58455.148.WH1 | WIRELESS TOUCH SCREEN KEYBOARD THAT SUPPORTS SMARTPHONE, PASS, TAGS, AND CODES AUTHENTICATION

Ajax

The Ajax KeyPad TouchScreen Jeweller, 58455.148.WH1, white is a 5" touch keypad designed for intuitive and advanced control of security systems, combining contactless authentication, management via smartphone and codes , along with an advanced graphical interface that guarantees immediate use and operational precision. Jeweller & Wings communication ensures encrypted radio connections up to 1,700 m, while sabotage protection with tamper and communication loss detection safeguards the system from tampering attempts. Powered by AA batteries for up to 1.5 years and compatible with external power supply, the keypad offers continuous reliability and easy installation via SmartBracket .

Main specifications:

- 5" IPS touch display with intuitive interface and updated event logs

- Advanced authentication: Pass/Tag, BLE smartphone and codes

- Jeweller & Wings communication with encryption and regular polling

- Tamper protection and spoofing prevention

- Integrated emergency functions: panic, fire and auxiliary alert

- AA battery power for up to 1.5 years with external power option

Further details

✅ Jeweler Communication:
Jeweller radio technology ensures secure and stable communication between the keyboard and the hub up to 1,700 m in open space, using advanced encryption and regular polling to constantly monitor device status, ensuring fast, reliable and interference-resistant system control.
✅ Wings Communication:
Wings communication integrates a dedicated channel for rapid data transmission, improving event synchronization and real-time notifications. This technology ensures that critical information, such as status changes or alarms, reaches the central system immediately with maximum accuracy and operational continuity.
✅ Screen:
The 5" capacitive IPS display offers a bright and intuitive interface, with high resolution (480 × 854 px) that allows a clear view of system status, event logs and notifications. Automatic backlight adjustment ensures optimal readability in any environment, improving the user experience and management speed.
✅ Main features :
The device supports authentication via Pass/Tag, Bluetooth Low Energy, codes, and smartphones, allowing for quick, multi-level access. It includes group management, quick controls for automatic scenarios, audible and LED indications for doors, delays, and alarms, as well as auto-locking and malfunction notifications, ensuring comprehensive and intelligent security management.
✅ Anti-sabotage protection:
The KeyPad TouchScreen Jeweler features a tamper system that immediately detects any attempt to disassemble or open the device, with additional protections such as anti-spoofing authentication and hub communication loss detection. This level of security prevents fraudulent access and protects the integrity of the entire system.
✅ Power supply:
The device is powered by six pre-installed AA batteries with up to 1.5 years of battery life, ensuring continuous, wireless operation. An external power supply option is also available to act as a backup and allow for over-the-air firmware updates, ensuring consistent performance even under heavy use or environmental changes.

