Dahua HAC-HMW3200L-FR 4-in-1 mobile chamber Special S5 version for vehicles. To be installed inside the front windshield. CMOS 1 / 2.7 "of 2MP. 2 4-in-1 video outputs with M12 aviation connectors. 2.8 mm (116 °) fixed front lens. Fixed rear lens of 2.1 mm (139 °). 0.02 lux F2.0. OSD, AWB, AGC, BLC, HLC, WDR digital, 2D-DNR, horizontal mirror mode. Incorporates microphone . 3AXIS. 12V DC.
discover the available quantity
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
HD CVI 2 MEGAPIXEL 2.8MM VEHICLE CAMERA - DOUBLE LENS - S5 VERSION - DAHUA MOBILE
S5 Version Camera for HD CVI Mobile Dahua vehiclesResolution 1080P 2MP FULL HD - Rear lens 2.1 mm ~ Front lens 2.8 mm - 1 / 2.7 "CMOS sensor
Day / Night (ICR) - Incorporates Microphone
Ideal for installation on moving vehicles - Power supply NOT included - 24 month warranty
Product details
- Rear lens 2.1mm ~ Front lens 2.8mm
- 1 / 2.7 "2Megapixel CMOS image sensor
- 12V DC power supply not included
- Suitable for indoor and outdoor environments
- 24 months warranty
Data sheet
| Model | HAC-HMW3200L-FR-S5 |
| Room | |
| Image Sensor | 1 / 2.7 "CMOS |
| Effective Pixels | 1920 (H) × 1080 (V), 2MP |
| Scanning System | Progressive |
| Electronic Shutter Speed |
PAL: 1/25 ~ 1 / 100000s |
| Min. Illumination | 0.02Lux / F2.0,30IRE, 0Lux IR on |
| S / N Ratio |
More than 65dB |
| IR Distance | Up to 3m (9.8feet) |
| IR On / Off Control | Auto / Color / B / W |
| IR Leds | 1 |
| Lens | |
| Lens Type | Fixed lens / Fixed iris |
| Mount Type | Board-in |
| Focal Length | |
 |
MOBILE ROOM The " Mobile Camera " is a camera particularly suitable for installation on moving vehicles, thanks to its shock-proof and compact case. Smart Design |
|
|
SHOCKPROOF - EN50155 Vibration is unavoidable in mobile installations. In order to avoid image or connection errors, the hardware structure of the mobile camera is shock resistant with the certification of EN50155 . In addition, the mobile camera adopts M12 aviation connector for stable connection with MCVR.  |
 |
HD-CVI is the new technology in the world of video surveillance. By simply replacing the equipment (Cameras and DVRs) in the analog infrastructure, the resolution can reach up to 1920X1080 (FULL-HD). In this way it is possible to obtain the same results as in the IP world but with a high cost containment. |
 |
This camera features a resolution of 2Megapixel 2 MP 1080P FULL HD |
 |
This camera features dual optics Rear lens: 2.1mm Front Optics: 2.8mm |
|
|
OSD (ON SCREEN DISPLAY) allows you to define masked areas, image correction, ATR, Day / Night sensitivity, Shutter speed, White balance, light compensation and much more ... The OSD menu is multi-language |
 |
This camera is equipped with an on-board microphone |
 |
Allows you to adapt the lens to Night / Day vision
|
 |
BLC (Back Light Compensation) is one of the 3 possible steps in the management of images with contrast, typical situations are (entrances or exits from car parks, plates, special lights, entrances with shots from inside to outside, etc.) light is one of the most complex operations possible, the BLC function allows a discreet adaptation to these situations |
 |
AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and does not require specific settings. |
 |
D-WDR (Digital Wide Dynamic Range) is the Software solution of the most powerful WDR integrated in the DSP, exactly as it happens for the digital zoom compared to the Optical Zoom, it is a software simulation of emulation of the WDR technology, however extremely useful in circumstances of strong contrast.  |
 |
DC12V power supply NOT included in the package.  |
 |
This camera was made of PLASTIC. |
 |
This product is covered by a 24 month warranty. |
