Dahua PTZ Starlight WizSense 4MP 4.8-120mm Onvif PoE IR150 Active Deterrence Artificial Intelligence IP66
AI Series SD6C3425XB-HNR-A-PV1 Dahua WizSense ONVIF PoE + PTZ outdoor camera with 4Megapixel resolution, motorized varifocal lens with 25X optical zoom (4.8-120mm), IR LED 150m, 1/2.8" Sony® STARVIS™ CMOS sensor with Technology Starlight, H.265+, Triple Stream, WDR 120dB, artificial intelligence , face recognition , auto tracking, perimeter protection, active deterrence , video analysis, Audio, Alarm, ROI, EIS, Defog, WDR 120dB, 1in/1out x Audio - 2in/1out x Alarm, MicroSD slot (256GB), IP66 protection.
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
PTZ CAMERA 4MP ONVIF® POE WITH ARTIFICIAL INTELLIGENCE AND ACTIVE DETERRENCE - STARLIGHT
4Megapixel resolution - 4.8mm~120mm lens ( 25x zoom) - 1/2.8" Starlight CMOS sensor
Slot for Micro SD Card (256GB) - IP66 protection - 24 months warranty
AI TECHNOLOGY | ARTIFICIAL INTELLIGENCE: |
Product details
- PoE Outdoor ONVIF® AI Camera - Dahua
- 4Megapixel resolution
- 4.8mm~120mm motorized varifocal lens (25x optical zoom)
- 1/2.8" CMOS sensor with Starlight Technology
- Starlight technology: Color night vision!
- Video Compression up to H.265+
- Triple Stream
- Day/Night(ICR), AWB,AGC,BLC,HLC 2D / 3D-NR, Defog, EIS, WDR (120db)
- Illuminator up to 150 meters .
- Artificial Intelligence: Perimeter Protection - Video Analysis - Active Deterrence - Movement Recognition
- Active deterrence
- 2 inputs and 1 alarm output
- 1 input and 1 output of audio
- 1 microSD-Card slot (Max 256GB not included)
- IP66 protection
- Dimension: 325.3 mm × Φ202.0 mm (12.81" × Φ7.95") (H × D)
- Arm included - Power supply NOT included
- 24 months warranty
Data sheet
| model | SD6C3425XB-HNR-A-PV1 |
| Room | |
| Image Sensor | 1/2.8” |
| Pixels | 4MP |
| Effective Pixels | 2560(H)×1440(V) |
| Scanning System | Progressives |
| Electronic Shutter Speed | 1/1s~1/30,000s |
| Min Illumination | Color: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux (IR light on) |
| ROM | 4GB |
| RAM | 1GB |
| IR LEDs | 4 |
| Illumination Distance | 150m (492.13ft) (IR) 50m (164.04ft) (white light) |
| Illuminator Number | 2 (IR light) 2 (dual light fusion) |
| lens | |
| Focal Length | 4.8mm–120mm |
| Max Openings | F1.6–F4.0 |
| Angle Of View | H: 55.8°–2.9°; V: 31.6°–1.6° ; D: 63.7°–3.3° |
| optical zoom | 25x |
| Focus control | Auto/Semi-Auto/Manual |
| Iris Control | Auto/Manual |
| Close Focus Distance | H: 55.8°–2.9°; V: 31.6°–1.6° ; D: 63.7°–3.3° |
| PTZ | |
| Pan/Tilt Range | Pan: 0° to 360° endless Tilt: –20° to +90°, auto flip 180° |
| Manual Control Speed | Pan: 0.1°/s–160°/s Tilt: 0.1°/s–60°/s |
| Speed presets | Pan: 240°/s; Tilt: 150°/s |
| Presets | 300 |
| Tours | 8 (up to 32 presets per tour) |
| Pattern Number | 5 |
| Scan Number | 5 |
| Power-off Memory | Yes |
| Idle motion | Presets/Tours/Patterns/Scans |
| protocol | DH-SD Pelco-P/D (auto recognition) |
| artificial intelligence | |
| Video Metadata | Support human body, human face, motor vehicle and non-motor vehicle image capture. |
| IVS (Perimeter Protection) | Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. |
| Face Detection | Yes |
| SMD | Yes |
| Auto Tracking | Yes |
| Active Deterrence | |
| Light Warning | Red and blue warning lights Flash duration: 5s–30s Flash frequency: High, medium, low |
| Sound Warning | Sound warning alarm: Customizable |
| Video | |
| Compression | Smart H.265+; H.265; Smart H.264+; H.264B; H.264H; |
| Streaming Capability | 3 Streams |
| Resolution | 4M (2560×1440); 3M (2048×1536); 1080p (1920×1080); 1.3M (1280×960); 720p (1280×720); D1 (704×576); CIF (352×288) |
| Frame Rates | Main stream: 4M/3M/1080p/1.3M/720p (1–25/30 fps) Sub stream 1: D1/CIF (1–25/30 fps) Sub stream 2: 1080p/1.3M/720p (1–25/30 fps) |
| Bit Rate Control | CBR; VB extension |
| Bit rate | Default resolution of the main stream: H264: 2816kbps–8192kbps H265: 1024kbps–7936kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC extension | Yes |
| wdr extension | 120dB |
| HLC extension | Yes |
| White Balance | Car; manual; tracking; indoors; outdoors; outdoor car; sodium lamp; auto sodium lamp |
| Gain Control | Auto/Manual |
| Noise reduction | 2D NR; 3D NO |
| Motion Detection | Yes |
| Region of interest | Yes |
Electronic Image Stabilization (EIS) | Yes |
Electronic Defog | Electric |
digital zoom | 16x |
Flip | 180° |
Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view; supports multiple colors and mosaic blocks |
| Audio | |
| Compression | G.711a; G.711Mu; G.726; G722.1; G.729; MPEG2-Layer2; G723; pcm extension |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| protocol | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; smtp; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; SSL; QoS; FTP; UPnP; ICMP; SNMP; SNMP v1/v2c/v3 (MIB-2); IGMP; ARP; RTCP; RTP; PPPoE; IP filter; RTMP; Bonjour; TCP; SMB; NFS extension |
| Interoperability | ONVIF® (Profile S&G&T) |
| User/Host | 20 (total bandwidth: 64M) |
| Storage | FTP; Micro SD card (256GB); NOS |
| Browsers | IE 7 and later versions Chrome 42 and earlier versions Firefox 52 and earlier versions Safari |
