Dahua Mini Dome IP Camera 4MP 2.8 mm PoE IR 30 m Human Detection IP67 - Dahua

Dahua Mini Dome IP Camera 4MP 2.8 mm PoE IR 30 m Human Detection IP67 - Dahua
-56%

IPC-HDW1431T1-S6 - The 4 MP Mini Dome IP camera with 2.8 mm fixed lens is designed to offer clear images and a wide 92° viewing angle, ideal for indoor and outdoor video surveillance. Thanks to 4 MP resolution , Smart H.265+/H.264+ compression, IR illumination up to 30 meters and 120 dB WDR , it guarantees high performance even in difficult lighting conditions. The Human Detection function improves detection accuracy, while PoE power supply and IP67 protection ensure simple, reliable and weatherproof installations. Dahua

Technical data sheet

Reference: IPC-HDW1431T1-S6

Brand: Dahua

EAN: 6937552442207

Manufacturer Object ( [id] => 13 [name] => Dahua [description] =>

The Asian Company, born in 2001, is famous because of the excellent quality of its product in terms of performances and potential.

The range of products made by Dahua includes not only classic CCTV systems but also more complex and articulate systems: not only video surveillance, indeed, but also access control, video intercoms, thermal cameras and much more.

The reliability, the cutting-edge technologies and the competitive prices offered by Dahua are only some of the reasons why Setik has always chosen to distribute this brand. Dahua has been for years a reference point in the international CCTV market, due to the huge investments dedicated every year to Research and Development. Numbers are clear: since 2016, Dahua has registered more than 800 patents with its own brand.

The Dahua-branded products sold by Setik Srl could eventually be delivered as OEM: this means that the items are absolutely original and made by Dahua, but characterized by a different aesthetic look reserved for the online market (generally as far as the logo and the package are regarded).

This has no effects on the warranty and on the technical specifications nor even on the possible updates and functionalities, because the products are authentic Dahua’s ones.

[short_description] =>

Videosorveglianza Dahua

Zhejiang Dahua Technology Co., Ltd. is one of the leading solution providers in video surveillance industry, with more than 13,000 employees and 35 active branches all over the world.

[id_address] => [date_add] => 2012-07-14 17:53:54 [date_upd] => 2026-02-19 16:06:32 [link_rewrite] => dahua [meta_title] => Best Dahua Products: DVR, HCVR,NVR, IPC,SD,PTZ,HDCVI, [meta_keywords] => dahua, dahuatech, dahua distribution, dahua national supplier [meta_description] => Dahua, TVCC manufacturer, IP, Analogue and SDI,HD-CVI [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


IPC-HDW1431T1-S6 | 4MP Mini Dome IP Camera with 2.8mm Fixed Lens - Human Detection

Dahua

The 4 MP Mini Dome IP camera with 2.8 mm fixed lens guarantees high-definition images and a wide 92° viewing angle , ideal for video surveillance of homes, offices and commercial businesses. Thanks to 4 MP resolution , Smart H.265+/H.264+ compression, IR illumination up to 30 meters and 120 dB WDR , it offers clear images even in high-contrast light conditions. The Human Detection function improves the accuracy of people detection, while PoE power supply and IP67 protection ensure simple installation and high reliability even in outdoor environments.

Main specifications:

  • Resolution: 4 MP (2560×1440)
  • Optics: Fixed 2.8 mm with 92° viewing angle
  • Night vision: IR up to 30m
  • Compression: Smart H.265+ / H.264+
  • WDR: 120 dB with 3D NR, HLC and BLC
  • Artificial Intelligence: Human Detection
  • Power supply: PoE and 12V DC
  • Protection: IP67 for indoor and outdoor installations

Further details

✅ Optics :
The 2.8mm fixed lens with a 92° viewing angle provides wide and uniform coverage of the monitored area, making it ideal for monitoring entrances, corridors, offices, shops and outdoor environments with a high level of detail.
✅ Resolution:
The 4 MP (2560×1440) resolution ensures sharp and detailed images, allowing for more precise identification of people and objects, while the Smart H.265+/H.264+ compression optimizes video quality by reducing bandwidth consumption and storage space.
✅ Human Detection :
The Human Detection function uses an intelligent algorithm to accurately recognize and classify people , reducing false alarms caused by animals, vegetation or other irrelevant movements and improving the efficiency of the video surveillance system.
✅ Network:
The RJ-45 10/100 Base-T interface and support for major network protocols (IPv4, IPv6, RTSP, HTTP, DHCP, P2P and ONVIF Profile S/T) ensure seamless integration with NVRs, management software and mobile applications, allowing simple and reliable remote access .

Technical data sheet

IPC-HDW1431T1-S6
Technical features
Dahua Entry Series IP Minidome
1/2.9" CMOS sensor with progressive scan
Maximum resolution 4MP (2560 × 1440)
Auto day/night switching (ICR), color or B/W
Minimum illumination 0.03 [email protected] (color, 30 IRE), 0.003 [email protected] (B/W, 30 IRE), 0 lux with illuminator activated
Integrated IR illumination with range up to 30 m (100 ft)
1 IR LED with automatic or manual on/off control
Fixed lens 2.8 mm M12
Maximum aperture F2.0
Angle of view (2.8 mm): H 92°, V 50°, D 107°, D 107°.
Minimum focusing distance: 1.0 m
Video stream
H.265, H.264, H.264H, H.264B video compression
MJPEG compatible only on substream
Smart codecs Smart H.265+ and Smart H.264+
2 streams
Stream 1: 2560 × 1440@1-25/30 ips
Stream 2: 704 × 576@1-25 ips / 704 × 480@1-30 ips
Supported resolutions: 4M (2560 × 1440), 3M (2304 × 1296), 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)
CBR/VBR bitrate control
H.264 video bitrate: 32kbps-4096kbps
H.265 video bitrate: 12kbps-4096kbps
Features
WDR 120 dB
3D NR
BLC
HLC
Configurable motion detection (4 areas, rectangular)
Configurable ROI (4 areas)
0° or 180° image rotation
Mirror
Privacy masks (4 areas)
Auto, natural, streetlight, outdoor, manual and regional custom white balance
Automatic or manual gain control
Digital watermark
Smart Lighting
Smart features
Human detection with accurate classification and detection
Intelligent search working with Smart NVR for refined search, event extraction and merging to event videos
Network
RJ-45 interface (10/100 Base-T)
SDK and API
Protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
ONVIF (Profile S and Profile T) and CGI interoperability
Users/hosts: 6 (total bandwidth 24M)
Browsers: IE, Chrome, Firefox
Management software: Smart PSS Lite, DSS, DMSS, DoLynk Care
Mobile client: iOS and Android
Power supply
12 VDC or PoE (802.3af)
Basic power consumption 1.5 W (12 VDC) / 1.9 W (PoE)
Maximum consumption 3.5 W (12 VDC) / 4.3 W (PoE)
Environmental
Operating temperature -40°C to +60°C (-40°F to +60°F)
Operating humidity less than 95% (non-condensing)
Storage temperature -40 °C to +60 °C (-40 °F to +60 °C)
Storage Humidity less than 95% (non-condensing)
IP67 protection
Physical characteristics
Housing: inner core metal + plastic, plastic cover, plastic decorative ring, plastic pedestal
Dimensions: 85.5 mm × Φ109 mm
Net weight: 0.25 kg
Gross weight: 0.38 kg
3AXIS: Pan 0°~360°, Tilt 0°~78°, Rotation 0°~360°
Certifications
CE-LVD: EN 62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
