149624.263.WH1 | CENTRALE WIRELESS CON SUPPORTO DELLA FOTO-VERIFICA - COLLEGABILE TRAMITE WI-FI, ETHERNET E DUE SCHEDE SIM (2G/3G/LTE)
>> IN REGALO CARTELLO ADESIVO AJAX

Il Ajax Hub BP Jeweller, 149624.263.WH1, bianco è una centrale d’allarme wireless progettata per garantire sicurezza continua anche in siti remoti senza alimentazione elettrica, grazie al funzionamento a batteria e ai protocolli criptati Jeweller e Wings che assicurano consegna immediata di allarmi e foto. Con un raggio di comunicazione fino a 2.000 m in spazio aperto, doppio slot SIM 2G/3G/LTE e avanzata protezione anti-jamming, offre affidabilità professionale in ogni condizione. La modalità Battery Saver estende l’autonomia per mesi, mantenendo monitoraggio costante, autenticazione dispositivi e invio eventi istantaneo. Ideale per installazioni dove continuità e prestazioni sono fondamentali.
Specifiche principali:
- Comunicazione radio sicura e criptata con protocolli Jeweller e Wings
- Raggio operativo fino a 2.000 m in spazio aperto
- Doppio slot micro SIM (2G/3G/LTE) per continuità di rete
- Notifiche di allarme, jamming e prime foto in circa 9 secondi
- Modalità Battery Saver con autonomia fino a 23 mesi (batterie NB)
- Supporto fino a 100 dispositivi, 50 utenti e 50 stanze
- Installazione semplice, funzionamento stabile senza alimentazione esterna
Ulteriori dettagli
Il controllo avviene tramite doppio slot per SIM 2G/3G/LTE, garantendo ridondanza e continuità di rete anche in zone con copertura instabile. Il sistema può inoltre utilizzare un’antenna esterna per potenziare la ricezione e assicurare sempre un canale attivo verso la centrale di monitoraggio (CMS).
Scheda tecnica
| 149624.263.WH1 | |
| Capacity | |
| Wireless Ajax devices | up to 100 Specifically, up to 10 sirens or keypads with a built-in siren and up to 5 range extenders. |
| Ajax NVRs | up to 36 |
| Ajax cameras | up to 224 via Ajax NVRs and up to 492 standalone |
| Third-party IP cameras | up to 10 when using RTSP via SDK up to 224 when using ONVIF via Ajax NVRs |
| Users | up to 50
|
| Automation scenarios | up to 32
|
| Security groups | up to 9 |
| Rooms | up to 50 |
| Event log | up to 1,000 events Events are saved on the non-volatile onboard flash memory. |
| Wireless communication | |
| Jeweller communication technology | Proprietary wireless communication technology to transmit commands, alarms, and events. Key features:
|
| Radio frequency bands | 866.0 - 866.5 MHz 868.0 - 868.6 MHz 868.7 - 869.2 MHz 905.0 - 926.5 MHz 915.85 - 926.5 MHz 921.0 - 922.0 MHz Depence on the sales reagion |
| Maximum effective radiated power (ERP) | < 25 mW Featured automatic power control to reduce power consumption and noise interference. |
| Radio signal modulation | GFSK |
| Wings communication range | Up to 2.000 m Up to 6,500 ft Between the hub and connected devices (in an open space). Maximum range depends on the connected device. |
| Polling interval | from 12 to 300 s Adjusted by PRO or user with admin rights in the Ajax apps. |
| Encrypted radio communication | All the data stored and transmitted are protected by block encryption featuring a dynamic key. |
| Radio frequency hopping | To prevent radio interference and radio signal interception. |
| Wings communication technology | Proprietary wireless communication technology to transmit photo verifications. Key features:
|
| Radio frequency bands | 866.0 - 866.5 MHz 868.0 - 868.6 MHz 868.7 - 869.2 MHz 905.0 - 926.5 MHz 915.85 - 926.5 MHz 921.0 - 922.0 MHz Depence on the sales reagion |
