TPC-BF1241-LB10F12-DW-S8-V1 - is a hybrid thermal IP camera from the Eureka series designed for advanced detection of intrusions, fires and thermal anomalies in industrial and perimeter environments. It combines a 256×192 VOx 12μm thermal sensor with a 10mm fixed thermal lens and a 4MP visible camera with a 12mm fixed lens , offering precise monitoring even over long distances. Thanks to the fusion of thermal and visible images , AI functions for people and vehicle classification , smoke and heat detection, it ensures intelligent and reliable protection. The equipment also includes IR illuminator up to 30m , integrated white light , alarm audio, MicroSD slot up to 256GB , PoE power supply and IP67 protection for professional outdoor installations. Dahua
TPC-BF1241-LB10F12-DW-S8-V1 | POE THERMAL BULLET IP CAMERA WITH 12mm FIXED LENS - 10mm THERMAL LENS - 4 MEGAPIXELS - ARTIFICIAL INTELLIGENCE

The Dahua TPC-BF1241-LB10F12-DW-S8-V1 is a hybrid thermal IP camera from the Eureka series designed for perimeter security, fire detection and critical area monitoring. It combines a 256×192 VOx 12μm thermal sensor with 10mm thermal lens and a 4MP visible camera with 12mm lens , offering precise control even over long distances. Thermal and visible fusion technology, together with AI functions for intrusion detection, people and vehicle classification, smoke and heat , ensures advanced protection. Equipped with IR up to 30m , built-in white light , alarm audio, MicroSD up to 256GB , PoE power supply and IP67 protection, it is ideal for professional indoor and outdoor applications.
Main specifications:
- VOx thermal sensor 256×192
- 4 MP optical camera (2688×1520)
- 10mm thermal optics and 12mm visible optics
- AI with people and vehicle classification
- Fire and smoke detection
- IR up to 30m
- Built-in alarm audio
- MicroSD up to 256 GB
- PoE and 12 VDC
- IP67 protection
Further details
The visible camera integrates a 4 MP (2336×1752) sensor with a 12 mm F2.0 fixed lens , ideal for monitoring large areas and for the precise identification of people, vehicles and details from a distance.
The thermal module is equipped with a fixed 10 mm F1.0 lens , designed to detect temperature changes, hot spots and potential fire starts even in difficult environmental conditions.
✅ Built-in dual microphone:
Technical data sheet
| TPC-BF1241-LB10F12-DW-S8-V1 |
| Technical features |
| Dahua Eureka Series Hybrid Bullet IP Thermal Camera |
| Thermal sensor: uncooled VOx (vanadium) detector, 256 (H) × 192 (V), pixel pitch 12 µm, spectral range 8-14 µm |
| Thermal sensitivity (NETD): < 40 mK (@f/1.0, 25 Hz, 300 K) |
| Lens fixed thermal: 10 mm, F1.0 |
| Thermal angle of view (10 mm): H 17.3°, V 13.1°, F1.0 |
| Thermal digital zoom: 16 levels |
| Digital Detail Enhancement (DDE): yes |
| Color Palettes: 18 |
| Fusion mode: 3 (Warm color, Cool color, Ironred) |
| Viewable channel: 1/2.7" CMOS sensor, 4 MP (2336 × 1752) |
| Lens Visible fixed: 12 mm, F2.0 |
| Visible angle of view (12 mm): H 22°, V 16.6° |
| Minimum illumination: color 0.05 lux, B/W 0.005 lux, 0 lux (IR on) |
| IR: up to 30 m |
| Day/Night: Auto (ICR), Color, B/W |
| S/N ratio: ≥55 dB |
| Integrated white light |
| Video stream |
| Video compression: H.265, H.264, H.264H, MJPEG |
| Thermal resolutions: 1280 × 960 (1.3M), XVGA (1024 × 768), VGA (640 × 480), 256 × 192 |
| Visible resolutions: 2336 × 1752, 1080P (1920 × 1080), 720P (1280 × 720), D1 (704 × 576) |
| Stream 1 (thermal): 1280 × 960 @ 25 fps (50 Hz) / 30 fps (60 Hz) |
| Stream 2 (thermal): 256 × 192 @ 15 fps by default |
| Stream 1 visible: 2336 × 1752 @ 25 fps (50 Hz) / 30 fps (60 Hz) |
| Stream 2 visible: 352 × 288 @ 15 ips by default |
| Features |
| BLC, HLC and DWDR |
| Noise reduction: 2D NR, 3D NR |
| RoI: yes |
| Image rotation: 180 |
| Exposure compensation: yes |
| Dual image fusion (visible and thermal channel) |
| AGC: auto and manual |
| Hot and cold spot tracing |
| Remote auxiliary management |
| Intelligent functions |
| General analytics: tripwire and intrusion |
| Heat detection and alarm |
| Human/vehicle classification |
| Smoke detection |
| Call detection |
| Audio |
| Audio compression: G.711a, G.711mu, PCM |
| Audio input: 1 |
| Audio output: 1 |
| Built-in speaker for alarm |
| Storage |
| MicroSD card slot up to 256 GB (card not included) |
| Alarms |
| Alarm input: 2 |
| Alarm output: 2 |
| Communication interface |
| RS-485 via 1 pair |
| Optional Wi-Fi: 802.11b/g/n (1x1), 2.4 GHz, up to 150 Mbps, distance up to 150 m (unshielded and undisturbed) |
| Network |
| Network interface: 1 × RJ-45 (10/100 Base-T) |
| Protocols: HTTPS, HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, SNMP, QoS, UPnP, NTP |
| Interoperability: ONVIF, CGI, Dahua SDK |
| Concurrent users: 10 |
| Security: Authorized user and password, associated MAC, encrypted HTTPS, IEEE 802.1x, network access control |
| Power supply |
| Power supply: 12 VDC ± 20% and PoE |
| Basic power consumption: <5.7 w="" 12="" vdc="" illuminator="" off="" 6="" 8="" poe="" td=""> |
| Maximum power consumption: <8.2 w="" 12="" vdc="" illuminator="" on="" and="" speaker="" 9="" 4="" poe="" td=""> |
| Environmental |
| Operating temperature -30 °C to +60 °C (-22 °F to +140 °F) |
| Storage temperature -30 °C to +70 °C (-22 °F to +70 °C) |
| Relative humidity ≤95%. |
| IP67 protection |
| Physical characteristics |
| Dimensions (L × W × H): 205.5 × 90.4 × 90.1 mm |
| Packaging dimensions (L × W × H): 279 × 187 × 138 mm |
| Net weight: ≤ 0.9 kg |
| Gross weight: ≤ 1.3 kg |
