38097.06.WH1 #38097| Ajax CombiProtect Jeweller bianco è un avanzato sensore wireless che unisce rilevazione di movimento PIR e analisi di rottura vetri tramite microfono, garantendo sicurezza affidabile in ogni ambiente. Grazie all’algoritmo SmartDetect e all’immunità agli animali, evita i falsi allarmi mantenendo una copertura fino a 12 m con angolo di 88,5°. La tecnologia DualTone per la rottura vetri assicura precisione fino a 9 m, filtrando rumori come abbaio di cani o traffico. La comunicazione Jeweller offre portata fino a 1.200 m, con crittografia e autenticazione anti-spoofing. Facile da installare tramite QR, garantisce fino a 5 anni di autonomia con batteria preinstallata. Ajax
Riferimento: 38097.06.WH1
Marca: Ajax Systems
EAN: 4823114014956
Disponibilità: 30
FUORI TUTTO ×
FUORI TUTTO!
Approfitta della imperdibile offerte del nostro outlet
Scopri la promo >>
38097.06.WH1 | RILEVATORE DI MOVIMENTO E ROTTURA VETRO IR WIRELESS CON MICROFONO

Il Ajax CombiProtect Jeweller, 38097.06.WH1, bianco è un sensore professionale che combina rilevazione di movimento PIR e analisi della rottura vetri, garantendo una protezione completa per ambienti domestici e professionali. Grazie all’algoritmo SmartDetect e al filtro DualTone, assicura massima precisione evitando falsi allarmi, mentre la tecnologia radio Jeweller offre comunicazione criptata fino a 1.200 m. L’installazione tramite QR code e la batteria con autonomia fino a 5 anni garantiscono una gestione rapida e affidabile nel tempo.
Specifiche principali:
- Rilevazione movimento fino a 12 m con angolo 88,5°
- Rilevazione rottura vetri fino a 9 m con angolo 180°
- Tecnologia Jeweller con portata fino a 1.200 m e crittografia avanzata
- Immunità animali fino a 20 kg / 50 cm
- Autonomia fino a 5 anni con batteria CR123A preinstallata
- Installazione rapida con QR code e gestione da app
Ulteriori dettagli
Scheda tecnica
| 38097.06.WH1 | |
| Communication | |
| Jeweller communication technology | Proprietary wireless communication technology to transmit commands, alarms, and events. Key features:
|
| Radio frequency bands | 866.0 - 866.5 MHz 868.0 - 868.6 MHz 868.7 - 869.2 MHz 905.0 - 926.5 MHz 915.85 - 926.5 MHz 921.0 - 922.0 MHz Depence on the sales reagion |
| Maximum effective radiated power (ERP) | up to 20 mW Automatic power control to reduce power consumption and radio interference. |
| Radio signal modulation | GFSK |
| Radio signal range | Up to 1,200 m up to 3,900 ft Between the detector and a hub (or radio signal range extender) in an open space. |
| Encrypted radio communication | All the data stored and transmitted are protected by block encryption featuring a dynamic key. |
| Frequency hopping | Radio communication uses frequency hopping to prevent interception and jamming |
| Detection | |
| Sensitive element | PIR sensor |
| Motion detection distance | up to 12 m up to 39 ft When installed at the height of 2.4 m. When installed at the height of 7.9 ft. |
| Motion detection angles | horizontal: 88.5° |
| Motion detection speed | from 0.3 to 2 m/s from 1 to 6.6 ft/s The direction of the detector lens should be perpendicular to an alleged intrusion path into the facility. |
| Sensitivity | 3 levels Adjusted by PRO or user with admin rights in the Ajax app. |
| Pet immunity | weight: up to 20 kg weight: up to 44 lb height: up to 50 cm height: up to 1.6 ft |
| False alarm prevention | SmartDetect Software algorithm |
| Temperature compensation | Effective motion detection at temperatures from −10°C to +40°C. from 14°F to 104°F. |
| Recommendations | It is recommended to install the detector at a height of 2.4 m. It is recommended to install the detector at a height of 7.9 ft. The device is designed for indoor use only. |
| Glass break detection | |
| Sensitive elements | electret microphone |
| Glass break detection distance | from 0.3 up to 9 m from 1 up to 30 ft |
| Glass break detection angles | horizontal: 180° |
| Sensitivity | 3 levels Adjusted by PRO or user with admin rights in the Ajax app. |
| False alarm prevention | DualTone Two-factor glass break verification software algorithm: by low and high frequencies. |
| Glass break characteristics | |
| Minimum glass size | 279 × 279 mm 11″ × 11″ Detection distance is up to 9 m (30 ft) for all glass types when the High sensitivity level is selected. |
| Glass types and their thickness: |
|
| Caution | The device will not detect glass breaking if the glass is covered with shockproof, sunscreen, decorative, or any other film. |
| Sabotage protection | |
| Tamper alarm | Notifications on attempts to detach the device from the surface or remove it from the mounting panel. |
| Holding screw | to secure the detector on SmartBracket |
| Protection against spoofing | device authentication |
| Communication loss detection | after 36 s Detection time depends on the Jeweller or Jeweller/Fibra settings. |
| Power Supply | |
| Battery | 1 × CR123A Pre-installed. |
| Type | type C |
| Calculated battery life | up to 5 years |
| Detector’s operating voltage range | 2.1−3.3 V⎓ |
| Device’s nominal operating voltage | 3 V⎓ |
| Quiescent device’s current consumption at nominal voltage | 38 μA |
| Maximum device’s current consumption at nominal voltage | 60 mA |
| Full battery capacity | 1,600 mAh |
| Low battery voltage | 2.5 V⎓ |
| Low battery recovery voltage | 2.7 V⎓ |
| End-of-life battery voltage | 2.1 V⎓ Device is switched off. |
| End-of-life battery capacity | 300 mAh |
| Manufacturer | Huiderui or Duracell UL listed. |
| Enclosure | |
| Color | White |
| Dimension | 110 × 65 × 50 mm 4.33″ × 2.56″ × 1.97″ |
| Weight | 92 g 3.25 oz |
| Operating temperature range | from −10 °C to +40 °C from 14 °F to 104 °F Temperature range from 32 °F (0 °C) to 120 °F (+49 °C) is certified according to UL/ULC standards. |
| Operating humidity | up to 75% Humidity of up to 93% is certified according to UL/ULC standards. |
| Casing protection class | IP50 |
| Complete set | CombiProtect Jeweller SmartBracket mounting panel CR123A battery (pre-installed) Installation kit Quick start guide |
| Warranty | 24 months |