| Maximum effective radiated power (ERP) | < 25 mW Featured automatic power control to reduce power consumption and noise interference. |
| Radio signal modulation | GFSK |
| Radio signal range | Up to 2.000 m Up to 6,500 ft Between the hub and connected devices (in an open space). Maximum range depends on the connected device. |
| Encrypted radio communication | All the data stored and transmitted are protected by block encryption featuring a dynamic key. |
| Radio frequency hopping | To prevent radio interference and radio signal interception. |
| Recommendations | Hub BP Jeweller is designed for indoor use only. |
| Communication channels | |
| Cellular | 2 micro-SIM slot |
| Cellular bands | 2G GSM900/DCS1800 (B3/B8) 3G WCDMA 850/900/2100 (B1/B5/B8) 4G (LTE) FDD B1/B3/B5/B7/B8/B20 |
| Automatic switching between communication channels | between SIM cards — up to 4 minutes |
| Communication channels prioritization | 1. Micro SIM slot 1 2. Micro SIM slot 2 |
| Auto APN | The APN auto select feature allows setting access point automatically based on the installed SIM card. |
| External antenna connectors | Jeweller Wings 4G (LTE) The system will notify of the damaged antenna. Ajax ExternalAntenna is sold separately. |
| Alarm transmission system categories | SP5 |
| Control panel operation method | pass-through |
| Signaling security | S2 Substitution security. |
| Information security | I2 |
| Notifications | |
| Supported notification types |
|
| Event types |
|
| Photo verification | |
| Photo verification types |
|
| Photo delivery time | up to 9 s by default. |
| Photo resolution | up to 640 × 480 pixels Depends on the detector. |
| Number of photos in a series: | from 1 to 5 pictures |
| Monitoring | |
| Supported protocols |
|
| Event types |
|
| Power Supply | |
| External | 4.2–16 V⎓, up to 2 A Zinc-air battery or external power source. |
| Internal | 4.2–16 V⎓, up to 2 A Rechargeable lead-acid and LiFePO4 batteries (not included). Non-rechargeable LTC batteries (not included). |
| Device operating DC voltage range | 3.5–16 V⎓ |
| Autonomous operation | |
| On external battery in full function mode | up to 18 months On a 12 V⎓, 600 Ah, zinc-air non-rechargeable external battery (not included). |
| On external battery in Battery saving mode | more than 5 years On a 12 V⎓, 600 Ah, zinc-air non-rechargeable external battery (not included). |
| On internal battery in a Battery saving mode | up to 17 months On a 7.2 V⎓, 95 Ah, LTC non-rechargeable Internal battery NB (7.2V/95Ah) (not included). up to 4 months On a 6.4 V⎓, 27 Ah, LiFePO4 rechargeable Internal battery RB (6.4V/27Ah) (not included). up to 2 months On a 12 V⎓, 7 Ah, lead-acid rechargeable internal battery (not included). |
| Sabotage protection | |
| Tamper alarm | Notifications on attempts to detach the device from the surface or remove it from the mounting panel. |
| Protection against spoofing | devices’ authentication |
| Frequency hopping | The hub sends notifications to all users and the security company of jamming or losing connection with the devices. |
| Jamming alert | Hub BP Jeweller analyzes the channel’s noise level and the quality of communication with added devices and sends an alert in 30 seconds. |
| Enclosure | |
| Color | White |
| DImension | 196 × 238 × 100 mm 7.72″ × 9.37″ × 3.94″ |
| Weight | 1,010 g 5.63 oz |
| Operating temperature range | from −10°C to +40°C from 14°F to 104°F |
| Operating humidity | up to 75% |
| Casing protection class | IP40 |
| Complete set | Hub BP Jeweller Casing Installation kit Quick start guide |
| Warranty | 24 months |
