VIGI C540V(4mm) TP-Link VIGI 4MP Telecamera PTZ da esterno C540V IP ONVIF PoE con Full Color e Visione Notturna 4Megapixel, doppia ottica varifocale 4-12mm, Zoom 3x, H.265+, Smart IR con luce bianca fino a 30M. Classificazione persone e veicoli, Video Analisi, Smart Video Enhancement, monitoraggio da remoto, BLC, 3D DNR, HLC, SmartIR, bottone reset. Protezione IP66. Dimensioni: 107x136x139 mm
3 Anni di Garanzia
FUORI TUTTO ×
FUORI TUTTO!
Approfitta della imperdibile offerte del nostro outlet
Scopri la promo >>

VIGI C540V(4mm) TELECAMERA 4MP TP LINK VIGI PTZ DOPPIA LENTE VARIFOCALE CON VISIONE NOTTURNA - FULL COLOR

Telecamera TP-Link VIGI 4MP PTZ IP ONVIF - VIGI C540V(4mm)
Risoluzione 4Megapixel - doppia ottica varifocale 4-12mm - Compressione H.265+ - Sensore 1/3" Progressive Scan CMOS - Zoom 3x
Visione Notturna e IR luce bianca: Fino a 30 metri - SmartVid: Smart IR, WDR, 3D DNR, BLC, HLC
Tracciamento Automatico del movimento e percorsi personalizzabili - Video Analisi e Classificazione umani/veicoli - Full Color
Monitoraggio da remoto - 3 Anni di garanzia
DETTAGLI PRODOTTO
|| Specifiche Tecniche:
- Risoluzione Video: H.265+/H.265/H.264+/H.264
- Sensore: 1/3’’ Progressive Scan CMOS
- Illuminazione: 0.0005 Lux; 0 Lux with white light
- Frequenza dei Fotogrammi: 2560x1440, 2304x1296, 2048x1280, 1920x1080,1280x720
- Alimentazione: 12V DC/PoE
- Obiettivo: Doppia lente varifocale 4-12mm
|| Caratteristiche Principali:
- Visione Notturna Full-Color e IR: Fino a 30 metri di distanza per immagini nitide anche al buio.
- Patrol Personalizzato: Configura percorsi di monitoraggio su misura.
- Tracciamento Automatico: Segue automaticamente i movimenti di persone e veicoli.
- Difesa Attiva: Allarmi acustici e luminosi integrati per rispondere a eventi sospetti.
- Storage On-Board: Supporta memorie micro-SD per archiviazione locale.
- Rilevamento Intelligente: Include rilevamento movimento con classificazione umana, manomissione della telecamera, attraversamento di linea e intrusioni in area.
- SmartVid: Tecnologie avanzate come Smart IR, WDR, 3D DNR e BLC migliorano la qualità video.
- Compatibilità ONVIF: Interoperabilità con altri dispositivi di sicurezza.
- Monitoraggio Remoto: Accesso tramite l'app VIGI, interfaccia Web e VIGI Security Manager.
- 3 Anni di Garanzia
SCHEDA TECNICA
| CAMERA | |
|---|---|
| Image Sensor | 1/3’’ Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Min. Illumination | 0.0005 Lux; 0 Lux with white light |
| Day & Night | IR Cut Filter |
| Day/Night Switch | Day/Night/Auto/Schedule-Switch |
| Zoom | 3x Mixed Zoom |
| LENS | |
| Focal Length | 4-12 mm (Mixed Zoom) |
| Aperture | F1.6 |
| FOV | Diagonal FOV: 100°, Horizontal FOV: 84°, Vertical FOV: 46° |
| Lens Mount | M16*P 0.5 |
| ANGLE ADJUSTMENT (MANUAL) | |
| Range | Pan: 0° to 332°, Tilt: 0° to 120° |
| PTZ | |
| Pan/Tilt Range | Pan: 0° to 332°, Tilt: 0° to 120° |
| Pan/Tilt Speed | Pan Speed: Configurable from 1° to 55°/s; Preset Speed: 55°/s Tilt Speed: Configurable from 1° to 40°/s, Preset Speed 40°/s |
| Presets | 300 |
| Patrol Scan | 8 patrols, up to 8 presets for each patrol |
| Power-off Memory | Yes; Auto restore to previous PTZ and lens status after power failure |
| Park Action | Yes; Preset; Patrol Scan |
| 3D Positioning | Yes |
| ILLUMINATOR | |
| IR LED | Quantity: 1 Range: 30m Wavelength: 850nm |
| White LED | Quantity: 3 Range: 30m |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
| VIDEO | |
| Max. Resolution | 2560 X 1440 |
| Main Stream | Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080,1280x720 Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Sub-Stream | Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 640x480, 352x288, 320x240 Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Bit Rate Control | CBR, VBR |
