DAHUA ALARM KIT - WIFI - 868MHz FREQUENCY - ART-ARC3000H-03-FW2-868


FREE DAHUA CARBON MONOXIDE! CODE: DAHUA-GIFT


FREE DAHUA ADHESIVE SIGN

WHAT DOES THIS KIT INCLUDE?
-
1x ARC3000H-FW2-868 Alarm HUB
- 1x Radio control ARA24-W2-868
- 1x Magnetic door contact ARD323-W2-868
- 1x ARD1233-W2-868 PIR sensor
>> 1x Dahua Adhesive Sign | Gift! <<



SUPER GIFT | 1x DAHUA PROTECTED AREA ADHESIVE SIGN

DAHUA Customized Intrusion Detection System Protected Area Adhesive Sign
Durable and with customizable text. Dimensions: A5 21 x 14.8 cm.

Wireless Alarm Hub - 868MHz Dahua ARC3000H-FW2-868

Postazione esterna dahua ARC3000H-FW2-868

1x Alarm Hub - Wireless - 868MHz - 2.4GHz - Up to 150 Devices - ARC3000H-FW2-868

Alarm Control Panel - Dahua
> Wired, wireless, 4G/3G, GPRS mode
> Wi-Fi frequency: 2.4Ghz
> Alarm notifications via call or SMS (up to 5 numbers can be registered)
> Status display (battery level, signal strength, temperature, program version)
> Supports up to 150 devices (including 6 sirens and 64 keyfobs)
> ANR: Automatic Network Replenishment
> Low battery alarm
> LAN RJ45 100M
> Tamper
> Video Linkage on App
> Cloud Update
> Communication distance up to 2,000m in open field without obstacles
> Operating temperature: –10 °C to +50 °C
> Power supply: 12 V DC, 1.5 A
> Net weight: 0.38Kg
> For desk or wall mounting
> Dimensions: 163.0mm × 163.0mm × 32.0mm

1X Dahua 4-Button Remote Control - ARA24-W2-868

ARA24-W2-868

1x 4-Button Remote Control - ARA24-W2-868

> Dahua Wireless Keypad
> Two-way wireless communication protocol: 868MHz frequency
>
Operating status indicator (green for normal, red for abnormal)
> Coverage up to 900 meters in open space
> 4 buttons (Home, Away, Disarm, SOS)
> SOS emergency alarm (via dedicated button)
> Built-in tamper switch
> Power supply: CR2032 batteries
> Average battery life: 5 years
> Net weight: 20g
> Dimensions: 60.0mm × 39.5mm × 15.0mm
> Supported operating temperature: –10 °C to +55 °C
> Housing material: Polycarbonate and ABS

1X Magnetic Door Contact - Wireless - ARD323-W2-868
ARD323-W2-868

1x Dahua 868MHz Wireless Door/Window Alarm Sensor Contact . ARD323-W2-868

> Two-Way Wireless Door/Window Contact - Dahua
> 868MHz two-way wireless communication protocol
Transmission up to 1,200m (in open space, without obstacles)
> Tamper sabotage
> Power button (Power on/off)
> Alarm indicator light (green)
> Encryption: AES128
> Power supply: 1 CR123A battery
> Material: Polycarbonate and ABS
> Appearance: white color
> Reed Switch Sensor
> Temperature measurement: –15 °C to +65 °C
> Operating temperature: –10 °C to +55 °C
> Item weight (net): 70g
> Dimensions: 100.2mm × 20.8mm × 20.3mm
> Relative humidity: 10%–90%

1X
Wireless PIR Detector - Pet Immune - ARD1233-W2-868
ARD1233-W2-868

1x PIR Detector - 12M Range - Two-Way Wireless 868MHz - PET IMMUNE Dahua . ARD1233-W2-868

> Wireless PIR Detector - Dahua
> 868Mhz two-way wireless communication frequency
> Distance up to 1,600m in open field without obstacles
> Detection range 12m
> Pet Immune (immune to pet detection)
> Frequency Hopping
> Powered by CR132A battery
> Average battery life 4 years
> Low battery alarm
> Alarm indicator light (green)
> Power button
> AES128 encryption
> 3 adjustable detection sensitivity levels
> Dimensions: 104.0mm × 60.0mm × 50.0mm
> Net weight of the item: 100g
> Appearance: white color
> Manufacturing material: Polycarbonate and ABS
> Operating temperature: –10 °C to +55 °C

