IPC-HDBW7459Z-Z4-PV-X - is a WizMind 4MP IP dome camera designed for professional advanced video surveillance applications. Equipped with an 8-32mm PTRZ motorized varifocal lens , it offers remote framing adjustment and high-definition images even in low light conditions thanks to AI-ISP and Smart Dual Light technology with an IR range of up to 80 meters. The integration of Xinghan Large-Scale AI Models-Vision models enables intelligent functions such as facial recognition , ANPR , perimeter protection , people counting and DPI detection. Complete with a built-in dual microphone , speaker with audible and light alarm, PoE/ePoE support and IP67 IK10 protection, it represents a reliable solution for complex and high-security environments. Dahua
FIND INSTALLER
IPC-HDBW7459Z-Z4-PV-X | 4MP IP DOME CAMERA WITH 8-32mm VARIFOCAL LENS - ARTIFICIAL INTELLIGENCE - POE
The Dahua IPC-HDBW7459Z-Z4-PV-X is a 4MP WizMind IP dome camera designed for advanced security applications, with a 1/1.8" CMOS sensor and AI-ISP technology that ensures clear images even in low light conditions. Thanks to the Smart Dual Light illumination with IR range up to 80 m and warm light up to 60 m, it offers effective monitoring day and night. It integrates the powerful Xinghan Large-Scale AI Models-Vision models for functions such as facial recognition, ANPR, perimeter protection, people counting and PPE detection. The motorized PTRZ system, built-in dual microphone, speaker with audible and light alarm and IP67 IK10 protection make it ideal for high-security professional environments.
Main specifications:
- 4MP resolution
- 8-32 mm varifocal lens
- AI Xinghan Large-Scale Models
- Smart Dual Light IR 80 m
- Facial recognition and ANPR
- Advanced perimeter protection
- Dual microphone and speaker
- PoE / ePoE
- IP67 and IK10
- MicroSD support up to 1TB
Further details
✅ Optics :
The camera integrates an 8-32mm motorized varifocal lens with F1.6 aperture, designed to adapt to short- and long-range monitoring scenarios. The system allows for precise framing and focus adjustments to obtain detailed images in any context.
✅ Resolution:
The 1/1.8" 4MP CMOS sensor delivers high-definition images of up to 2688 × 1520 pixels at high frame rates, ensuring smooth and detailed reproduction of people, vehicles and complex scenes.
✅ Smart Dual Light:
Smart Dual Light technology combines IR illumination up to 80 meters and warm light up to 60 meters , improving nighttime visibility and automatically activating the most suitable mode for sharper color images during events.
✅ Motorized PTRZ:
The motorized PTRZ system allows remote pan, tilt, pan and zoom adjustment, reducing installation time and allowing precise setup without manual intervention on the camera.
✅ Xinghan Large-Scale AI Models-Vision :
Thanks to the advanced Xinghan AI models, the camera improves the recognition of people, vehicles and objects, simultaneously supporting functions such as Face Recognition , ANPR , Perimeter Protection , People Counting , PPE Detection and AcuPick with high accuracy and false alarm reduction.
Thanks to the advanced Xinghan AI models, the camera improves the recognition of people, vehicles and objects, simultaneously supporting functions such as Face Recognition , ANPR , Perimeter Protection , People Counting , PPE Detection and AcuPick with high accuracy and false alarm reduction.
✅ Smart Conductive Heat Transfer Technology :
Innovative thermal transfer technology uses adaptive heating elements to eliminate condensation, fog, ice, and snow from the dome, maintaining a clear and reliable view even in extreme weather conditions.
Innovative thermal transfer technology uses adaptive heating elements to eliminate condensation, fog, ice, and snow from the dome, maintaining a clear and reliable view even in extreme weather conditions.
✅ Audio:
Equipped with a built-in dual microphone with noise reduction algorithms and a Hi-Fi speaker , it offers audio acquisition up to 30 meters and effective audio communications for advanced security applications.✅ Alarm :
It supports active sound and light alarms , as well as numerous intelligent events such as intrusion, line crossing, face recognition, ANPR, person detection and tampering, for proactive protection of the monitored area.
It supports active sound and light alarms , as well as numerous intelligent events such as intrusion, line crossing, face recognition, ANPR, person detection and tampering, for proactive protection of the monitored area.
✅ Network Camera:
Compatible with IPv4/IPv6, ONVIF, RTSP, HTTPS and DoLynk Cloud protocols, it guarantees advanced integration with professional video surveillance systems and remote management via dedicated software and apps.
✅ Functions:
It includes advanced perimeter protection , facial recognition , ANPR license plate reading , people counting , parking management , video metadata , privacy protection and self-learning AI features , ideal for enterprise and smart city applications .
