IMOU N118W 18 Channel Wi-Fi NVR with Bidirectional Audio, Wi-Fi 6 and 4K H.265 Recording

IMOU N118W 18 Channel Wi-Fi NVR with Bidirectional Audio, Wi-Fi 6 and 4K H.265 Recording

 
HDD space calculation
-10% Neu

NVR-N118W-8A0E-P-IMOU - The IMOU N118W Wi-Fi network video recorder supports up to 18 channels for advanced video surveillance management. Thanks to dual-band Wi-Fi 6 with 4 high-power antennas, it ensures stable and fast coverage in any environment. It offers resolution up to 4K H.265 for ultra-clear and smooth images, with low bandwidth consumption. With a built-in microphone and speaker, it allows two-way audio without additional devices, ideal for remote control. The HDMI/VGA and USB interfaces ensure wide compatibility, while storage up to 16TB guarantees safe and long-term storage. Compatibility with Onvif and the IMOU app complete the package, for simple and smart control from anywhere. Imou


Technical Data Sheet

Artikel-Nr.: NVR-N118W-8A0E-P-IMOU

Marke: IMOU

EAN: 6937479640120

Manufacturer Object ( [id] => 41 [name] => IMOU [description] =>

Imou verwendet intelligente und leicht zu bedienende Technologien, die für die Sicherheit von Haushalten sowie kleinen und mittleren Unternehmen geschaffen wurden. Alle Systeme sind mit Alexa und Google Home kompatibel. Bitten Sie das Gerät einfach, die Bilder zu zeigen, um immer unter Kontrolle zu haben, was uns am meisten am Herzen liegt.

[short_description] =>


Imou wurde mit dem Ziel gegründet, intelligente Lösungen anzubieten, die es jedem ermöglichen, ein komfortableres und sichereres Leben zu führen und den Alltag der Verbraucher zu vereinfachen, wie der offizielle Slogan "Enjoy Smart Life" verdeutlicht.

[id_address] => [date_add] => 2020-01-14 16:31:52 [date_upd] => 2025-07-23 14:59:46 [link_rewrite] => imou [meta_title] => Imou [meta_keywords] => imou [meta_description] => Imou wurde mit dem Ziel gegründet, intelligente Lösungen anzubieten, die es jedem ermöglichen, ein komfortableres und sichereres Leben zu führen und den Alltag der Verbraucher zu vereinfachen [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 26 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
INSTALLATEUR FINDEN

TOTALER AUSVERKAUF ×

 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

NVR-N118W-8A0E-P-IMOU | NVR 18 CHANNELS DUAL-BAND WI-FI 6 8MP



The IMOU N118W Wi-Fi network video recorder offers advanced security management with support for up to 18 channels, ideal for professional and home systems . Thanks to dual-band Wi-Fi 6 with 4 high-power antennas, it ensures a stable and fast connection in any environment. With resolution up to 4K H.265, clear and smooth images are guaranteed while reducing bandwidth use. The device integrates a microphone and speaker for two-way audio, HDMI/VGA outputs, USB ports, Onvif compatibility and storage up to 16TB, offering maximum flexibility and reliability.

Main specifications:

- Supports up to 18 channels with Ethernet/Wi-Fi connection

- Maximum resolution 4K H.265 for high quality images

- Dual-band Wi-Fi 6 (2.4/5GHz) with 4 high-power antennas

- Built-in microphone and speaker for two-way audio

- HDMI, VGA and USB interfaces for wide compatibility

- Storage up to 16TB with USB backup support

Further details


✅ Number of Channels:
It supports up to 18 channels , allowing complete management of multiple IP cameras connected both via wired and wireless mode.
✅ Maximum Resolution:
Compatible with H.265/H.264 codec, it offers video quality up to 4K UHD , minimizing bandwidth and storage space consumption.

✅ Network:
It includes a 10/100 Mbps RJ-45 Ethernet port and supports wired and wireless networks, ensuring stability and reliability in data transmission.

✅ Dual-Band:
With Wi-Fi 6 (2.4GHz/5GHz) technology and 4 high-power antennas, it ensures strong signal, extended coverage and fast connections.
✅ Microphone and Speaker:
Integrated to enable real-time two-way audio , ideal for intercom and remote control without external devices.
✅ Interfaces:
Equipped with HDMI and VGA outputs , 2 USB ports , microphone input, speaker output and reset button, for complete compatibility with monitors and peripherals.
✅ Storage:
It supports up to 16TB SATA HDD and USB Flash Drive backup, ensuring long-term data preservation and safety.

✅ Secure Storage with Imou Cloud:
With Imou Cloud , all your videos are protected and accessible online . You can choose between recording to the cloud or to a microSD card (up to 256GB), for flexible recording management.
Buy your 7-day IMOU PROTECT BASIC subscription or your 30-day IMOU PROTECT PRO subscription

NVR-N110W-8A0E-P-IMOU dimensions

Technical data sheet

NVR-N118W-8A0E-P-IMOU
Video & Audio
Access Channel 18 channels
Network Bandwidth 90Mbps
Playback Decoding 4-channel 8MP@15fps
4-ch 5MP@30fps
Video Compression H.265/H.264
Audio Compression AAC
Backup File Format MP4
Live Display 1,4,8,9,10
Network
Wired Network 1, RJ-45 10/100Mbps self-adaptive Ethernet interface
Wi-Fi Network IEEE802.11b/g/n/ax, Wi-Fi 6.2.4GHz＆5GHz
Compatible APP IMOU APP (IOS＆Android)
Third Party Agreement Onvif
External Interface
Video Output 1*VGA＆1*HDMI
Audio Input 1*Microphone(Built-in)
Audio Output 1*Speaker(Built-in)
USB Interface 2*USB
Reset Button Yes
Network Interface 1 RJ–45 port (10/100 Mbps)
Special Features
IPC Connection Automatically connect to IMOU cameras
Smart Detection Motion / Person / Vehicle
Remote Upgrade Yes
Sound Channel Two-Way Audio
Storage
Hard Drive Capacity 1 SATA port, up to 16 TB
Backup Media USB Flash Drive
External Interface
Power Supply DC 12V 2A
Power Consumption ＜9W (with HDD Average Power)
＜19W (with HDD Peak Power)
Working Temperature -10℃~+45℃
Working Humidity Less Than 95%RH
Dimensions (L×W×H) 241.5mm×260mm×60.2mm (Folded antenna)
Bare Weight 890g (Without HDD)
Certification THERE IS
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
