The IPC-PT2849DC1-SW-PV is an 8MP camera with a 3.6mm lens and a viewing angle of up to 93.4° . It offers ultra-clear 4K images with WizColor technology for color visibility even in low-light conditions. Thanks to automatic tracking, AI detection of people and vehicles, and the audible and light alarm function, it ensures intelligent and reliable protection. The 360° panoramic view, two-way audio, and Wi-Fi 6 connection make surveillance more comprehensive and faster, while the DMSS app allows remote management, real-time notifications, and secure Dahua data sharing.
CLEARANCE SALE ×
CLEARANCE SALE!
Take advantage of our must-see outing offers.
Discover the promo >>
IPC-PT2849DC1-SW-PV | 8MP 3.6mm FIXED LENS WI-FI CAMERA - AUTO TRACKING - WIZ COLOR

The Dahua IPC-PT2849DC1-SW-PV 8MP Wi-Fi PTZ camera with 3.6mm lens and up to 93.4° viewing angle offers 4K Ultra HD resolution with WizColor technology for clear color images even in the dark. Equipped with automatic tracking, AI detection of people and vehicles, light/sound alarm and two-way audio, it ensures complete protection with 360° panoramic vision. With Wi-Fi 6, IP66 protection and management via DMSS app, it guarantees high performance and advanced security .
Main specifications:
- 3.6mm optics with FOV up to 93.4°
- 4K Ultra HD resolution with WizColor technology
- AI detection of people and vehicles
- 360° panoramic view with automatic tracking
- Integrated sound and light alarm
- Two-way audio and Wi-Fi 6 connection
Further details
✅ Wi-Fi 6:

Technical data sheet
| MODEL | IPC-PT2849DC1-SW-PV |
| Room | |
| Image Sensor | 1/1.8" CMOS |
| Max. Resolution | 3840 (H) × 2160 (V) |
| Electronic Shutter Speed | 1 s–1/100,000 s |
| Min. Illumination | 0.0005 lux@F1.0 (Color, 30 IRE); 0 lux (Illuminator on) |
| Illumination Distance | 30 m (98.43 ft) (Warm light) |
| Illuminator Number | 4 (Warm light) |
| Lens | |
| Focal Length | 3.6 mm |
| Max. Openings | F1.0 |
| Field of View | H: 82.9°; V: 47.3°; D: 93.4° |
| PTZ | |
| Pan/Tilt Range | Pan: 0° to 345°; Tilt: 0° to 90° |
| Smart Event | |
| Human Detection | Yes |
| Vehicle Detection | Yes |
| Video | |
| Video Compression | Smart H.265+; H.264M; H.264H; Smart H.264+; H.265; H.264B; MJPEG(Sub Stream 1) |
| Video Frame Rate | Main stream: 8M/3M/720p@(1–15fps) Sub stream 1: 640 × 360/QVGA@(1–15 fps) |
| Day/Night | Color/B/W |
| WDR | 120 dB |
| Motion Detection | Yes |
| Image Rotation | 180° |
| Audio | |
| Audio Compression | PCM, G.711A, G.711Mu |
| Built-in MIC | Yes |
| Built-in Speaker | Yes |
| Network | |
| Network | RJ-45 (10/100 Base-T) |
| Standard Wi-Fi | IEEE802.11g;IEEE802.11b; IEEE802.11n; IEEE802.11ax |
| Wi-Fi Frequency Range | 2.4 GHz |
| Wi-Fi Transmission Rate | 229 Mbps |
| Wi-Fi Pairing | Bluetooth pairing |
| Max. Transmission Power | ≤20 dBm@2,400–2,483.5 MHz |
| Interoperability | ONVIF (Profile S & Profile G & Profile T); CGI |
| Storage | Micro SD card (Up to 512 GB); FTP |
| Management Software | NVR;DMSS |
| Mobile Client | Android; iOS |
| Function | |
| Abnormal Sound Alarm | Yes |
| Certification | |
| Certifications | THERE IS |
| Power | |
| Power Supply | 12 VDC, 1 A ± 10% |
| Power Consumption | Basic: 3 W Max. (Basic power consumption + WDR + Light on + PTZ operation): 9 W |
| Environment | |
| Operating Temperature | –30 °C to +55 °C (–22 °F to +131 °F) |
| Operating Humidity | ≤95% |
| Protection | IP66; TVS 2000V lightning proof; surge protection; voltage transient protection |
| Structure | |
| Product Dimensions | 153.5 mm × Φ129.3 mm (6.04" × Φ5.09") |
| Net Weight | 0.60 kg (1.32 lb) |