✅ Doors :
It features 3 alarm inputs , 2 alarm outputs , RCA audio input and output , RS-485 port , BNC video output and MicroSD support up to 1 TB , offering maximum integration flexibility.
✅ PoE :
PoE+ and ePoE support enables power and data transmission over a single Ethernet cable, simplifying installation, reducing infrastructure costs, and ensuring greater operational reliability.
Technical data sheet
| MODEL | IPC-HDBW7459Z-Z4-PV-X |
| Room | |
| Image Sensor | 1/1.8" CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
| Min. Illumination | 0.0006 [email protected] (Color, 30 IRE) 0.0002 [email protected] (B/W, 30 IRE) 0 lux (Illuminator on) |
| S/N Ratio | > 56 dB |
| Illumination Distance | Up to 80 m (262.47 ft) (IR) Up to 60 m (196.85 ft) (Warm light) |
| Illuminator On/Off Control | Auto;Manual |
| Illuminator Number | 4 (Multi-core (IR + warm) light) |
| Pan/Tilt/Rotation Range | Pan: 0°–355° Tilt: 0°–80° Rotation: 0°–355° |
| Lens | |
| Lens Type | Motorized vari-focal |
| Lens Mount | Module |
| Focal Length | 8 mm–32 mm |
| Max. Openings | F1.6 |
| Field of View |
H: 41°–15°; V: 22°–9°; D: 47°–18° |
| Iris Control | Car |
| Iris Control Type | P-Iris |
| Close Focus Distance | 1 m (3.28 ft) |
| Smart Event | |
| IVS | Abandoned object; missing object |
| Intelligence | |
| Intelligence Notes | Dual intelligent functions can be enabled simultaneously: Face detection + people counting; face recognition + people counting; PPE detection + Perimeter Protection; PPE detection + face detection; PPE detection + face recognition |
| EPTZ | Yes |
| IVS (Perimeter Protection) | Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle, animal and human), loitering detection, people gathering, parking detection, stay detection, abandoned object, and missing object. Offers Perimeter Protection Large-Scale AI Models to extend the target detection range and reduce the rate of false alarm. Supports self-learning, it filters out false alarms. Supports privacy protection. |
| AcuPick | Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people, animals, and motor vehicles, and search through live and recorded videos to quickly locate targets. |
| Face Detection (Full Image) | Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face extraction attributes including 6 attributes and 8 expressions; face snapshot set as face, one-inch photo or custom; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting; supports privacy protection for faces |
| Face Recognition | There are two modes: General mode and counting mode. General mode: Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face extraction attributes including 6 attributes and 8 expressions; face snapshot set as face or one inch photo; snapshot strategies (recognition priority and optimization snapshot); face angle filter; optmization time setting. support privacy protection for faces. Supports adding 5 group face databases; registering person one by one or in batches; setting face similarity; and supports face comparison with the face database containing up to 200,000 face pictures. Counting mode: Offers advanced customer counter, filters out specified faces from the face database, and exports reports both before and after removing duplicate faces. |
| PPE Detection | Triggers alarms when the detected object matches or does not match all of the configured attributes (helmets, hats, uniforms, masks, gloves, shoe covers, shoes, safety vests, seatbelts, goggles, and aprons). Supports self-learning, it detects the different colors and styles of workwear. Supports privacy protection for faces/human bodies. |
| People Counting | Tripwire people counting and people counting in area; generating and exporting reports (day/month/year); queue management and exporting report (day/month); 4 rules can be set for tripwire people counting, people counting in area, and queue management; supports privacy protection |
| Heat Map | Yes |
| ANPR | ANPR: ANPR, track, priority, snapshot. Vehicle attributes: License plate, vehicle type, vehicle color. Other attributes: Seat belt, smoking, calling. Support up to 10,000 blocklist records and 10,000 allowlist records. The camera can recognize plate numbers of vehicles moving at speeds of up to 60km/h. Supports privacy protection for vehicle bodies. |
| Parking Space Management | Parking Space Management: Manage outdoor and planned parking lots; manage parking spaces in multiple areas; display the total number of parking spaces and parking spaces that are available; trigger alarms based on a predefined number of vehicles |
| Video Metadata | Motor vehicle, non-motor vehicle, face, human detection; track; snapshot; snapshot optimization; optimal face snapshot upload Generates flow statistics for people, motor vehicles, and non-motor vehicles based on the direction, and exports reports Motor vehicle attributes: License plate, vehicle type, vehicle color, vehicle logo, seatbelt, smoking, and calling Non-motor vehicle attributes: Type, color, number of people, top type and color, and hat Human body attributes: Top and bottom type and color, bag, hat, gender, and umbrella Supports privacy protection for faces, human bodies, and vehicle bodies |
