Telecamera IP ANPR 4MP VIGI InSight LPR345Z con ottica motorizzata 2.7–13.5mm 5x, LPR targhe, WDR 120dB, PoE, IP67 IK10
InSight LPR345Z - è una soluzione professionale progettata per il riconoscimento automatico delle targhe (ANPR/LPR) e il controllo accessi veicolari in parcheggi, aziende e aree protette. Dotata di ottica motorizzata varifocale 2.7–13.5 mm con zoom ottico 5x e apertura F1.6, offre un’inquadratura flessibile e precisa per l’identificazione dei veicoli. Grazie alla risoluzione 4MP (2688×1520), True WDR 120 dB e compressione H.265+, garantisce immagini dettagliate e ottimizzazione della banda. Integra illuminazione LED per visione Full-Color, microfono integrato e funzioni avanzate di riconoscimento targhe con allowlist e blocklist fino a 100.000 veicoli. La struttura IP67 e IK10, con PoE, interfaccia audio e allarme e slot MicroSD fino a 512 GB, la rende ideale per sistemi di sicurezza e controllo accessi professionali. Vigi
InSight LPR345Z – TELECAMERA BULLET - OTTICA VARIFOCALE 2.7-13.5mm RISOLUZIONE 4MP - OUTDOOR

La telecamera IP VIGI InSight LPR345Z è progettata per sistemi di controllo accessi veicolari e riconoscimento automatico targhe (ANPR/LPR), ideale per parcheggi, ingressi aziendali e aree protette. Integra ottica motorizzata varifocale 2.7–13.5 mm con zoom ottico 5x e apertura F1.6, offrendo regolazione precisa dell’inquadratura e identificazione affidabile dei veicoli. Grazie alla risoluzione 4MP (2688×1520), True WDR 120 dB e compressione H.265+, garantisce immagini nitide e ottimizzazione della banda. Le funzioni ANPR con allowlist e blocklist fino a 100.000 targhe consentono gestione automatizzata degli accessi e controllo barriere. Dotata di illuminazione LED Full-Color, microfono integrato, PoE e struttura IP67 IK10 antivandalo, è ideale per installazioni professionali outdoor.
Caratteristiche principali:
- Ottica motorizzata varifocale 2.7–13.5 mm con zoom ottico 5x
- Risoluzione 4MP (2688×1520) con compressione H.265+
- Tecnologia ANPR/LPR per riconoscimento automatico targhe
- Gestione allowlist e blocklist fino a 100.000 veicoli
- True WDR 120 dB per immagini bilanciate
- Illuminazione LED Full-Color integrata
- Microfono integrato e interfaccia audio/allarme
- Porta RJ45 con PoE e slot MicroSD fino a 512 GB
- Protezione IP67 e IK10 per installazioni esterne
Ulteriori dettagli
La telecamera integra una ottica motorizzata varifocale 2.7–13.5 mm con zoom ottico 5x e apertura F1.6, che consente di regolare con precisione l’inquadratura e ottenere un campo visivo variabile fino a 102°, ideale per il monitoraggio di ingressi, parcheggi e varchi veicolari.
Grazie al sensore CMOS 1/2.9” Progressive Scan e alla risoluzione 4MP (2688×1520), la telecamera garantisce immagini dettagliate e nitide, supportando la compressione video H.265+ / H.264+ per ottimizzare banda e spazio di archiviazione nei sistemi di videosorveglianza IP.
La presenza di interfacce audio e ingressi/uscite di allarme consente l’integrazione con sistemi di sicurezza esterni, permettendo di gestire notifiche, attivazioni automatiche e collegamenti con dispositivi di controllo accessi.
Le funzioni avanzate di miglioramento video come True WDR 120 dB, BLC e 3D DNR permettono di ottenere immagini più chiare e bilanciate, riducendo rumore digitale e migliorando la qualità delle registrazioni anche in condizioni di forte contrasto luminoso.
