PFM886-15 | OUTDOOR LONG RAGE 5G WIRELESS BRIDGE

Dahua

The Dahua PFM886-15 is a long-range 5GHz outdoor wireless bridge, ideal for professional applications such as video surveillance, industrial networks, and point-to-point connections. Equipped with 802.11ac MIMO technology, it offers speeds of up to 867 Mbps and a range of up to 15 km, ensuring stable and reliable transmission even in complex environments. It supports TDMA to optimize bandwidth and five operating modes for maximum flexibility (Access Point, Client, WDS AP, WDS Client, Repeater). Thanks to the IP66 waterproof and UV-resistant housing and PoE power supply, it ensures durability and easy installation in any conditions.

Main specifications:

- Wireless speed up to 867 Mbps and maximum range of 15 km

- TDMA technology for efficient multi-point transmissions

- 5 operating modes: AP, Client, WDS AP, WDS Client, Repeater

- 23 dBi directional antenna and 27 dBm output power

- IP66 water and UV resistant construction

- PoE power supply for quick and safe installation

Further details

✅ Wireless Features:
The PFM886-15 uses a high-performance 802.11ac MIMO chip , capable of ensuring stable, reliable and high-speed connections. It operates in the 5GHz band (5745–5825 MHz) , extendable from 4920 to 6100 MHz , for greater flexibility and reduced interference. With a built-in 23 dBi antenna and transmission power up to 27 dBm , it ensures coverage of up to 15 km even in complex terrain. TDMA (Time Division Multiple Access) technology optimizes bandwidth and enables smooth and continuous point-to-multipoint transmission.
✅ Hardware :
Designed for outdoor environments, the device features a waterproof and UV-resistant housing with an IP66 rating , ensuring stable operation even in extreme weather conditions. It is powered via PoE (Power over Ethernet) , simplifying installation and reducing wiring costs. It has a Gigabit RJ45 port , 3 LED indicators for signal quality , and low power consumption ( ≤25W ). Its compact design (240×Ø373 mm, 0.94 kg) allows for convenient and safe mounting.
✅ Software:
The system integrates advanced security features with 802.1x/WPA-PSK/WPA2-PSK encryption , IP/MAC filtering and SSID masking . It supports Access Point, Client, WDS AP, WDS Client and Repeater operating modes, offering wide configuration flexibility. It is compatible with the main network protocols ( TCP/UDP/HTTP/NTP/DHCP ) and has professional management tools such as SNMP, Telnet, Syslog, NTP and Access Controller . The intuitive web interface and the ability to remotely upgrade the firmware facilitate maintenance and continuous performance optimization.

Technical data sheet

Model PFM886-15
Wireless Features
Wireless Standard IEEE802.11 a/n/ac
Working Frequency 5745~5825MHz (support frequency to extend, extended range: 4920~6100MHz)
Wireless Speed 867Mbps
Modulation Mode OFDM
Antenna 23dBi
Output Power 27dBm (max)
Receiving Sensitivity 11a： 6Mbps -91 dBm 54 Mbps -72dBm
11n： MCS0 -85 dBm MCS7 -67dBm
11ac：MCS0 -85 dBm MCS9 -60dBm
Transmission Distance ≤15km
Wireless Direction Angle Horizontal 10°, vertical 10°
Hardware
Power 1*PoE RJ45 (PoE input via PoE switch or PoE adapter)
Power Consumption ≤25W
Ethernet Port 1×10/100M/1000MBase-TX (Cat. 5/5E, RJ-45)
Indicator Light 3×Link Quality
Working Temperature -30℃~+70℃
Storage Temperature -40℃~+85℃
Working Humidity 5%~95%RH (no condensation)
Equipment Dimension 240mmⅹØ373mm
Equipment Weight 0.94kg
Protection Level IP66
Software
Encryption Type 802.1x/WPA-PSK/WPA2-PSK
Network Mode Route/Network Bridge
Working Mode Access Point/Client/WDS AP/WDS client/WDS Repeater
Security Mechanism IP/MAC address filtering, hide network name
Network Protocol TCP/UDP/ARP/ICMP/DHCP/HTTP/NTP
TDMA Enhancement Support
Auto ACK Timing Adjustment Support
Management and Log NTP, Syslog, Telnet, AC, SNMP
Webpage Configuration Management Web, SNMP, Access Controller
Firmware Update Web, Access Controller
Bandwidth Flexible Configuration 10/20/40/80MHz
