TW2423AS-B3P 24" Full HD IPS Android PoE NFC RFID Wi-Fi LAN VESA for Digital Signage and Retail - iiyama
The iiyama ProLite TW2423AS-B3P 24" Full HD professional monitor is designed for digital signage, intelligent retail and professional interactive applications . The IPS display with 1920x1080 resolution ensures sharp images, vivid colors and wide viewing angles , ideal for informational and multimedia content. Thanks to the integrated Android operating system , the device allows easy management of applications and digital content. Advanced connectivity with Wi-Fi, Bluetooth, LAN and Power over Ethernet (PoE) allows clean and flexible installations with just one cable. The integrated NFC/RFID reader allows user authentication, identification and contactless payments. The robust design with VESA support and continuous 24/7 operation makes it perfect for permanent installations in professional environments.
TW2423AS-B3P – IPS MONITOR 24" FULL HD IIYAMA PROLITE - TOUCSCREEN - ANDROID OS - RJ45 & POE
The iiyama ProLite TW2423AS-B3P 24" Full HD professional monitor is designed for digital signage, intelligent retail and interactive business applications that require reliability and easy content management. The IPS display with 1920x1080 resolution offers sharp images, vivid colors and wide viewing angles , ideal for presentations, information and visual communication. Thanks to the integrated Android operating system , it allows flexible management of applications and multimedia content. Full connectivity with Wi-Fi, Bluetooth, LAN and Power over Ethernet (PoE) allows clean installations with a single cable. The integrated NFC/RFID reader facilitates user authentication, logins and contactless payments. The robust design with VESA support and continuous 24/7 operation makes it ideal for permanent professional installations.
Main features:
- 24" IPS display with Full HD 1920×1080 resolution
- Integrated Android operating system for application management
- Wi-Fi, Bluetooth, LAN and Power over Ethernet (PoE) connectivity
- Integrated NFC/RFID reader for authentication and payments
- VESA mounting support for professional installations
- Designed for 24/7 continuous operation
Further details
Technical data sheet
| Model | TW2423AS-B3P |
| DISPLAY CHARACTERISTICS | |
| Design | Thin bezel |
| Diagonal | 23.8", 60.5cm |
| Panel | IPS |
| Native resolution | 1920 x 1080 (2 megapixel HD) |
| Aspect ratio | 16:9 |
| Panel brightness | 450 cd/m² |
| Static contrast | 1000:1 with touch |
| Response time (MPRT) | 14ms |
| Viewing zone | horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
| Color support | 16.7 million 8-bit |
| Horizontal Sync | 30 - 83kHz |
| Viewable area W x H | 527 x 296.5mm |
| Pixel pitch | 0.275mm |
| Color | black, matte |
| TOUCH | |
| Touch technology | projective capacitive |
| Touch points | 10 (HID, only supported by integrated OS, external OS only support single touch) |
| Touch method | finger, glove (latex), capacitive stylus |
| Touch interface | USB |
| INTERFACES / CONNECTORS / CONTROLS | |
| Digital signal output |
USB-C x1 (1x v. 3.2 (Gen 1, video output and touch board function – mirror screen)) |
| Audio output |
Mini jack x1 |
| Audio output |
Speakers 2 x 5W |
| HDCP |
Yes |
| USB ports | x2 (1x v. 3.2 (Gen 1, 5Gbit; DC5V, 900mA), 1x 2.0 (DC5V, 500mA)) |
| RJ45 (LAN) | x1 (PoE - IEEE802.3bt/72W (1000M)) |
| Microphone | x1 |
| FEATURES | |
| Integrated software | Android 14 with GMS |
| SOC | Octa-core RK3576 (4x A53 + 4x A72) |
| GPU | ARM G52 MC3 |
| Storage | 32GB eMMC |
| Memory | 4GB LPDDR4 |
| WiFi | IEEE802.11ax/ac/a/b/g/n |
| Bluetooth | 5.3 |
| Extra | auto-rotation, 2x5W speakers, dual microphone, anti-glare coating, PoE, iiSignage² |
| Max. non-stop operating time | 24/7 |
| Anti-image retention | Yes |
| Glass hardness | 6H |
| OSD key lock | Yes |
| GENERAL | |
| Control buttons |
Power switch, volume/ button +, volume/ button - |
| Applications | Applications: lock application, manage restart time, manage power on/off time, calculator, calendar, Chrome, alarm/clock/timer/stopwatch, manage files & folders, organize albums, Gmail, Google, iiSignage², play audio files, Play store, system preferences, sound recorder, play video |
| Flicker free | Yes |
| MECHANICAL | |
| Orientation | landscape, portrait, face-up |
| VESA mounting | 100 x 100mm |
| Cable management system | Yes |
| MTBF | 50000 hours (excluding backlight) |
| ACCESSORIES INCLUDED | |
| Cables | power (1.8m) |
| Guides | quick start guide, safety guide |
| Other | AC adapter |
| Cable cover | Yes |
| POWER MANAGEMENT | |
| Power Supply Unit | external |
| Power Supply | DC 12 V |
| Power Usage | 17.5W typical, 1.5W stand by, 0.3W off mode |
| SUSTAINABILITY | |
| Regulations | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| REACH SVHC | above 0.1%: Lead |
| DIMENSIONS & WEIGHT | |
| Product dimensions W x H x D | 550 x 336 x 28mm |
| Box dimensions W x H x D | 640 x 410 x 121mm |
| Weight (without box) | 4.24kg |
| Weight (with box) | 6.2kg |