| Privacy Protection | Mosaics and frosted glasses can be automatically placed over faces, human bodies and vehicle bodies protect their privacy |
| Smart Search | Yes |
| Video | |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| AI Coding | AI H.265, AI H.264 *Includes smart codec technology, Smart H.265+ and Smart H.264+ |
| Video Frame Rate | Default: Main stream: 2688 × 1520@(1–25/30 fps) Sub stream: 1920 × 1080@(1–25/30 fps) Third stream: 1920 × 1080@(1–25/30 fps) Fourth stream: 1920 × 1080@(1–25/30 fps) Fifth stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) High Frame Rate: Main stream: 2688 × 1520@(1–75/90 fps)/1920 × 1080@(1–100/120 fps) Sub stream: 1920 × 1080@(1–25/30 fps) Third stream: 1920 × 1080@(1–25/30 fps) Fourth stream: 1920 × 1080@(1–25/30 fps) Fifth stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Streaming Capability | 5 stream |
| Resolution | 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280×960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | VBR; CBR; ABR |
| Video Bit Rate | H.264: 32 kbps–10,240 kbps H.265: 12 kbps–10,240 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 140 dB |
| Scene Self-adaptation (SSA) | Yes |
| White Balance | Car; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Car |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Image Stabilization | Gyroscope Image Stabilization (GIS) |
| Smart Lighting | Yes |
| Smart Dual Light | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 mosaics + 8 color blocks (The color of every pure color block can be set as one, including red, orange, yellow, green, cyan, blue, purple and black.) |
| Time-Division Exposure | Yes |
| Audio | |
| Built-in MIC | Yes, built-in dual Mic |
| Built-in Speaker | Yes, built-in speaker; Max power consumption: 2 W; max sound level at 10 cm: 110 dB * Test results from laboratory |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm | |
| Alarm Event | No SD card; SD card full; SD card error; SD card durability warning; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missingobject; loitering detection; people gathering; parking detection; scene changing; audio detection; defocus detection; external alarm; face detection; face recognition; video metadata; ANPR; people counting in area; stay alarm; people counting; people number error detection; people stay detection; security error; parking space management; PPE detection; tampering detection |
| Network | |
| Network | RJ-45 (10/100/1000 Base-T) |
| SDK and API | Yes |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; DoLynk Cloud; Auto Registration |
| Interoperability | ONVIF (Profile S & Profile G & Profile T & Profile M); CGI |
| User/Host | 20 (Total bandwidth: 340 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 1TB); NAS |
| Browser | IE: IE11 and later Chrome: Chrome 100 and later Firefox: Firefox 47.0.2 and later |
| Management Software | Smart PSS Lite; DSS; DMSS |
| Mobile Client | Android; iOS |
| Cyber Security | Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of |
| Function | |
| Light Warning | Yes |
| Sound Warning | Yes |
| Heater (Window Heating) | Quickly removes water, ice, snow, and mist from the glass to keep images clear |
| Certification | |
| Certifications | CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| Port | |
| RS-485 | 1 (baud rate range: 1200 bps–115200 bps) |
| Audio Input | 1 channel (RCA port) |
| Audio Output | 1 channel (RCA port) |
| Alarm Input | 3 channels in: supports wet contact connection (max load 5 mA 3–5 VDC); supports dry contact connection |
| Alarm Output | 2 channels out: dry contact, max load 1,000 mA 30 VDC/500 mA 50 VAC |
| Analog Output | 1 channel (CVBS output: BNC) |
| Power Output | 12 VDC power output, max. current 165 mA, peak current 700 mA |
| Power | |
| Power Supply | 12 VDC (±30%) & 24 VAC (±30%) independent power port; PoE+ (802.3at) |
| Dual Power Backup | When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart. |
| Power Consumption | Basic: 7.5W (12VDC); 8.87W (24VAC); 9.48W (PoE); Max.: 19W (12VDC); 22.5W (24VAC); 23.8 W (PoE) (ICR switch + IR intensity); Heating: 2W (12VDC); 2.4W (24VAC); 2.6W (PoE) |
| ePoE | Yes |
| Environment | |
| Operating Temperature | –40 °C to +65 ℃ (–40 °F to +149 °F) |
| Operating Humidity | ≤95% (RH), non-condensing |
| Strorage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | 10–95% (RH), non-condensing |
| Protection | IP67; IK10 |
| Anti-corrosion Level | Basic Protection *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection. |
| Structure | |
| Casing Material | Casing: Metal |
| Product Dimensions | 150mm × Φ159mm (5.91" × Φ6.26") |
| Net Weight | 1.4 kg (3.09 lb) |
| Gross Weight | 1.9 kg (4.19 lb) |
