DS-2CD2347G3-LIY 4MP 2.8mm ColorVu IP67 AI Human Vehicle Detection - Hikvision

DS-2CD2347G3-LIY 4MP 2.8mm ColorVu IP67 AI Human Vehicle Detection - Hikvision
-35% Neu

DS-2CD2347G3-LIY(2.8mm) - is a 4MP (2688×1520) IP turret camera with 1/1.8" Progressive Scan CMOS sensor and ColorVu 24/7 technology, designed for color images even down to 0.0001 Lux. The 2.8 mm F1.0 fixed lens offers a wide 111.1° horizontal FOV and 2.5 m to infinity depth of field, ensuring high brightness and detail. It integrates Smart Hybrid Light (IR + White Light) up to 30 m , WDR 130 dB and H.265+ compression for optimized performance in high-contrast scenes. The Deep Learning functions with Human & Vehicle Detection , Face Capture and advanced perimeter protection, IP67 certification and NEMA 4X protection, make it ideal for professional indoor and outdoor installations. Hikvision

Technical Data Sheet

Artikel-Nr.: DS-2CD2347G3-LIY(2.8mm)

Marke: Hikvision

EAN: 6936422115180

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Seit ihrem Geburtsjahr ist ihr Ansehen so stark gewachsen, dass sie 2015 die erste globale Sicherheitsrealität sein wird.

Ab 2016 expandiert Hikvision seinen Markt und wird zum Total Solution Provider für den gesamten Sicherheitsmarkt. So tritt sie in die Welt der Intrusion Detection ein und nähert sich dann neuen Technologien und Intelligenz im Dienste der Menschheit, indem sie sich mit IoT, Machine Vision, Robotik und Automotive-Systemen befasst. Vom Marktführer im Sicherheitsbereich wird Hikvision mit Engagement, Leidenschaft und Kompetenz zu einem Hi-Tech-Unternehmen mit der Vision 4.0, immer mit hohen Zielen.

Setik fühlt sich daher geehrt, ein Hikvision-Vertriebspartner zu sein. Wir werden, wie immer, Produkte der neuesten Generation und die entsprechende technische und kommerzielle Unterstützung anbieten.

[short_description] =>

Videosorveglianza Hikvision

Hikvision wurde 2001 mit dem Ziel gegründet, komplette professionelle Videoüberwachungslösungen zu schaffen und zu entwickeln und wurde schnell zu einem führenden Unternehmen in der Sicherheitswelt.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Hikvision [meta_keywords] => Hikvision [meta_description] => Hikvision wurde 2001 gegründet und wurde bald zu einem führenden Unternehmen in der Welt der Videoüberwachung. Entdecken Sie jetzt die Produkte im Katalog! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 26 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
INSTALLATEUR FINDEN


KOSTENLOSER VERSAND! ×


FREE SHIPPING ON
THE ENTIRE CATALOGUE!

Code: FREE-WEEK-E
Only until 10:00 a.m. on 16/02

DS-2CD2347G3-LIY(2.8mm) – TURRET CAMERA FIXED LENS 2.8mm 4MP - HUMAN AND VEHICLE DETECTION - DEEP LEARNING FUNCTION - COLORVU - SMART HYBRID LIGHT

Hikvision

The Hikvision DS-2CD2347G3-LIY (2.8mm) is a 4MP (2688×1520) IP turret camera with a 1/1.8" Progressive Scan CMOS sensor and ColorVu 24/7 technology, capable of color images up to 0.0001 Lux thanks to the F1.0 aperture. The 2.8 mm fixed lens offers a wide 111.1° horizontal FOV and a depth of field from 2.5 m to infinity, ideal for wide-angle coverage. It integrates Smart Hybrid Light (IR + White Light) up to 30 m, WDR 130 dB and H.265+ compression for maximum quality and bandwidth optimization. The Deep Learning functions with Human & Vehicle Detection, Face Capture , IP67 protection and NEMA 4X certification guarantee reliability in professional indoor and outdoor environments.

