OUTDOOR CAMERA HDCVI 4IN1 5MP - ACTIVE DETERRENCE - SMART IR 30M - S2 VERSION - DAHUA

Made by Dahua
4in1 outdoor camera with integrated PIR - Dahua Version S2 HDCVI - HAC-ME1500EQ-L-S2
5Megapixel resolution - 4in1: CVI / CVBS / AHD / TVI switchable - 3.6mm fixed lens - Smart IR 30MT illuminator - Integrated PIR with infrared sensor - Active warm light deterrence - Day / Night (ICR), BLC, DWDR, Privacy mask , Mirror Mode, 2DNR, AWB, AGC - IP67 protection for outdoor use - Made of plastic and metal - Power supply NOT included - 24 month warranty

Product details

- 4in1 outdoor camera - Dahua - HAC-ME1500EQ-L-S2
- Resolution: 5 Megapixel 5MP
- S2 version
- 4in1: CVI / CVBS / AHD / TVI switchable via BNC port
- 5MP 1 / 2.7 "CMOS image sensor
- Integrated PIR with infrared sensor with detection range 10m / 110 °
- 3.6mm fixed lens
- Functions: Day / Night (ICR), BLC, DWDR, AGC, AWB, 2DNR, Privacy Mask, Mirror Mode
- High quality Smart IR illuminator with range up to 30 meters.
- 12V DC power supply not included
- Suitable for outdoor and indoor environments
- IP67 protection (dust / immersion)
- Dimensions: Φ109.9 mm × 100.9 mm (Φ4.33 "× 3.97")
- Weight: 0.3Kg
- Material: Plastic and metal interior and plastic cover
- Operating temperature: –40 ° C to +60 ° C
- 24 months warranty

Data sheet

HAC-ME1500EQ-L

Technical Specs

Room

Image Sensor

5MP

Max. Resolution

1 / 2.7 "CMOS

Pixel

2880 (H) × 1620 (V)

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25 s – 1 / 100,000 s NTSC: 1/30 s – 1 / 100,000 s

S / N Ratio

0.005 Lux / F1.6, 30 IRE, 0 Lux IR on

Min. Illumination

> 65 dB

Illumination Distance

30 m (98.4 ft)

Illuminator On / Off Control

Car

Illuminator Number

1 (IR light)

HD-CVI is the new technology in the world of video surveillance. By simply replacing the equipment (Cameras and DVRs) in the analog infrastructure, the resolution can reach up to 1920X1080 (FULL-HD). In this way it is possible to obtain the same results as in the IP world but with a high cost containment.
Quadruple hybrid technology This camera is a QUADRIBRID (4 Integrated Technologies)
These cameras are at the same time, Analog , Ahd , HDCVI and HDVI .

PIR sensor

PIR sensor

This camera integrates a PIR sensor.

Detection range: 10m / 110 °.

Risoluzione 5.0 Megapixel (2560x1920)

5MP resolution, means 12 times the resolution of a common D1 camera :
It guarantees adequate resolutions for any need.

5MP 1 / 2.7 "CMOS image sensor

TLC_FIXED_lens.jpg This camera is equipped with a fixed 3.6mm lens.
IR illuminator up to 30mt Smart IR infrared illuminator, with 1 LED and approximate maximum range of 30m.

This camera is also equipped with SMART IR technology.
Through this technology , the light emitted by the LEDs is adapted according to the framed object.

Active deterrence

Active deterrence:

Report intruders with built-in white light and siren

DWDR function

D-WDR (Digital Wide Dynamic Range) is the Software solution of the most powerful WDR integrated in the DSP, exactly as it happens for the digital zoom compared to the Optical Zoom, it is a software simulation of emulation of the WDR technology, however extremely useful in circumstances of strong contrast.

Esempio funzione Digital Wide Dynamic Range
Allows you to adapt the lens to Night / Day vision

ICR The IR CUT FILTER is a mechanical filter that allows a correct display of images in daylight viewing conditions. It filters the typical infrared frequencies thus improving the image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.
Immagine esempio IR CUT FILTER
BLC (Back Light Compensation) is one of the 3 possible Steps in managing images with Contrast, typical situations are (Entering or exiting car parks, Plaques, Particular lights, Entrances with shots from inside to outside, etc.) the compensation of light is one of the most complex operations possible, the BLC function allows a discreet adaptation to these situations


Click to enlarge

AGC_Camera AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and does not require specific settings.
Protezione IP67 contro polveri e immersioni Protection level IP67 (Dust / Diving)

12VDC_Aliment 12VDC power supply not included
Questo prodotto è coperto da garanzia 24 mesi italiana

This product is covered by a 24 month warranty.

Download

Download the English brochure
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