| Video Compression | Main stream: H.265/H.265+/H.264/H.264+ Sub-stream: H.265/H.264 |
| H.264 Type | Main Profile/High Profile |
| H.264 + | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265 + | Main Stream Supported |
| Video Bit Rate | Main Stream: 256 Kbps to 4 Mbps Sub-Stream: 64 Kbps to 512 Kbps |
| IMAGE | |
| Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°) |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | DWDR |
| SNR | ≥ 52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD Setting | Yes |
| AUDIO | |
| Audio Communication | Yes |
| Audio Input | Yes |
| Audio Output | N/A |
| Audio Compression | Yes |
| Audio Sampling Rate | 8KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64 Kbps(G.711 alaw) |
| NETWORK | |
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Network Storage | NAS (NFS, SMB/ CIFS) |
| API | Open Network Video Interface (Profile S) |
| Web Browser | Google Chrome® 57 and above Firefox® 52 and above Safari® 11 and above Microsoft® Edge 91 and above |
| Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, VIGI Security Manager, VIGI NVR, Web |
| Cloud | Yes |
| ONVIF | Yes |
| INTERFACE | |
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| On-board Storage | Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB |
| Built-in Speaker | Yes |
| Built-in Microphone | Yes; Records Anything Going on within a 15-ft Radius of the Camera |
| Audio | N/A |
| Alarm | N/A |
| Reset Button | Yes |
| Power | DC Power Port |
| ALARM AND EVENT MANAGEMENT | |
| Smart Event | Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Abandoned Object Detection, Object Removal Detection |
| Basic Event | Motion detection, Camera Tampering, Scene Change Detection, Exception (illegal login) |
| Alarm Linkage | Memory Card Video Recording, Message Push, White Light Flashing |
| Linkage Method | N/A |
| Output Notification | Message Push |
| GENERAL | |
| Operating Temperature | -30–60 °C |
| Storage Temperature | -40–60 °C |
| Operating Humidity | 95% or Less (Non-condensing) |
| Storage Humidity | 95% or Less (Non-condensing) |
| Power Supply | 12V DC ± 5%, 5.5mm Coaxial Power Plug PoE (802.3af/at, class 0) |
| Power Consumption | Maximum 14 W Typical (Day Mode) 2.9 W Typical (Night Mode with IR LED) 5.7W Typical (Night Mode with White LED) 6.1W |
| Material | Plastic |
| Protection | IP66 |
| Product Dimensions (L x W x H) | 107*136*139 mm |
| Package Contents | VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
| Net Weight | 0.43 Kg |
| Gross Weight | 0.66 Kg |
| Certifications | CE, NTRA, VCCI, KC, BSMI, FCC, IC |
![]() |
|
|
Nitidezza e colori h24 La telecamera Full-Color VIGI supporta risoluzione video 4MP ed è in grado di catturare video a colori e ricchi di dettagli anche in condizioni di totale oscurità, grazie all'obiettivo con apertura F1.6 , al sensore ad alta sensibilità e ai faretti supplementari integrati. |
|
|
Hardware Pan-Tilt Monitora ogni zona grazie alle telecamere VIGI Pan-Tilt. I percorsi di pattuglia personalizzati e il tracciamento automatico ti permettono di monitorare in modo intelligente le aree chiave e migliorare la sicurezza della tua proprietà.
|
|
|
Classificazione persone e veicoli I chip AI integrati nella telecamera VIGI supportano algoritmi avanzati che consentono di distinguere esseri umani e veicoli da altri oggetti in movimento, per un'estrema personalizzazione delle opzioni di monitoraggio e di azionamento dell'allarme.
Classificazione persone e veicoli
Classificazione veicoli On
|
|
|
Automatic Tracking Grazie al movimento pan-tilt e all'analisi intelligente dell'immagine puoi seguire specifiche persone o veicoli in movimento, tracciandone il percorso in modo preciso.
|
|
|
|
|
|
|
|
|
Garanzia 3 anni Il seguente prodotto é coperto da garanzia 3 anni |
|
