Dahua HY-1320 2-Wire EN54-5/7 Multi-Sensor Smoke and Temperature Detector

Dahua HY-1320 2-Wire EN54-5/7 Multi-Sensor Smoke and Temperature Detector

 
-56%

HY-2301-RE - The multi-sensor detector combines smoke and temperature detection in a single device, offering advanced and highly reliable fire protection. Thanks to the split-spectrum photoelectric optical sensor and built-in thermistor, it analyzes smoke and temperature changes in real time to quickly trigger the alarm in the event of a fire. The polarity-free 2-wire technology simplifies wiring and installation, while the intelligent dust compensation algorithm optimizes accuracy and reduces maintenance. Compliant with EN54-5 and EN54-7 standards, it is ideal for apartments, offices, shops, warehouses and industrial environments. Dahua

Technical Data Sheet

Reference: HY-1320

Brand: Dahua

EAN: 6939554931826

Manufacturer Object ( [id] => 13 [name] => Dahua [description] =>

The Asian Company, born in 2001, is famous because of the excellent quality of its product in terms of performances and potential.

The range of products made by Dahua includes not only classic CCTV systems but also more complex and articulate systems: not only video surveillance, indeed, but also access control, video intercoms, thermal cameras and much more.

The reliability, the cutting-edge technologies and the competitive prices offered by Dahua are only some of the reasons why Setik has always chosen to distribute this brand. Dahua has been for years a reference point in the international CCTV market, due to the huge investments dedicated every year to Research and Development. Numbers are clear: since 2016, Dahua has registered more than 800 patents with its own brand.

The Dahua-branded products sold by Setik Srl could eventually be delivered as OEM: this means that the items are absolutely original and made by Dahua, but characterized by a different aesthetic look reserved for the online market (generally as far as the logo and the package are regarded).

This has no effects on the warranty and on the technical specifications nor even on the possible updates and functionalities, because the products are authentic Dahua’s ones.

[short_description] =>

Videosorveglianza Dahua

Zhejiang Dahua Technology Co., Ltd. is one of the leading solution providers in video surveillance industry, with more than 13,000 employees and 35 active branches all over the world.

[id_address] => [date_add] => 2012-07-14 17:53:54 [date_upd] => 2026-02-19 16:06:32 [link_rewrite] => dahua [meta_title] => Best Dahua Products: DVR, HCVR,NVR, IPC,SD,PTZ,HDCVI, [meta_keywords] => dahua, dahuatech, dahua distribution, dahua national supplier [meta_description] => Dahua, TVCC manufacturer, IP, Analogue and SDI,HD-CVI [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


HY-1320 | MULTI-SMOKE AND TEMPERATURE SENSOR

Dahua

The Dahua HY-1320 multi-sensor detector integrates smoke and temperature detection in a single device, offering an advanced and highly accurate fire protection system for residential, commercial, and industrial environments. Thanks to the split-spectrum photoelectric optical sensor and built-in thermistor, it analyzes smoke and temperature changes in real time to quickly activate the alarm within 1 second. The polarity-free 2-wire technology simplifies wiring and installation, while the intelligent dust compensation algorithm improves reliability and maintenance. Compliant with EN54-5 and EN54-7 standards, it guarantees high performance and maximum fire safety.

Main specifications:

- Multi-sensor smoke and temperature detection for more accurate and reliable fire protection

- Split-spectrum photoelectric optical sensor to quickly identify the presence of smoke

- Integrated thermal detection with A2R threshold from 54°C to 62°C for advanced temperature monitoring

- 2-wire, polarity-free technology for simple wiring and quick installation

- Intelligent dust compensation algorithm to reduce false alarms and maintenance

- Built-in microprocessor for stable communication and high performance

- EN54-5 and EN54-7 compliance for certified professional fire protection systems

Further details

✅ 2-wire technology:
Polarity-free design to simplify wiring and speed up installation of the multi-sensor detector, reducing connection errors and improving the efficiency of professional fire protection systems.
✅ Multi-sensor detection:
Multi-sensor smoke and temperature detection that combines optical and thermal analysis to offer more precise, reliable and rapid fire protection in the detection of early fires.
✅ Split-spectrum photoelectric optical sensor:
Built-in photoelectric split-spectrum optical sensor to effectively identify smoke and increase detection accuracy, reducing the risk of false alarms and improving the safety of monitored environments.
✅ Intelligent thermal detection:
Intelligent thermal detection with constant monitoring of temperature changes and A2R threshold from 54°C to 62°C, ideal for quickly detecting dangerous situations and fires in their early stages.
✅ Integrated microprocessor:
Built-in microprocessor to ensure stable communication, intelligent data processing and high performance in professional addressable fire alarm systems.
✅ EN54-7 and EN54-5 compliant:
EN54-7 and EN54-5 compliant certified to European fire safety standards, ensuring reliability, continuous protection and compatibility with modern systems for residential, commercial and industrial environments.

Technical data sheet

HY-1320
Technical Specification
Power DC24V
Current Monitoring current: ≤ 150μA
Alarm current: ≤ 240μA
Indicator Red
Polling: Flash 6 seconds
Alarm: Remain lit
Fault: Flash 2 seconds
Alarm Threshold for Heat Detection A2R (54°C to 62°C)(129°F to 144°F)
Wiring Two-wire, polarity-free
Addressing Method Electrical encoder
Address Range 1-254
Communication Distance ≤ 1500 m (4921.26 ft)
Operating Temperature –10°C to +50°C (+14°F to +122°F)
Storage Temperature –20°C to +65°C (–4°F to +149°F)
Operating Humidity ≤ 95% RH (no condensation)
Color White
Dimensions (with base) Φ100mm × 68.7mm (Φ3.00" × 2.70")
Weight (with base) 106.3 g (0.23 lb)
Compliance Standard EN54-5, EN54-7
