38207.106.WH1 | RIPETITORE DEL SEGNALE RADIO WIRELESS CON SUPPORTO JEWELLER E WINGS

Il Ajax ReX 2 Jeweller, 38207.106.WH1, bianco è un avanzato estensore di portata radio progettato per ampliare la copertura dei sistemi Ajax e supportare la foto-verifica in modo rapido e sicuro. Grazie ai protocolli Jeweller e Wings e alle quattro antenne integrate, garantisce trasmissioni stabili di comandi, eventi e immagini fino a 1.700 m in campo aperto, anche in presenza di interferenze o tramite strutture in cemento e acciaio. Il dispositivo può commutare automaticamente tra radio ed Ethernet per mantenere la comunicazione attiva e protegge i dati con algoritmi di autenticazione e crittografia. Con una batteria di backup fino a 38 ore, installazione immediata tramite QR code e gestione remota via app Ajax, ReX 2 è ideale per grandi edifici e infrastrutture complesse che richiedono sicurezza e continuità operativa.
Specifiche principali:
- Doppio canale di trasmissione: radio Jeweller/Wings + Ethernet fino a 100 Mb/s
- Portata di comunicazione fino a 1.700 m in campo aperto
- Trasmissione foto MotionCam: 10–18 secondi secondo il canale utilizzato
- Consegna allarmi ultrarapida in 0,3 secondi
- Protezione anti-jamming e anti-manomissione del coperchio
- Autonomia di backup fino a 38 ore in caso di blackout
- Commutazione automatica tra canali in caso di perdita di segnale
- Installazione facile via QR code e configurazione da remoto tramite app Ajax
Ulteriori dettagli
ReX 2 garantisce tempi di risposta estremamente rapidi: 0,3 secondi per la trasmissione degli allarmi, fino a 18 secondi per l’invio foto via Wings e fino a 10 secondi tramite Ethernet. Questa velocità consente una gestione immediata degli eventi, mantenendo il sistema altamente reattivo anche con decine di dispositivi collegati.
Scheda tecnica
| 38207.106.WH1 | |
| Connection possibilities | |
| Number of ReX 2 Jeweller connected to the hub | 5 For all compatible hub models. |
| Number of devices connected to ReX 2 Jeweller | up to 199 Depends on the hub model. Only Hub 2 Plus Jeweller and Hub 2 (4G) Jeweller are under certification by UL. |
| Communication | |
| Jeweller communication technology | Proprietary wireless communication technology to transmit commands, alarms, and events. Key features:
|
| Radio frequency bands | 866.0 - 866.5 MHz 868.0 - 868.6 MHz 868.7 - 869.2 MHz 905.0 - 926.5 MHz 915.85 - 926.5 MHz 921.0 - 922.0 MHz Depence on the sales reagion |
| Maximum effective radiated power (ERP) | up to 20 mW Automatic power control to reduce power consumption and radio interference. |
| Radio signal modulation | GFSK |
| Wings communication range | Up to 1,700 m Up to 5,600 ft Between the range extender and a hub in an open space. |
| Encrypted radio communication | All the data stored and transmitted are protected by block encryption featuring a dynamic key. |
| Frequency hopping | To prevent radio interference and radio signal interception. |
| Wings communication technology | Proprietary wireless communication technology to transmit photo verifications. Key features:
|
| Radio frequency bands | 866.0 - 866.5 MHz 868.0 - 868.6 MHz 868.7 - 869.2 MHz 905.0 - 926.5 MHz 915.85 - 926.5 MHz 921.0 - 922.0 MHz Depence on the sales reagion |
| Radio signal range | Up to 1,700 m Up to 5,600 ft Between the hub and connected devices (in an open space). Maximum range depends on the connected device. |
| Encrypted radio communication | All the data stored and transmitted are protected by block encryption featuring a dynamic key. |
| Frequency hopping | To prevent radio interference and radio signal interception. |
| Ethernet | 1 8P8C socket (up to 100 Mbps) An alternative or main communication channel to transmit events, alarms, and photos. |
| Delivery time | |
| Alarm delivery time to the hub | 0.3s |
| Photo delivery time to the hub | 18 s Via ReX 2 Jeweller using the Wings channel. Delivery time depends on the settings. 10 s Via ReX 2 Jeweller using the Ethernet channel. Delivery time depends on the settings. |
| Recommendations | The device operating voltage is 110–240 V~. ReX 2 Jeweller is designed for indoor use only. |
| Sabotage protection | |
| Tamper alarm | Notifications on attempts to detach the device from the surface or remove it from the mounting panel. |
| Protection against spoofing | devices’ authentication |
| Communication loss detection | after 36 s Detection time depends on the Jeweller or Jeweller/Fibra settings. |
| Power Supply | |
| Main | 110–240 V~, 50/60 Hz Up to 6 W of mains power consumption. |
| Backup | built-in battery Li-ion 2 Аh Calculated battery life:
Rechargeable Li-ion Polymer Battery XK 953562T 3.7 V⎓, 2 Ah Calculated battery life:
|
| Manufacturer | Dongguan Lean Power UL listed. |
| Type | type A Power supply is used inside the supervised premises |
| Quiescent device’s current consumption at nominal voltage | 14.5 mA |
| Maximum device’s current consumption at nominal voltage | 95.8 mA |
| Low battery voltage | 3.7 V⎓ |
| Low battery recovery voltage | 4.1 V⎓ |
| End-of-life battery voltage | 3.6 V⎓ Device is switched off. |
| Minimum energy level for a backup battery in the charged state | 100% |
| Alternative | 6 V⎓ Connected via an alternative power supply unit* 6V PSU for Hub 2/Hub 2 Plus/ReX 2 which is sold separately. 12 or 24 V⎓ Connected via an alternative power supply unit* 12–24V PSU for Hub 2/Hub 2 Plus/ReX 2 which is sold separately. |
| Enclosure | |
| Color | White |
| DImension | 163 × 163 × 36 mm 6.42″ × 6.42″ × 1.42″ |
| Weight | 410 g 14.46 oz |
| Operating temperature range | from −10°C to +40°C from 14°F to 104°F Temperature range from 32 °F (0 °C) to 120 °F (+49 °C) is certified according to UL/ULC standards. |
| Operating humidity | up to 75% Humidity of up to 93% is certified according to UL/ULC standards. |
| Casing protection class | IP20 |
| Complete set | ReX 2 Jeweller SmartBracket mounting panel Power cable Screw terminal block Adapter (only for INCERT compliance) Ethernet cable Installation kit Quick start guide |
| Warranty | 24 months |
