-D Controller 2 gates double reader €325.00
ASC2202B-S 2-gate controller, single reader €259.00
ASC2202C-D 2-gate controller with double reader and cabinet €697.00
ASC2202C-S 2-gate controller, single reader with cabinet €665.00
ASC2204B-S 4-gate controller, single reader €335.00
ASC2204C-D 4-gate controller with double reader and cabinet €916.00
ASC2204C-S 4-gate controller, single reader with cabinet €728.00
ASC2208C-S 8-gate controller, single reader with cabinet €916.00
Total List Price 4841.00


All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
