iDS-7216HUHI-M2/XT/4A+16/4ALM DVR AcuSense 16 Channels AI 4K, Alarms, Face Recognition + 2 TB HDD Included - Hikvision

iDS-7216HUHI-M2/XT/4A+16/4ALM DVR AcuSense 16 Channels AI 4K, Alarms, Face Recognition + 2 TB HDD Included - Hikvision

 
BEST PRICE -35%

iDS-7216HUHI-M2/XT/4A+16/4ALM - AcuSense DVR is a professional 16-channel HDTVI/AHD/CVI/CVBS/IP video recorder designed for advanced video surveillance systems with AcuSense Deep Learning AI technology. It supports intelligent functions such as facial recognition , perimeter protection , AcuSearch and Motion Detection 2.0 with human/vehicle classification to drastically reduce false alarms. Compatible with cameras up to 8 MP 4K , it offers H.265 Pro+ compression, simultaneous playback of up to 16 channels and management of up to 32 IP cameras . Equipped with a 16-input / 4-output alarm interface , dual SATA bay up to 12 TB per disk and HDTVI two-way audio support. 1 x 2 TB HDD included. It represents an ideal solution for professional security, companies and high-reliability infrastructures. Hikvision

Technical Data Sheet

Artikel-Nr.: iDS-7216HUHI-M2/XT/4A+16/4ALM

Marke: Hikvision

EAN: 6942160403694

Disponibilità: 7

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Seit ihrem Geburtsjahr ist ihr Ansehen so stark gewachsen, dass sie 2015 die erste globale Sicherheitsrealität sein wird.

Ab 2016 expandiert Hikvision seinen Markt und wird zum Total Solution Provider für den gesamten Sicherheitsmarkt. So tritt sie in die Welt der Intrusion Detection ein und nähert sich dann neuen Technologien und Intelligenz im Dienste der Menschheit, indem sie sich mit IoT, Machine Vision, Robotik und Automotive-Systemen befasst. Vom Marktführer im Sicherheitsbereich wird Hikvision mit Engagement, Leidenschaft und Kompetenz zu einem Hi-Tech-Unternehmen mit der Vision 4.0, immer mit hohen Zielen.

Setik fühlt sich daher geehrt, ein Hikvision-Vertriebspartner zu sein. Wir werden, wie immer, Produkte der neuesten Generation und die entsprechende technische und kommerzielle Unterstützung anbieten.

[short_description] =>

Videosorveglianza Hikvision

Hikvision wurde 2001 mit dem Ziel gegründet, komplette professionelle Videoüberwachungslösungen zu schaffen und zu entwickeln und wurde schnell zu einem führenden Unternehmen in der Sicherheitswelt.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Hikvision [meta_keywords] => Hikvision [meta_description] => Hikvision wurde 2001 gegründet und wurde bald zu einem führenden Unternehmen in der Welt der Videoüberwachung. Entdecken Sie jetzt die Produkte im Katalog! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 26 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
INSTALLATEUR FINDEN

iDS-7216HUHI-M2/XT/4A+16/4ALM – 16-CHANNEL ACUSENSE DVR - 8MP RESOLUTION - 4 AUDIO INPUTS - 16 INPUTS & 4 ALARM OUTPUTS

Hikvision

The Hikvision iDS-7216HUHI-M2/XT/4A+16/4ALM AcuSense DVR is a professional 16-channel HDTVI/AHD/CVI/CVBS/IP video recorder designed for advanced video surveillance systems with AcuSense Deep Learning AI technology. It supports intelligent functions such as facial recognition , perimeter protection , AcuSearch and Motion Detection 2.0 with human/vehicle classification to drastically reduce false alarms. Compatible with cameras up to 8 MP 4K , it offers H.265 Pro+ compression, simultaneous playback of up to 16 channels and management of up to 32 IP cameras . Equipped with a 16-input / 4-output alarm interface , dual SATA bay up to 12 TB per disk and 1 2 TB HDD included , as well as HDTVI two-way audio support, it represents an ideal solution for professional security, companies and high-reliability infrastructures.

Main features:

  • AcuSense Professional 16-Channel DVR
  • Support up to 32 IP cameras
  • Camera compatibility up to 8 MP 4K
  • AI Deep Learning AcuSense technology
  • Facial recognition up to 4 channels
  • Perimeter protection up to 8 channels
  • Motion Detection 2.0 human/vehicle
  • Intelligent AcuSearch Technology
  • H.265 Pro+ video compression
  • Synchronized playback up to 16 channels
  • HDTVI two-way audio support
  • 16 input / 4 output alarm interface
  • 2 SATA interfaces up to 12TB per HDD
  • RJ45 Gigabit Ethernet port
  • HDTVI/AHD/CVI/CVBS/IP 5in1 compatibility
  • Remote management via Hik-Connect and ONVIF
  • 1 x 2TB HDD included

