DIGITAL SIGNAGE - INDUSTRIAL DISPLAY 24/7 - LCD - 32 INCH - VERTICAL - ANDROID 8.1 - DAHUA - LDH32-WAI200K

LDH32-WAI200K


MAIN FEATURES:

  • Digital Industrial Billboard - Dahua - LDH32-WAI200K
  • LCD Backlight
  • 24/7
  • 32-inch built-in display
  • Resolution 1080 × 1920
  • Format 9:16
  • 8-bit color, 16.7 million colors
  • Contrast 1,200:1
  • Brightness: 2500 cd/m²
  • Response time: 6ms
  • Suitable for vertical use
  • Viewing angle: 178/178°
  • RAM 2GB
  • ROM 16GB
  • Android 8.1 operating system
  • Integrated 2x5W Stereo Speakers
  • Inputs: RJ45 ×1, USB ×2, TF card Slot ×1, HDMI ×1, 3.5mm Audio In×1
  • Mounting bracket, power cable and remote control
  • Power supply: AC100-240V, 50/60Hz
  • Power supply unit: internal
  • Operating temperature: 0 °C to +40 °C
  • Relative humidity: 10%~85%
  • Dimensions: 433mm × 739mm × 85.5mm
  • Net weight: 19Kg

Technical data sheet

Model LDH32-WAI200K
LCD Panel
Panel Dimensions 32 inches
Backlight LED
LCD Technology IPS
Aspect Ratio 9:16
Brightness 2500 cd/m² (typ.)
Contrast IPS 1200:1(typ.)
Display Colors 8 bit, 16.7M colors
Resolution 1080 (H) × 1920 (V)
Viewing Angle 178° (H); 178° (V)
Response Time 6 ms (typ.)
Surface Treatment Haze 1%
Built-in System
Operating System Android 8.1
CPU 4 cores A17, 1.6 GHz
RAM 2 GB
ROM 16 GB
Video Decoding 2-ch H.264 1080p@25fps; 4-ch H.265 1080p@25fps; 4-ch H.265 1080p@30fps; 2-ch H.264 1080p@25fps; 2-ch H.265 1080p@30fps; The decoding capacity statistics are based on tests with a single video file.
Function
Audio Compression MPEG-3, WMA, WAV
Video Compression MPEG-4, H.264 AVC/MVC, H.265 HEVC
Video Format mp4, avi, mov, mkv, wmv
DevicePorts
Network Port 1 × RJ–45 10/100/1000 Mbps self-adaptive Ethernet port
Wi-Fi Optional (External Wi-Fi module)
Bluetooth No
Data Transmission Ports 2 × USB 2.0 ports (type A)
1 × TF card slot, up to 128GB
Video Input 1 × HDMI 1.4 (1080P @60Hz)
Video Output No
Audio Port 1 × 3.5mm Mic jack
IR Receiver Yes
Speaker
Built-in Speaker 2 × 5W
General
Power Supply 100–240 VAC, 50/60 Hz
Power Consumption ≤125W
Standby Power Consumption ≤0.5W
Operating Temperature 0 °C to +40 °C (+32 °F to +104 °F)
Storage Temperature –20 °C to +60 °C (-4 °F to +140 °F)
Operating Humidity 10%–85% (RH), non-condensing
Storage Humidity 10%-90% (RH)
Product Material Metal casing
Casing Color (Frame/Rear) Black
Product Dimensions 433 mm × 739 mm × 85.5 mm (17.05" × 29.09" × 3.37”) (without wall mount bracket)
Packaging Dimensions 1,070 mm × 670 mm × 236 mm (42.13" × 26.38" × 9.29")
Net Weight 19kg (41.88lb)
Gross Weight 22kg (48.50lb)
Installation Installation
Display Mode Portrait
Wall Mounting Hole Position 300mm × 260mm
Accessories Ceiling mount bracket, power cord, legal and regulatory information, remote control, screw
Certification
Certification EC; ERP

Further details

LDH32-WAI200K dimensions

Download

Download the English Brochure
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
