Dahua CS4210-8GT 10-Port Gigabit Cloud Managed Switch for Business Networks

Dahua CS4210-8GT 10-Port Gigabit Cloud Managed Switch for Business Networks

-57% New

CS4210-8GT - The 10-port cloud switch (8 Gigabit RJ-45 and 2 SFP uplinks) offers high performance for enterprise networks and security systems. Thanks to the DoLynk Care platform, it allows remote monitoring, real-time notifications and advanced network topology management. With a switching capacity of 20 Gbps and a packet forwarding rate of 14.88 Mpps , it guarantees stability even with large traffic volumes. The fanless metal design ensures long life, protection against surges and resistance to temperatures from -10°C to +55°C, ideal for offices, hotels, shops and SMEs. Dahua

Technical Data Sheet

Reference: CS4210-8GT

Brand: Dahua

EAN: 6923172566232

Manufacturer Object ( [id] => 13 [name] => Dahua [description] =>

The Asian Company, born in 2001, is famous because of the excellent quality of its product in terms of performances and potential.

The range of products made by Dahua includes not only classic CCTV systems but also more complex and articulate systems: not only video surveillance, indeed, but also access control, video intercoms, thermal cameras and much more.

The reliability, the cutting-edge technologies and the competitive prices offered by Dahua are only some of the reasons why Setik has always chosen to distribute this brand. Dahua has been for years a reference point in the international CCTV market, due to the huge investments dedicated every year to Research and Development. Numbers are clear: since 2016, Dahua has registered more than 800 patents with its own brand.

The Dahua-branded products sold by Setik Srl could eventually be delivered as OEM: this means that the items are absolutely original and made by Dahua, but characterized by a different aesthetic look reserved for the online market (generally as far as the logo and the package are regarded).

This has no effects on the warranty and on the technical specifications nor even on the possible updates and functionalities, because the products are authentic Dahua’s ones.

[short_description] =>

Videosorveglianza Dahua

Zhejiang Dahua Technology Co., Ltd. is one of the leading solution providers in video surveillance industry, with more than 13,000 employees and 35 active branches all over the world.

[id_address] => [date_add] => 2012-07-14 17:53:54 [date_upd] => 2025-06-24 15:40:21 [link_rewrite] => dahua [meta_title] => Best Dahua Products: DVR, HCVR,NVR, IPC,SD,PTZ,HDCVI, [meta_keywords] => dahua, dahuatech, dahua distribution, dahua national supplier [meta_description] => Dahua, TVCC manufacturer, IP, Analogue and SDI,HD-CVI [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

CS4210-8GT | 10-PORT CLOUD-MANAGED NETWORK SWITCH


Dahua

The Dahua CS4210-8GT 10-port managed cloud switch (8 Gigabit RJ-45 and 2 SFP uplinks) offers high performance and reliability for enterprise networks and security systems. Featuring the DoLynk Care platform, it enables remote management, real-time monitoring, and instant notifications. With a 20 Gbps switching capacity, advanced buffering, and features such as VLAN, STP, and link aggregation, it ensures stability and service continuity even with large data flows. The fanless metal design ensures long life, quiet operation, and resistance to surges, discharges, and extreme environmental conditions .

Main specifications:

- 10 total ports: 8 RJ-45 Gigabit + 2 SFP uplink

- Cloud management via DoLynk Care app

- Network topology with LLDP protocol

- Switching capacity 20 Gbps and forwarding rate 14.88 Mpps

- VLAN, STP/RSTP and link aggregation support

- Fanless metal design with integrated guards

Further details

Number of doors:
The switch integrates 10 total ports , including 8 RJ-45 Gigabit ports for high-speed connections and 2 SFP uplink ports at 1000 Mbps. This configuration guarantees flexibility and stability for corporate networks and security systems .
Cloud Management :
Through the DoLynk Care platform, it enables remote network management, with real-time monitoring, error notifications, and the ability to intervene immediately. This is a significant advantage for companies requiring constant monitoring.
Network Topology:
It supports the LLDP protocol , automatically generating and displaying the network topology. This allows you to quickly identify faults or anomalies and perform maintenance operations quickly and easily .
Switching capacity :
With a switching capacity of 20 Gbps and a packet forwarding rate of 14.88 Mpps , the switch ensures high performance, even in the presence of large data flows, keeping the entire infrastructure stable.

Technical data sheet

CS4210-8GT
Basic
Layer Layer 2
Switching Capacity 20 Gbps
Packet Forwarding Rate 14.88 Mpps
Description of Function Slots Port 1-8: 8 × RJ45 10/100/1000 Mbps; Port 9-10: 2 × SFP 1000 Mbps (uplink)
Operating Temperature –10 °C to +55 °C (+14 °F to +131 °F)
Operating Humidity 5%–95% (RH), non-condensing
Storage Temperature –40 °C to +70 °C (–40 °F to +158 °F)
Storage Humidity 5%–95% (RH), non-condensing
Power Supply External power supply: 12 VDC, 1.5 A
Power Consumption Idling: ≤2.5W
Full load: 6 W
Statics Protection Air discharge: 8 kV;
Contact discharge: 6 kV
Lightning Protection Common mode: 4 kV
Differential mode: 2 kV
Net Weight 0.55 kg (1.21 lb)
Gross Weight 1.3 kg (2.87 lb)
Product Dimensions 190 mm × 106 mm × 30 mm (7.48" × 4.17" × 1.18") (L × W × H)
Packaging Dimensions 256 mm × 244 mm × 87 mm (10.07" × 9.61" × 3.43") (L × W × H)
Casing Material Sheet metal
Installation Desktop mount; wall mount
Hardware
Reset Button 1
Performance
MTBF 222.36 years
Packet Buffer Size 4 Mbit
Jumbo Frame 15K Bytes
MAC Table Size 8K
Communication Standard IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3az
IEEE 802.3ab
IEEE 802.3ad
VLAN Number 32
Feature
Ethernet Loop Protection STP; RSTP
VLAN Function IEEE 802.1Q VLAN
Link Aggregation Static Aggregation
Port Feature IEEE 802.3x Flow Control
Unknown Unicast Suppression
Multicast Storm Control
Broadcast Storm Control
MAC+Port Binding
Loop Prevention
Mirror N:1 Mirroring
Local Port Mirroring
Reliability LLDP
DHCP Function DHCP Client
Security Port Isolation
Equipment Management Web Management
Cloud Management
Logs
Fault Alarm
General
Packing List 1 × Quick Start Guide
1 × Legal and Regulatory Information
1 × Power Adapter
1 × Power Cord
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
