DS-PDD15AM-EG2 Triple Technology PIR Microwave Alarm Sensor 15m Internal Antimasking - Hikvision

DS-PDD15AM-EG2 Triple Technology PIR Microwave Alarm Sensor 15m Internal Antimasking - Hikvision

 
-35% Neu

DS-PDT15AM-EG2 - is a triple-technology wired detector designed to ensure high standards of security in indoor environments, thanks to the combination of a PIR sensor and a 24GHz microwave for precise and reliable detection. It offers coverage of up to 15 meters with an 85.9° angle , ensuring effective monitoring of large areas. It integrates advanced functions such as anti-masking, anti-cloaking and anti-blocking , ideal for preventing tampering and sabotage attempts. The presence of digital temperature compensation and automatic sensitivity improves performance in any environmental conditions. The compact design and non-interference technology allow for quick and efficient installation. - Hikvision

Technical Data Sheet

Artikel-Nr.: DS-PDT15AM-EG2

Marke: Hikvision

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Seit ihrem Geburtsjahr ist ihr Ansehen so stark gewachsen, dass sie 2015 die erste globale Sicherheitsrealität sein wird.

Ab 2016 expandiert Hikvision seinen Markt und wird zum Total Solution Provider für den gesamten Sicherheitsmarkt. So tritt sie in die Welt der Intrusion Detection ein und nähert sich dann neuen Technologien und Intelligenz im Dienste der Menschheit, indem sie sich mit IoT, Machine Vision, Robotik und Automotive-Systemen befasst. Vom Marktführer im Sicherheitsbereich wird Hikvision mit Engagement, Leidenschaft und Kompetenz zu einem Hi-Tech-Unternehmen mit der Vision 4.0, immer mit hohen Zielen.

Setik fühlt sich daher geehrt, ein Hikvision-Vertriebspartner zu sein. Wir werden, wie immer, Produkte der neuesten Generation und die entsprechende technische und kommerzielle Unterstützung anbieten.

[short_description] =>

Videosorveglianza Hikvision

Hikvision wurde 2001 mit dem Ziel gegründet, komplette professionelle Videoüberwachungslösungen zu schaffen und zu entwickeln und wurde schnell zu einem führenden Unternehmen in der Sicherheitswelt.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Hikvision [meta_keywords] => Hikvision [meta_description] => Hikvision wurde 2001 gegründet und wurde bald zu einem führenden Unternehmen in der Welt der Videoüberwachung. Entdecken Sie jetzt die Produkte im Katalog! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 26 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
INSTALLATEUR FINDEN

DS-PDT15AM-EG2 | WIRED DUAL-TECH AM DETECTOR

Hikvision

The Hikvision DS-PDD15AM-EG2 is a triple-technology wired detector designed for advanced security systems, combining a PIR sensor and a 24GHz microwave for precise and reliable detection. It guarantees coverage of up to 15 meters with an 85.9° angle , ideal for indoor environments such as homes and shops. It integrates advanced security functions such as anti-masking, anti-cloaking and anti-blocking , preventing sabotage attempts and false alarms. The presence of automatic sensitivity and digital temperature compensation ensures consistent performance in any environmental conditions. The compact design and non-interference technology allow for simple, quick and efficient installation.

Main specifications:

- Triple PIR + 24GHz Microwave technology for precise and reliable detection

- 15m / 85.9° coverage ideal for indoor environments

- Anti-masking, anti-cloaking and anti-blocking functions for maximum security

- Automatic sensitivity and digital temperature compensation for operational stability

- Non-interfering technology for quick installations even back-to-back

- Compact wired design with low power consumption and high reliability

Further details

✅ Detection Performance:
The detector uses a combination of PIR sensor and 24GHz microwave , offering coverage of up to 15 meters with an 85.9° angle and 52 detection zones , ensuring high accuracy and reduction of false alarms also thanks to automatic sensitivity and digital temperature compensation .
✅ Features :
It integrates advanced features such as anti-masking, anti-cloaking and anti-blocking , as well as digital processing and sealed optics , ensuring maximum protection against tampering and operational reliability in indoor environments.
✅ Interface:
Equipped with a normally closed (NC) alarm output and dedicated LED indicators (PIR, Microwave and Alarm) , it allows immediate monitoring of the device status and easy integration into security systems.
✅ Transmission :
Fully wired transmission system, designed to offer stable and continuous connection , ideal for professional installations where reliability and signal security are fundamental.
✅ Power supply:
It supports 9–16 VDC power supply with a typical value of 12V , featuring low power consumption (up to 25mA) , ensuring efficiency and constant operation over time.

Technical data sheet

DS-PDT15AM-EG2
General
Operation Temperature -10 °C to 55 °C (14 °F to 131 °F)
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Operation Humidity 10% to 90%
Dimensions (WxHxD) 65.7 mm (2.59") × 103.8 mm (4.09") × 45.5 mm (1. 79")
Weight 100g
Mounting Height 1.8 m to 2.4 m
Mounting Method Wall
Application Scenario Indoor
Bracket Optional wall & ceiling accessory
Detection Performance
Detection Method Passive Infrared; Microwave
Detection Range 15 m
Detection Angle 85.9°
Detection Zones 52
Detectable Speed 0.3～2m/s
Sensitivity Auto;Low
White Light Filter 6500lux
Microwave Frequency 24GHz(24.15～24.25GHz)
Digital Temperature Compensation Support
Creep Zone Protection Support
Features
Digital Processing Support
Sealed Optics Support
Tamper Protection Front
Anti-masking Support
Anti-cloaking Support
Anti-blocking Support

Interfaces
Alarm Output Normally Closed
LED Indicator Green(PIR), Orange(Microwave), Blue(Alarm)
Transmission
Transmission Method Wired
Electrical Characteristics
Power Supply 9 to 16 VDC
Typical Voltage 12 VDC
Power Consumption Maximum current：25mA@12VDC Quiescent current：17mA@12VDC
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