SCHEDA TECNICA
| InSight LPR345Z | |
| CAMERA | |
| Sensore di immagine | 1/2.9” Progressive Scan CMOS |
| Shutter Speed | 1/100 to 1/1000 s |
| Slow Shutter | Yes |
| Luminosità minima | Color: 0.005 Lux; 0 Lux with IR/white light |
| LENS | |
| Type | Motorized Varifocal Lens |
| Focal Length | 2.7-13.5 mm (5X Optical Zoom) |
| Aperture | F1.6 |
| FOV | Horizontal FOV: 29.6°-102.0°, Vertical FOV: 16.8°-53.8°, Diagonal FOV: 34.1°-122.8° |
| Lens Mount | Φ14 |
| Angle Adjustment (Manual) | |
| Range | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| ILLUMINATOR | |
| IR LED | Quantity: 4 |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
| ILLUMINATOR | |
| Max. Resolution | 2688 x 1520 |
| Main Stream | Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080 |
| Sub-Stream | Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 1280x720, 848x480, 704x576, 640x480, 640x360, 352x288, 320x240 |
| Bit Rate Control | CBR, VBR |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | Main Stream: 256 Kbps to 6 Mbps Sub-Stream: 64 Kbps to 1024 Kbps |
| Image | |
| Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | 120 dB |
| SNR | ≥ 52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD Setting | Yes |
| AUDIO | |
| Ingresso audio | Built-in Microphone Audio In Interface |
| Uscita audio | Audio Out Interface |
| Codec audio | Yes |
| Audio Sampling Rate | 8KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64 Kbps(G.711 alaw) |
| NETWORK | |
| Protocol | TCP/IP, UDP, ICMP, ARP, SNMP, RTMP, HTTP, HTTPS, DHCP, DNS, RTSP, RTP, NTP, IPv4, IPv6, UPnP, SSL/TLS, FTP/SFTP |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile S/T/G) |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS |
| Web Browser | Google Chrome® 57 and above Firefox® 52 and above Safari® 11 and above Microsoft® Edge 91 and above |
| Cloud | Yes |
| Sicurezza | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X authentication |
| ALLARME E GESTIONE EVENTO | |
| Basic Event | Motion Detection Camera Tampering Exception (Illegal Login) |
| Alarm Linkage | Push Notifications |
| License Plate Recognition Management | |
| Capture Mode | Trigger Type: Video Detection, I/O Coil Picture Type: Scene Picture, Scene Picture + Close-up Picture Max Recognition Distance: 8 m (26 ft) at default zoom; 15 m (49 ft) at maximum zoom Scene Mode: Entrance & Exit |
| Capture Parameters | Image Format: JPEG Capture Resolution: 2560×1440 LED Control: Supports automatic light control/time control of LEDs Smart Recognition: ANPR Capture Picture Overlay: Capture Time, Plate Number, Vehicle Permission Type (Allowlist, Blocklist, Temporary) |
| Entrance and Exit | Barrier Gate Control Mode: By Camera Relay Output: 1-ch relay output, supporting opening and closing of barrier gates Allowlist And Blocklist: Up to 100,000 allowlist and blocklist totally (recommended for use with a microSD card) |
| INTERFACCE | |
| Interfaccia di rete | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Allarme | 1 Alarm In, 1 Alarm Out |
| Reset Button | Yes |
| Power | DC Power Port |
| RS-485 Port | Yes |
| On-board Storage | Built-In Memory Card Slot, Support MicroSD Card, Up to 512 GB |
| Built-in Microphone | Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera |
| Built-in Speaker | N/A |
| Audio | 1 Audio In, 1 Audio Out |
| GENERALE | |
| Operating Temperature | -30–60 °C (-22 °F to 140 °F) |
| Storage Temperature | -40–60 °C (-40 °F to 140 °F) |
| Operating Humidity | 95% or Less (Non-Condensing |
| Storage Humidity | 95% or Less (Non-Condensing) |
| Contenuto della confezione | VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
| Material | Metal |
| Net Weight | 1.07 Kg |
| Power Supply | DC 12V DC ± 5%, Max.10.8 W, 5.5 mm Coaxial Power Plug Recommended Power Supply:T120100-2C1 (for EU Regions) PoE PoE: 802.3af, class 0, Max.12.95 W ErP Information Power consumption in networked standby when all wired network ports are connected and all wireless network ports are activated: 2W. |
| Protection | IP67 Waterproof, IK10 Vandal Proof |
| Product Dimensions (L x W x H) | 10.1 × 3.9 × 4 in (256 × 100 × 101 mm) |
| Certifications | CE, NTRA, KC, FCC, IP67, IC, IK10, VCCI, BSMI, ONVIF |