Technical data sheet

Model ART-ARC3000H-03-FW2-868
Wireless Protection Zone Hub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs)
Buzzer Hub: Built-in
Button Hub: 1 × reset, 1 × power, 1 × AP Keyfob: 4 (Home, Away, Disarm, and SOS) Door Detector: 1 × power button PIR Detector: 1 × power button
Indicator Light Hub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction) Keyfob: 1 × two-color status indicator (green: normal, red: abnormal) Door Detector: 1 × green alarm indicator PIR Detector: 1 × green alarm indicator
Storage battery Hub: Built-in lithium battery
Network Mode Single SIM (GSM:900/1800 MHz, WCDMA:B1/B5/B8, LTE-FDD:B1/B3/B5/B7/B8/B20, LTE-TDD:B38/B40/B41); dual SIM single standby
Network Port Hub: 1 × RJ-45 10M/100M Ethernet port
Network Protocol Hub: TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP
Offline Cache Hub: Max. 50 entries (ANR)
Power Failure Protection for Configured Parameters Hub: Yes
Remote Update All: Cloud update
Video Linkage Hub: Yes
SMS Hub: Yes (up to 5 phone numbers)
Phone Call Hub: Yes (up to 5 phone numbers)
Low Battery Alarm All: Yes
Tamper Alarm Hub: Yes Door Detector: Yes PIR Detector: Yes
User Management Hub: Share function for App users
Search Hub: Searching push messages, device status, and program version. Detecting signal strength. Keyfob: Signal strength detection Door Detector: Signal strength detection PIR Detector: Signal strength detection
Arm and Disarm Hub: App; keyfob; schedule
Carrier Frequency All: 868.0 MHz–868.6 MHz
Communication Distance Hub: Up to 2,000 m (6,561.68 ft) in an open space Keyfob: Up to 900 m (2,952.76 ft) in an open space Door Detector: Up to 1,200 m (3,937.01 ft) in an open space PIR Detector: Up to 1,600 m (5,249.34 ft) in an open space
Communication Mechanism All: Two-way
Encryption Mode All: AES128
Frequency Hopping All: Yes
Wi-Fi Hub: 2.4G
External Zone Door Detector: 1-channel dry contact input
Measuring Range (Temperature) Door Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor) PIR Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor)
Measuring Precision (Temperature) Door Detector: ± 1 °C (± 33.8 °F) PIR Detector: ± 1 °C (± 33.8 °F)
Resolution (Temperature) Door Detector: 1 °C (33.8 °F) PIR Detector: 1 °C (33.8 °F)
Sensor Door Detector: Reed switch PIR Detector: Dual elements low-noise PIR sensor
Test Mode Door Detector: Yes PIR Detector: Yes
Scenario Door Detector: Non-metal doors
Movement Distance Door Detector: < 40 mm (1.57")
Detection Mode PIR Detector: PIR
Detection Range PIR Detector: 12 m (39.37 ft) (90°) with installation height of 2.2 m (7.21 ft)
Detection Speed PIR Detector: 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s)
Pet Immunity Level PIR Detector: ≤ 18 kg (39.68 lb)
White Light Resistance Level PIR Detector: 6500 lx
Two-way Digital Temperature Compensation PIR Detector: Yes, no attenuation of detection distance in high temperature
Sensitivity PIR Detector: 3 levels adjustable
Power Supply Hub: 12 V DC, 1.5 A (Europe, UK and USA power adapters are optional) Keyfob: CR2032 battery Door Detector: CR123A battery PIR Detector: CR123A battery
Battery Life Hub: Storage battery standby for 12 Hours Keyfob: 5 years Door Detector: 5 years PIR Detector: 4 years
Power Consumption Keyfob: Max. 100 mW Door Detector: Max. 125 mW PIR Detector: Max. 120 mW
Operating environment Hub: –10 °C to +50 °C (+14 °F to +122 °F) (indoor) Keyfob: –10 °C to +55 °C (+14 °F to +131 °F) (indoor) Door Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor) PIR Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
Operating Humidity All: 10%–90% (RH)
Product Dimensions Hub: 163.0 mm × 163.0 mm × 32.0 mm (6.42"" × 6.42"" × 1.26"") (L × W × H) Keyfob: 60.0 mm × 39.5 mm × 15.0 mm (2.36"" × 1.56"" × 0.59"") (L × W × H) Door Detector: 100.2 mm × 20.8 mm × 20.3 mm (3.94"" × 0.82"" × 0.80"") (L × W × H) PIR Detector: 104.0 mm × 60.0 mm × 50.0 mm (4.09"" × 2.36"" × 1.97"") (L × W × H)
Packaging Dimensions Hub: 219.0 mm × 187.0 mm × 91.0 mm (8.62"" × 7.36"" × 3.58"") (L × W × H) Keyfob: 135.0 mm × 98.5 mm × 27.8 mm (5.31"" × 3.88"" × 1.09"") (L × W × H) Door Detector: 135.0 mm × 98.5 mm × 27.8 mm (5.31"" × 3.88"" × 1.09"") (L × W × H) PIR Detector: 135.0 mm × 98.5 mm × 56.8 mm (5.31"" × 3.88"" × 2.24"") (L × W × H)
Installation Hub: Wall mount; Desktop Door Detector: Bracket mount PIR Detector: Wall mount
Net Weight Hub: 0.38 Kg (0.84 lb) Keyfob: 20 g (0.04 lb) Door Detector: 70 g (0.15 lb) PIR Detector: 100 g (0.22 lb)
Gross Weight Hub: 0.8 Kg (1.76 lb) Keyfob: 65 g (0.14 lb) Door Detector: 115 g (0.25 lb) PIR Detector: 170 g (0.37 lb)
Casing All: PC + ABS
Certifications All: CE