Technical data sheet

58455.148.WH1
Communication
Jeweler communication technology Proprietary wireless communication technology to transmit commands, alarms, and events.
Key features:
  • Two-way communication.
  • Advanced anti-sabotage.
  • Block encryption featuring a dynamic key.
  • Instant notifications.
  • Remote configuration via the Ajax apps.
Radio frequency bands 866.0 - 866.5 MHz
868.0 - 868.6 MHz
868.7 - 869.2 MHz
905.0 - 926.5 MHz
915.85 - 926.5 MHz
921.0 - 922.0 MHz
Depence on the sales reaction
Maximum effective radiated power (ERP) up to 20 mW
Automatic power control to reduce power consumption and radio interference.
Radio signal modulation GFSK
Radio signal range Up to 1,700 m
up to 5,600 ft
Between the detector and a hub (or radio signal range extender) in an open space.
Encrypted radio communication All the data stored and transmitted are protected by block encryption featuring a dynamic key.
Frequency hopping Radio communication uses frequency hopping to prevent interception and jamming.
Wings communication technology Proprietary wireless communication technology for transmitting the list of the groups, rooms and detectors to form the list of malfunctions.
Key features:
  • Two-way communication.
  • Advanced anti-sabotage.
  • Block encryption featuring a dynamic key.
  • Reloading the data packages in case of transmission errors
Radio frequency bands 866.0 - 866.6 MHz
Radio signal range Up to 1,700 m
up to 5,600 ft
Between the detector and a hub (or radio signal range extender) in an open space.
Encrypted radio communication All the data stored and transmitted are protected by block encryption featuring a dynamic key.
Frequency hopping Radio communication uses frequency hopping to prevent interception and jamming.
Display
Diagonal 5"
Matrix type IPS
Resolution 480 × 854 px
Sensor capacitive
Brightness settings
  • automatic
  • manual
If Auto Adjust is enabled, the display brightness depends on the light conditions. This saves battery power.
Backlight lifetime 30,000 hours
Guaranteed lifetime backlight when the Always Active Display toggle is enabled. It can be adjusted in Ajax apps and activates only when external power is connected.
User interface
  • dark
  • light
Key features
Panic buttons
  • panic
  • fire
  • auxiliary help
Sending an alarm or calling for help from the separate keypad tab.
Control
  • codes
  • Pass cards
  • Tag key fobs
  • smartphone (Bluetooth)
Contactless access DESFire® EV1, EV2
ISO14443-A (13.56 MHz)
Access codes up to 200 personal codes
One code for each user. The number of personal access codes depends on the hub model
1 keypad code
One code per KeyPad
Duress codes up to 200 personal codes
One code for each user. The number of personal access codes depends on the hub model
1 keypad code
One code per KeyPad
Codes for unregistered people up to 99 personal codes
For people who are not registered in the system. The number of such codes depends on the hub model
Arming without entering a code The enabled feature allows the user to arm the system without entering a code or presenting the access device.
Group management Changing the security mode of the groups to which the user has access from the keypad's display.
Scenarios management A separate keypad tab contains up to 6 buttons, and each one can control one automation device or a group of devices.
Indication of malfunctions and security mode
  • display
  • logo
  • sound indication
If enabled, the logo lights up red continuously or when the system or group is armed. KeyPad TouchScreen indication is shown on the display only when it is active. Built-in buzzer notifies about alarms, door openings and entry/exit delays.
Fire alarm muting Turns off the fire detectors alarm, including the interconnected alarm.
User pre-authorization When the feature is enabled, viewing the current system status and control screen is unavailable. For access, the user must pre-authorize: enter a code or present a personal access device to the keypad.
Contactless authorization with a smartphone A smartphone with the installed Ajax app and Bluetooth Low Energy (BLE) support can be used instead of Tag or Pass to authorize a user. BLE is a radio protocol with low power consumption. The keypad supports Android and iOS smartphones with BLE 4.2 and higher.
Auto screen wakeup The keypad wakes up automatically when approaching it. The approaching distance can be adjusted in the app.
Remote firmware update When a new firmware is available, an admin or PRO with the rights to configure the system can run the update in Ajax apps. The keypad must be connected to an external power supply to update the firmware.
ACE Type type B
Recommendations The device is designed for indoor use only. Please note that the keypad must be connected to an external power supply to update the firmware and keep the screen always active.
Sabotage protection
Unauthorized access auto-lock The keypad locks if an incorrect code is entered or unverified access devices are used more than 3 times in a row within 1 minute. The lock time is adjusted by PRO or user with admin rights in the Ajax app.
Tamper alarm Notifications on attempts to detach the device from the surface or remove it from the mounting panel.
Holding screw To secure the keypad on SmartBracket.
Protection against spoofing device authentication
Communication loss detection after 36 s
Detection time depends on the Jeweler or Jeweller/Fibra settings.
Power Supply
Battery 6 × AAA
Pre-installed.
Type Type C
Calculated battery life up to 1.5 years
With default settings and up to 4 interactions with a keypad per day.
Keypad's operating voltage range 10.5–14 V⎓, up to 0.4 A
The batteries serve as a backup when the external power supply is connected.
Keypad's nominal operating voltage 12 V⎓
Quiescent device's current consumption at nominal voltage 46 mA
Maximum device's current consumption at nominal voltage 1.5 mA
Full capacity 2,650 mAh
Low battery voltage 6.6 V⎓
Low battery recovery voltage 8.1 V⎓
End-of-life battery voltage 4.92 V⎓
Device is switched off.
End-of-life battery capacity 350 mAh
Enclosure
Color White
Dimension 172 × 82 × 26 mm
6.77″ × 3.23″ × 1.02″
Weight 329 g
11.61 oz
Operating temperature range from −10 °C to +40 °C
from 14 °F to 104 °F
Operating humidity up to 75%
Complete set KeyPad TouchScreen Jeweler
SmartBracket mounting panel
6 × ААА battery (pre-installed)
Installation kit
Quick start guide
Warranty 24 months
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