Further details

✅ Number of Channels:
 Hikvision DVR supports up to 16 analog HDTVI/AHD/CVI/CVBS channels with expansion up to 32 IP cameras , providing a professional solution for advanced high-performance video surveillance systems.
✅ Resolution :
 Compatible with up to 8MP 4K Ultra HD recording, it ensures detailed images and smooth playback up to 24 channels Full HD 1080p@30fps , ideal for professional monitoring and advanced video analysis.
✅ Perimeter Protection :
The intelligent perimeter protection function based on AI Deep Learning algorithms enables accurate recognition of people and vehicles, drastically reducing false alarms caused by environmental elements such as lights, leaves or animals.
✅ Facial Detection :
The system integrates advanced Face Detection and Face Capture functions with intelligent facial image search and acquisition of up to 4 simultaneous channels , optimizing access control and investigative analysis.
✅ Facial Recognition :
 Thanks to AI facial recognition , the DVR supports image comparison and face library management for intelligent subject identification, improving the safety and speed of video verification.
✅ Motion Detection 2.0 :
 Motion Detection 2.0 technology with human/vehicle classification uses deep learning algorithms to distinguish real movements from irrelevant events, increasing the accuracy and reliability of the security system.
✅ Video and Audio :
It supports H.265 Pro+ compression, 4K HDMI video output, HDTVI two-way audio and up to 16-channel synchronized playback, ensuring high audio-video performance and storage space optimization.
✅ Network :
 Equipped with RJ45 Gigabit Ethernet interface, it supports advanced protocols such as ONVIF, HTTPS, Hik-Connect, DDNS and iSCSI , allowing secure remote management and complete integration with professional IP infrastructures.
✅ Interfaces :
The DVR has 16 BNC video inputs , USB 3.0 ports, RS-485 interface, simultaneous HDMI/VGA outputs and 16 inputs / 4 outputs alarm configuration, ideal for integration with intrusion systems and security automations.
✅ 5in1 Technology :
 The 5in1 technology guarantees compatibility with HDTVI, AHD, CVI, CVBS and IP signals, offering maximum installation and upgrade flexibility without replacing the existing infrastructure.

Technical data sheet

iDS-7216HUHI-M2/XT/4A+16/4ALM
Perimeter Protection
Human/Vehicle Analysis Up to 16-ch (advanced model)
Facial Detection
Facial Detection and Capture Face picture detection, face picture search
4-ch face picture capture
Facial Recognition
Face Picture Library Up to 16 face picture libraries
HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash.
Facial Detection and Capture
(Captured from Camera)		 4-ch face picture comparison alarm (HD analog camera)
Motion Detection 2.0
Human/Vehicle Analysis Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;
Quick search by object or event type is supported;
Video and Audio
IP Video Input 16-ch (up to 32-ch), Up to 8 MP resolution
Analog Video Input 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDMI Output 1-ch, 4K (3840 × 2160)/30Hz,
2K (2560 × 1440)/60Hz,
1920 × 1080/60Hz,
1280 × 1024/60Hz,
1280 × 720/60Hz
HDMI/VGA simultaneous output
VGA Output 1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz,
1280 × 720/60Hz
HDMI/VGA simultaneous output
CVBS Input PAL/NTSC
CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Synchronous playback 16-ch
HDTVI Input 8 MP(3840 × 2160)@12/15 fps, 3K(2960 × 1665)@25/20 fps,3K(3328x1504)@20fps,2K(2304x1296)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30fps,1080P@25/30fps, 720P@25/30fps
AHD Input 5MP(2560×1944)@20fps, 4MP(2560×1440)@25/30fps,1080P@25/30fps, 720P@25/30fps
HDCVI Input 8 MP(3840 × 2160)@12/15 fps, 3K(2880 × 1620)@20/25 fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps, 1080P@25/30 fps, 720P@25/30fps
Audio Output 1-ch, RCA (Linear, 1 KΩ)
Audio Input 1-ch (up to 16-ch is optional), RCA (2.0 Vpp,1 KΩ), 16-ch via coaxial cable
Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Recording
Video Compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution Main stream:
8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
Substream:
WD1/4CIF/CIF@25 fps (P)/30 fps (N)
Video Bitrate 32 Kbps to 10 Mbps
Dual-stream Support main stream or sub stream
Stream Type Video, Video & Audio
Audio Compression G.711u
Audio Bitrate 64 Kbps
Decoding
Decoding Capability up to 24-ch 1080P@30fps
Network
Total Bandwidth 256 Mbps
Network Protocol TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
Remote Connection 128
Network Interface 1, RJ45 10/100/1000Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA 2 SATA interface
Capacity up to 12 TB capacity for each disk
Serial Interface RS-485 (half-duplex)
Alarm In/Out 16/4
USB Interface Front panel: 1 × USB 2.0;
Rear panel: 2 × USB 3.0
General
Power Supply 48 VDC, 5 A
Consumption ≤ 60 W
Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity 10 to 90%
Dimensions (W × D × H) 384 × 317 × 52 mm (15.1 × 12.5 × 2.0 inch)
Weight ≤ 2.1 kg (4.6 lb)
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
