The TP-Link MC100CM is a media converter ideal for connecting copper and fiber optic networks, ensuring stability and high performance. It supports 10/100Mbps speeds with an RJ45 interface and a multimode SC port, offering transmission distances of up to 2 km over fiber. Compact and easy to integrate into the MC1400 chassis, it ensures reliability thanks to LED indicators for network monitoring. With low power consumption and CE and FCC certifications, it is perfect for companies seeking a secure, scalable, and efficient connection in professional environments.
TOTALER AUSVERKAUF ×
CLEARANCE SALE!
Take advantage of our must-see outing offers.
Discover the promo >>
MC100CM| FAST ETHERNET MEDIA CONVERTERS, MULTIMODE, SC, 100BASE-FX OMADA TP-LINK

The TP-Link MC100CM is a media converter designed to connect copper and multimode fiber networks, ensuring stability and speeds of up to 100Mbps. Supporting IEEE 802.3/802.3u standards, it integrates a 10/100Mbps RJ45 port and a SC/UPC multimode fiber port with transmission ranges of up to 2km, ensuring reliable and continuous data transfer. Compact and with LED indicators for immediate monitoring, it offers low power consumption and is CE and FCC certified, making it a safe and efficient solution for business and professional networks.
Main specifications:
- 10/100Mbps RJ45 port + SC/UPC multimode fiber
- Transmission distance up to 2 km
- Compatible with IEEE 802.3 / 802.3u standards
- LED indicators for network monitoring
- Low consumption (1.19W) and CE, FCC certifications
Further details
✅ Standards Compatibility
It supports IEEE 802.3, IEEE 802.3i, and IEEE 802.3u , ensuring full interoperability with major Ethernet protocols. This compliance guarantees stability, speed, and compatibility with existing network infrastructures.Technical data sheet
Model | MC100CM |
MEDIA CONVERTER & MODULE | |
Standards & Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
Basic features | Auto-negotiation of Half-Duplex / Full-Duplex transfer mode Full Duplex Flow Control (IEEE 802.3x) Half Duplex Flow Control (Backpressure) Extends fiber distance up to 2km |
Doors | 1 1000M SC/UPC port 1 1000M RJ45 port (Auto MDI/MDIX) |
Wavelength | 1310nm |
Network Media 10BASE-T | UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
Network Media 100BASE-T | UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
Network Media 100BASE-FX | Multi-mode Fiber |
Dimensions (L x W x H) | 3.7*2.9*1.1in. (94.5*73.0*27.0mm) |
Diet | External Power Adapter |
Maximum energy consumption | 2.4W |
LED | PWR, Link/Act |
Safety & Emissions | FCC, CE, RoHS |
Package Content | Media Converter MC100CM Power Adapter Installation Guide |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