Main features:

- Resolution 4MP 2688×1520

- Fixed 2.8 mm F1.0 lens with FOV 111.1°

- ColorVu 24/7 color technology 0.0001 Lux

- WDR 130 dB and H.265+ compression

- Smart Hybrid Light IR + White Light up to 30m

- Deep Learning Human & Vehicle Detection with Face Capture

- IP67 and NEMA 4X corrosion protection


Further details

Fixed optics :
Fixed focal 2.8mm lens with F1.0 aperture and 111.1° horizontal FOV , designed to maximize light gathering and ensure wide coverage with a depth of field from 2.5 m to infinity.
Resolution:
4MP 2688×1520
1/1.8" Progressive Scan CMOS sensor for high-definition images, high details and smooth recording up to 30 fps with H.265/H.265+ compression.
24/7 Colorful Imaging ColorVu:
ColorVu technology with sensitivity up to 0.0001 Lux , capable of providing color images 24/7 even in almost total darkness.
Smart Hybrid Light:
Up to 30 m : intelligent lighting system with IR + White Light and 3 additional modes, which optimizes night visibility and active deterrence.
Human Detection:
Deep Learning-based people detection system with alarm activation on specific targets, ideal for perimeter protection and reduction of false positives.
Vehicle Detection:
Accurate vehicle classification for access control and perimeter protection applications.
Motion Detection :
Support for line crossing, intrusion, region entrance and region exiting , with alarm activation on specific targets (human/vehicle).
Deep Learning Function :
Built-in smart features for face capture and intelligent video analytics geared towards professional security.
 Network Protocol:
Compatibility with TCP/IP, HTTPS, RTSP, ONVIF (Profile S, G, T) , IPv4/IPv6 support, SSL/TLS encryption, 802.1X authentication and integration with major VMS.

Technical data sheet

DS-2CD2347G3-LIY(2.8mm)
Room
Image Sensor 1/1.8" Progressive Scan CMOS
Max. Resolution 2688 × 1520
Min. Illumination Color: 0.0001 Lux @ (F1.0, AGC ON),0 Lux with light
Shutter Time 1/3 s to 1/100,000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type Fixed focal lens, 2.8mm
Focal Length & FOV horizontal FOV 111.1°, vertical FOV 57.6°, diagonal FOV 138.5°
Lens Mount M16
Iris Type Fixed
Openings F1.0
Depth of Field 2.5 m to ∞
Illuminator
Supplement Light Type IR, White Light
Supplement Light Range Up to 30 m
Smart Supplement Light Yes
IR Wavelength 850mm
Video
Main Stream 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 30fps (2688×1520, 1920×1080, 1280×720)
Sub-Stream

50Hz: 25fps (1280×720, 640×480, 640×360)
60Hz: 30fps (1280×720, 640×480, 640×360)

Third Stream

50Hz: 10fps (1920×1080, 1280×720, 640×480, 640×360)
60Hz: 10fps (1920×1080, 1280×720, 640×480, 640×360)
*Third stream is supported under certain settings.

Video Compression

Main stream: H.265/H.264/H.264+/H.265+,
Substream: H.265/H.264/MJPEG
Third stream: H.265/H.264,
*Third stream is supported under certain settings.

Video Bit Rate

32 Kbps to 8 Mbps

H.264 Type

Baseline Profile, Main Profile, High Profile

H.265 Type

Main Profile

Bit Rate Control

CBR,VBR

Region of Interest (ROI)

1 fixed region for main stream and sub-stream

Scalable Video Coding (SVC)

H.264 and H.265 encoding

Network
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Simultaneous Live View

Up to 6 channels

API ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)

User/Host

Up to 32 users.
3 user levels: administrator, operator and user

Client

iVMS-4200,Hik-Connect,Hik-Central

Network Storage

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)

Web Browser

Free live view plug-ins: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+,
Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+

Image Parameters Switch

Yes

Image Settings

Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser

Image Enhancement BLC,HLC,3D DNR,Distortion Correction,Defog
Day/Night Switch

Day, Night, Auto, Schedule

Wide Dynamic Range (WDR)

130 dB

SNR ≥ 52 dB
Image Stabilization EIS
Privacy Mask

4 programmable polygon privacy masks

Interface
Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512GB
Reset Key Yes
Event
Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
Smart Event Scene change detection
Linkage Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email
Deep Learning Function
Face Capture Yes
Perimeter Protection Line crossing, intrusion
Support alarm triggering by specified target types (human and vehicle)
General
Power

12 VDC ± 25%, 0.7 A, max. 8.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max.11W

Material

Front cover: metal, body: metal, bracket: metal

Dimension

Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5")

Package Dimension

170mm × 170mm × 160mm (6.7" × 6.7" × 6.3")

Weight

Approx. 750 g (1.7 lb.)

With Package Weight

Approx. 1140 g (2.5 lb.)

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Language

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function

Heartbeat, mirror, flash log, password reset via email, password protection, anti-banding

Approval
EMC CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
IC: ICES-003: Issue 7,
RCM: AS/NZS CISPR 32:2015
KC: KN32: 2015, KN35: 2015
Safety UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
Environment

CE-RoHS (2011/65/EU)

Protection

IP67: IEC 60529-2013

Anti-Corrosion Protection

NEMA 4X (NEMA 250-2018)