| management software | Smart PSS; DSS; DMSS; Easy4ip; IVSS; player; configtool; NVRs; smart player |
| smart phones | iOS; android; iPhones; iPads; Windows Phone |
| Certifications | |
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 |
| Port | |
| Audio inputs | 1 (LINE IN; bare wire) |
| Audio Outputs | 1 channel (LINE OUT, bare wire; built-in speaker (mutually exclusive)) |
| Alarm Inputs | 2-ch, digital input (0–5 VDC) |
| Alarm Output | 1-ch |
| Alarm Linkage | Capture; presets; tours; patterns; recording; alarm digital input; send email |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detectionAccessories |
| Power | |
| Power Supply | 24 VDC, 2.5 A (± 25%) (included) PoE+ (802.3at) |
| power consumption | Basic: 13W Max.: 23W (illuminator + red and blue warning light + speaker + PTZ working) |
| environmental | |
| Operating Temperature | –40°C to +70°C (–40°F to +158°F) |
| Operating Humidity | ≤ 95% |
| Ingress Protection | IP66; TVS 6000V lightning proof; surge protection; voltage transient protection |
| structure | |
| Casing | ADC12 |
| Dimensions | 325.3mm × Φ202.0mm (12.81" × Φ7.95") (H × D) |
| Net Weight | 4.6kg (10.14lbs) |
| Gross Weight | 9.1kg (20.06lbs) |
Further details
 | All Onvif , the absolute standard for IP cameras, being Onvif guarantees compatibility with any modern recording system. NOT being Onvif means having a camera for its own sake that can never be used together with recording systems This camera is ONVIF® compatible |
  | The advantage of a PoE camera is evident, it allows it to be powered with the same cable with which it communicates without carrying additional power cables and without having to install a separate power supply system, a PoE camera guarantees constant voltages and simple installation PoE is the first generation technology, PoE+ is the latest standard . PoE+ (IEEE 802.3at) (High PoE) |
| AI | Artificial intelligence - Perimeter protection - Intrusion - Line crossing - Face recognition - Auto tracking |
 | Active deterrence: Alerts intruders with built-in white light and siren |
 | This camera has a resolution of 4Megapixel |
| Smart H.265+ Smart H.265+ is the optimized implementation of H.265 codec that uses scene-adaptive coding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ greatly reduces bit rate and storage requirements compared to standard H.265 compression
|
 | 1/2.8" STARVIS sensor with STARLIGHT technology. Low brightness, color vision even in night mode
With the addition of the STARVIS feature we have significant advantages: - Backlit structure with 2.9 µm-square unit pixel - High sensitivity (two or more times greater than other products on the market) - Increased sensitivity in the vicinity of an area covered by infrared light - Supports WDR (multiple exposure WDR, DOL-WDR) - Versatile interface (CMOS parallel, low voltage LVDS serial, MIPI CSI-2) With the Sony CMOS sensor it is possible to have color shots even in night mode. Normally, when entering night mode, the color vision becomes black/white.
|
 | 25x Optical Zoom ( 4,8 ~ 120 mm ) + 16x Digital Zoom |
 | Main stream: 4M/3M/1080p/1.3M/720p (1–25/30 fps) |
 | IR LED illuminator with range up to 150 meters! This camera is also equipped with SMART IR technology.
|
 | Generic PTZ Functions: Pan/Tilt Range: Pan: 0°–360° (endless) Tilt: -20°–90° (auto flip 180°) Manual Control Speed: Pan: 0.1°–160°/s Tilt: 0.1°–60°/s Preset Speed: Pan: 240°/s Tilt: 150°/s Presets: 300 Tours: 8 (up to 32 presets per tour) Pattern Numbers : 5 Scanning Number : 5 Speed Adjustment : Support Power-off Memory : Support Idle Motion : Preset/Tour/Pattern/Scanning Protocol : DH-SD Pelco-P/D (auto recognition) |
 | This camera has 2 inputs and 1 alarm output |
 | This camera features 1 Audio input + 1 Audio Output |
 | Day/Night: allows you to adapt the lens to night/day vision, and the relative automatic management of the IR Illuminator, when present.  |
 |
The IR CUT FILTER is a mechanical filter that allows correct viewing of images in daytime viewing conditions, filtering the typical infrared frequencies, thus improving image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies. |
 | ULTRA WDR up to 120dB WDR (Wide Dynamic Range): It is the professional solution in cases where it is necessary to operate in conditions of high light/shadow contrast. Fundamental in case of shooting from inside to outside, plates, shadowed points or all situations where there is no homogeneity of light.  |
 | This function allows you to clearly see images taken in particular climatic conditions: rain, smoke and fog   |
 | This camera features the EIS function. The EIS (image stabilizer) is especially useful when the camera is not positioned in a fixed place (ships, vehicles, etc.) or outdoors on poles where the weather conditions can make the image unstable  |
 | Possibility to insert Micro SD up to a maximum of 256GB (not included) |
 | Power supply NOT included in the package  |
 | Protection level from Heavy Rain and dust in IP parameters. |
 | This product is covered by a 24 month guarantee. |
