KTX01F - Dahua - Kit Videocitofonia Completo - Per installazione a parete: 1x postazione esterna 2 fili VTO2023S + 1x Postazione interna bifilare o WIFI con display 7" TFT e risoluzione 1024x600 VTH2123GW-W +1x Controller bifilare VTNC1003C + cavo alimentazione.
FUORI TUTTO ×
  FUORI TUTTO!
Approfitta della imperdibile offerte del nostro outlet
  Scopri la promo >>
KIT DI SORVEGLIANZA VIDEOCITOFONIA DAHUA VILLA - COMPLETO - PER FISSAGGIO IN SUPERFICIE - KTX03

|
 COSA INCLUDE IL KIT KTX03? - 1x Postazione Esterna con telecamera 2MP DWDR - Visione A: 84°; V: 43°; P: 99° - Per esterno IP65 - IK08 (VTO2023S)   |
Dettagli prodotto
|
 Postazione esterna con telecamera 2MP HDR DWDR - IK08 e da esterno IP65 - VTO2023S
  |
 VTO2023S > Telecamera 2MP CMOS 1/2.8" HDR, DWDR, 3DNR
  |
1x Monitor Indoor con display 7" TFT Touchscreen capacitivo - VTH2123GW-W![]()  |
 1x Postazione interna bifilare / WIFI bianca con display 7" TFT - Audio/Allarme - VTH2123GW-W > Touch screen capacitivo TFT 7" 1024 (H) × 600 (V)  |
|
 1x Controller bifilare - VTNC1003C
  |
 1x Controller bifilare - VTNC1003C > Case in ABS e Policarbonato  |
Scheda tecnica
| KIT: KTX03 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 VTH2123GW-W  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 System  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Main Processor  |
 Embedded Processor  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating System  |
 Embedded operating system  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Network Protocol  |
 UDP;TCP;IPv4;DNS  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Basic  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Screen Type  |
 Capacitive Touchscreen  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Display Screen  |
 7" TFT  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Screen Resolution  |
 1024 (H) × 600 (V)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Compression  |
 G.711a; G.711u; PCM  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Input  |
 1 channel  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Output  |
 Built-in speaker  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Mode  |
 Two-way audio with VTO (half–duplex);Two-way audio with app (full–duplex)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Enhancement  |
 Echo suppression/digital noise reduction  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Bit Rate  |
 16 KHz; 16 Bit  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Function  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Leave Videos  |
 Yes (SD card needed)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 DND Mode  |
 Do not disturb period can be set;Do not disturb mode can be set  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Number of Extensions  |
 5  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Wi-Fi  |
 Yes  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Wireless Standard  |
 IEEE802.11b; 802.11g; 802.11n  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Wireless Frequency Range  |
 2.4 GHz  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Storage  |
 Micro SD card (up to 64 GB)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Performance  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Casing Material  |
 PC + ABS  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Port  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 RS-485  |
 1  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Alarm Input  |
 6  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Alarm Output  |
 1 channel  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Output  |
 1 (12 V, 200 mA)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Lock Control  |
 Yes (use the alarm input port)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 General  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Appearance Color  |
 White  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Supply  |
 2-wire controller  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Adapter  |
 Optional  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Installation  |
 Surface mount  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Certifications  |
 CE  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Accessory  |
 Included:  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Product Dimensions  |
 134.6 mm × 189.6 mm × 24.0 mm (5.30" × 7.46" × 0.94")  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Temperature  |
 –10 °C to +55 °C (14 °F to +131 °F)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Humidity  |
 10%–90% (RH)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Altitude  |
 0 m–3000 m (0 ft – 9842.52 ft)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Consumption  |
 ≤ 4 W (standby), ≤ 10 W (working)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Gross Weight  |
 622 g (1.37 lb)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Storage Temperature  |
 0 °C to 40 °C (32 °F to 104 °F)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Storage Humidity  |
 30%–75%  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Anti-corrosion Level  |
 Basic Protection  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Environment  |
 Indoor  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 VTO2023S  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 System  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Main Processor  |
 Embedded Processor  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Button Type  |
 Mechanical  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Basic  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Camera  |
 1/2.8" 2 MP CMOS HDR Camera  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Field of View  |
 H: 84°; V: 43°; D: 99°  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 WDR  |
 DWDR  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Noise Reduction  |
 3D NR  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Video Resolution  |
 P: 960 (H) × 576 (V)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Video Frame Rate  |
 P: 25 fps  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Light Compensation  |
 Auto IR  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Day/Night  |
 Auto(ICR)/Color/B/W  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Input  |
 1 channel  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Output  |
 Built-in speaker  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Audio Mode  |
 Two-way audio (half–duplex)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Function  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Unlock Mode  |
 IC card; password; remote unlock  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Card Type  |
 IC card  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Leave Videos  |
 Yes (SD card inserted in VTH is needed)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Port  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 RS-485  |
 1  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Alarm Output  |
 1  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Output  |
 1 (12 V, 500 mA)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Exit Button  |
 1  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Door Status Detection  |
 1  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Lock Control  |
 1  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Performance  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Card Reading Distance  |
 0 cm-2 cm  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Issue Card Locally  |
 Yes  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Casing Material  |
 Aluminum alloy  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Capacity  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Card Capacity  |
 100  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Alarm  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Tamper Alarm  |
 Yes  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 General  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Unlock Password Mode  |
 Personal password  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Appearance Color  |
 Silvery white  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Supply  |
 2-wire Controller  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Adapter  |
 Optional  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Optional  |
 Surface Mount  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Certifications  |
 CE  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Accessory  |
 Sold separately: 2-wire controller  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Product Dimensions  |
 205.8 mm × 85.3 mm × 46.5 mm (8.10" × 3.36" × 1.83")  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Protection  |
 IP65 IK08  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Temperature  |
 –40 °C to +60°C (–40 °F to +140 °F)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Humidity  |
 10%–90% (RH), non-condensing  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Environment  |
 Outdoor  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Altitude  |
 0 m–3000 m (0 ft – 9842.52 ft)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Consumption  |
 ≤ 2 W (standby), ≤ 12 W (working)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Gross Weight  |
 978 g (2.16 lb)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Anti-corrosion Level  |
 Basic Protection  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 VTNC1003C  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Performance  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Casing Material  |
 PC + ABS  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Port  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Output  |
 48 V/0.9 A  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 General  |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Appearance Color  |
 White  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Supply  |
 48 VDC  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Adapter  |
 48 V/0.9 A  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Certifications  |
 CE; FCC  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Accessory  |
 Included: Line termination terminal  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Product Dimensions  |
 65.2 mm × 46.2 mm × 23.2 mm (2.57" × 1.82" × 0.91")  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Temperature  |
 –10 °C to +55°C (14 °F to +131 °F)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Humidity  |
 10%–95% (RH)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Operating Altitude  |
 0 m–3000 m (0 ft – 4265.09 ft)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Power Consumption  |
 3.5 W  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
 Gross Weight  |
 0.13 kg (0.29 lb)  |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
