CS4210-8GT | SWITCH DI RETE CLOUD MANAGED 10 PORTE

Lo switch cloud gestito Dahua CS4210-8GT con 10 porte (8 Gigabit RJ-45 e 2 SFP uplink) offre prestazioni elevate e affidabilità per reti aziendali e sistemi di sicurezza. Grazie alla piattaforma DoLynk Care, consente gestione da remoto, monitoraggio in tempo reale e notifiche immediate. Con una capacità di commutazione di 20 Gbps, buffer avanzato e funzioni come VLAN, STP e link aggregation, garantisce stabilità e continuità di servizio anche con grandi flussi di dati. Il design fanless in metallo assicura lunga durata, silenziosità e resistenza a sovratensioni, scariche e condizioni ambientali estreme.
Specifiche principali:
- 10 porte totali: 8 RJ-45 Gigabit + 2 SFP uplink
- Gestione cloud tramite app DoLynk Care
- Network topology con protocollo LLDP
- Switching capacity 20 Gbps e forwarding rate 14.88 Mpps
- Supporto VLAN, STP/RSTP e link aggregation
- Design fanless in metallo con protezioni integrate
Ulteriori dettagli
Scheda tecnica
| CS4210-8GT | |
| Basic | |
| Layer | Layer 2 |
| Switching Capacity | 20 Gbps |
| Packet Forwarding Rate | 14.88 Mpps |
| Description of Function Slots | Port 1-8: 8 × RJ45 10/100/1000 Mbps; Port 9-10: 2 × SFP 1000 Mbps (uplink) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity | 5%–95% (RH), non-condensing |
| Storage Temperature | –40 °C to +70 °C (–40 °F to +158 °F) |
| Storage Humidity | 5%–95% (RH), non-condensing |
| Power Supply | External power supply: 12 VDC, 1.5 A |
| Power Consumption | Idling: ≤2.5 W Full load: 6 W |
| Statics Protection | Air discharge: 8 kV; Contact discharge: 6 kV |
| Lightning Protection | Common mode: 4 kV Differential mode: 2 kV |
| Net Weight | 0.55 kg (1.21 lb) |
| Gross Weight | 1.3 kg (2.87 lb) |
| Product Dimensions | 190 mm × 106 mm × 30 mm (7.48" × 4.17" × 1.18") (L × W × H) |
| Packaging Dimensions | 256 mm × 244 mm × 87 mm (10.07" × 9.61" × 3.43") (L × W × H) |
| Casing Material | Sheet metal |
| Installation | Desktop mount; wall mount |
| Hardware | |
| Reset Button | 1 |
| Performance | |
| MTBF | 222.36 years |
| Packet Buffer Size | 4 Mbit |
| Jumbo Frame | 15K Byte |
| MAC Table Size | 8K |
| Communication Standard | IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3az IEEE 802.3ab IEEE 802.3ad |
| VLAN Number | 32 |
| Feature | |
| Ethernet Loop Protection | STP; RSTP |
| VLAN Function | IEEE 802.1Q VLAN |
| Link Aggregation | Static Aggregation |
| Port Feature | IEEE 802.3x Flow Control Unknown Unicast Suppression Multicast Storm Control Broadcast Storm Control MAC+Port Binding Loop Prevention |
| Mirror | N:1 Mirroring Local Port Mirroring |
| Reliability | LLDP |
| DHCP Function | DHCP Client |
| Security | Port Isolation |
| Equipment Management | Web Management Cloud Management Logs Fault Alarm |
| General | |
| Packing List | 1 × Quick Start Guide 1 × Legal and Regulatory Information 1 × Power Adapter 1 × Power Cord |
