MC100CM| FAST ETHERNET MEDIA CONVERTERS, MULTIMODE, SC, 100BASE-FX OMADA TP-LINK


Made Omada

The TP-Link MC100CM is a media converter designed to connect copper and multimode fiber networks, ensuring stability and speeds of up to 100Mbps. Supporting IEEE 802.3/802.3u standards, it integrates a 10/100Mbps RJ45 port and a SC/UPC multimode fiber port with transmission ranges of up to 2km, ensuring reliable and continuous data transfer. Compact and with LED indicators for immediate monitoring, it offers low power consumption and is CE and FCC certified, making it a safe and efficient solution for business and professional networks.

Main specifications:

- 10/100Mbps RJ45 port + SC/UPC multimode fiber

- Transmission distance up to 2 km

- Compatible with IEEE 802.3 / 802.3u standards

- LED indicators for network monitoring

- Low consumption (1.19W) and CE, FCC certifications

Further details

Standards Compatibility

It supports IEEE 802.3, IEEE 802.3i, and IEEE 802.3u , ensuring full interoperability with major Ethernet protocols. This compliance guarantees stability, speed, and compatibility with existing network infrastructures.
Interfaces
It features a 10/100Mbps RJ45 port for copper connection and a 100Mbps multimode SC/UPC port , allowing transparent conversion between fiber and traditional cable.
Advanced features (Link Fault Passthrough and Far End Fault)
These technologies enable real-time detection and reporting of faults at both ends of the connection, reducing downtime and simplifying network maintenance.
Fiber optic connections up to 2 km
Multimode fiber support with a wavelength of 1310 nm enables reliable transmissions up to 2 kilometers , ideal for internal connections in companies, campuses or professional environments that require stability and wide coverage.

Technical data sheet

Model MC100CM
MEDIA CONVERTER & MODULE
Standards & Protocols IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Basic features Auto-negotiation of Half-Duplex / Full-Duplex transfer mode
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Extends fiber distance up to 2km
Doors 1 1000M SC/UPC port
1 1000M RJ45 port (Auto MDI/MDIX)
Wavelength 1310nm
Network Media 10BASE-T UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media 100BASE-T UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media 100BASE-FX Multi-mode Fiber
Dimensions (L x W x H) 3.7*2.9*1.1in. (94.5*73.0*27.0mm)
Diet External Power Adapter
Maximum energy consumption 2.4W
LED PWR, Link/Act
Safety & Emissions FCC, CE, RoHS
Package Content Media Converter MC100CM
Power Adapter
Installation Guide
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
