Dahua outdoor camera HAC-ME1809TH-A-PV-S2 4K with 1 Video Output CVI/TVI/AHD/CVBS, 3.6mm fixed lens and 4K CMOS sensor. Smart IR LED illuminator 40MT, 3D NR, BLC, HLC, WDR, HLC-Pro Smart Dual Light, 1x alarm output, Active deterrence (red-blue lights), Built-in microphone, IP67 protection, metal and plastic, Dahua Technology
discover the available quantity
LO HAI TROVATO A MENO?
Scrivici dove e ti sconteremo la differenza fino a fine mese!
DAHUA OUTDOOR CAMERA - 4K - 3.6MM - SMART IR 40MT - DAHUA
4 Technologies in 1: HDCVI / HDTVI / AHD / ANALOG
4K resolution - 3.6mm fixed lens and 4K Smart Dual Light CMOS sensor, 1 BNC 4in1 CVI/TVI/AHD/CVBS Video Output
Product details
- 4in1 bullet outdoor camera - Dahua
- 4 Technologies in 1: HDCVI / HDTVI / AHD / ANALOG
- Resolution: 4K
- Smart Dual Light
- Active deterrence
- Built-in microphone
- 4K CMOS image sensor
- 3.6mm fixed lens
- Functions: BLC, HLC, DWDR, 3D NDR
- Smart IR LED Illuminator 40MT
- 1 BNC 4in1 CVI/TVI/AHD/CVBS Video Output
- 1 alarm output
- 12V DC power supply not included
- Suitable for indoor and outdoor environments
- IP67 protection (dust / immersion)
- Material: metal and plastic
- Dimensions 240.7 mm × Φ90.7 mm (9.48" × Φ3.57")
- 24 months warranty
Data sheet
| model | HAC-ME1809TH-A-PV-S2 |
| Room | |
| Image Sensor | 4K CMOS |
| mex resolution | 3840(H)×2160(V) |
| Pixels | 4K |
| Electronic Shutter Speed | 1/3s–1/100000s |
| Scan system | Progressives |
| S/N Ratio | >65dB |
| Min Illumination | 0.001 lux@F1.0 (Color, 30 IRE) 0.0001 lux@F1.0 (B/W, 30 IRE) 0 Lux warm light on |
| IR Distance | 40m (131.2ft) |
| IlluminationType | Warm light |
| IR On/Off Control | Car; manual |
| IR LEDs | 2 (Warm light); 2 (IR light) |
| Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° |
| lens | |
| LensType | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 3.6mm |
| Max Openings | F1.0 |
| Angle of view | H: 85°; V: 45°; Q: 100° |
| Iris type | Fixed iris |
| Close Focus Distance | 3.6mm: 2.8m (9.19ft) |
| Video | |
| Video Frame Rate | CVI: 4k@15fps; 5M@25fps; 4M@25fps; AHD: 4K@15fps; TVI: 4K@15fps; CVBS: 960H |
| Resolution | 4K (3840×2160); 5M (2880×1620); 4M (2560×1440); 960H (960×576/960×480) |
| BLC Mode | BLC; HLC; WDR; HLC-Pro |
| wdr extension | 120dB |
| White Balance | Car; manual |
| Noise reduction | 3D NO |
| White balance | Car; Area |
| Gain Control | Auto / Manual |
| Smart IR | Yes |
| Mirrors | Off/On |
| Privacy Masking | Off/On (8 area, rectangle) |
| Certification | |
| Certifications | CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+ A11:2017) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL62368-1+CAN/CSA C22.2 No.62368-1-14) |
| Port | |
| Video putput | 1 BNC output Support CVI/TVI/AHD/CVBS |
| Audio inputs | built-in mic |
| alarm out | 1ch alarm out |
| Active Deterrence | |
| Red/Blue Light Warning | Flash: 5s–60s; frequency: high/medium/low |
| Sound Warning | sound 1/2/3; Volume: high/medium/low; duration: 5s–60s; 110dB |
| Power | |
| Power Supply | 12V±30% DC |
| power consumption | Max 10.45W (12V DC, IR on) |
| environment | |
| Operating Conditions | -40°C to +60°C (-40°F to +140°F); |
| Storage Temperatures | -40°C to +60°C (-40°F to +140°F); <95% (noncondensing) |
| Protection Grade | IP67 |
| structure | |
| Casing | Cover: Metal Rear: Plastic Pedestal: Metal |
| Dimensions | 240.7mm × Φ90.7mm (9.48" × Φ3.57") |
| Net Weight | 0.48kg (1.06lb) |
| Gross Weight | 0.74kg (1.63lb) |
Further details
 | New ULTRA HD 4K Technology! 4K CMOS image sensor |
 |
This camera is a FOUR HYBRID (4 Integrated Technologies) These cameras are at the same time Analog , Ahd , Hdcvi and Hdtvi .    |
 | 3.6mm fixed lens |
| OSD (ON SCREEN DISPLAY) allows you to define masked areas, image correction, ATR, Day/Night sensitivity, Shutter speed, White balance, light compensation and much more... The OSD Menu is multi-language Multi-Tech: The camera features 4 technologies in 1 (HDCVI, HDTVI, AHD, Analog) |
 | Infrared illuminator with approximate maximum range of 40Mt |
 | Digital WDR (Wide Dynamic Range D-WDR (Digital Wide Dynamic Range) is the Software solution of the more powerful WDR integrated in the DSP, exactly as it happens for the digital zoom compared to the Optical Zoom, it is a software simulation of the WDR technology emulation, however extremely useful in circumstances of strong contrast.  |
 | Active deterrence : This camera integrates Active Deterrence functions Promptly report intruders and act even before the break-in occurs
|
 | The IR CUT FILTER is a mechanical filter that allows correct viewing of images in daytime viewing conditions. It filters out typical infrared frequencies, thus improving image quality. In night conditions the filter is removed as it is necessary to capture the typical IR frequencies.  |
 |
BLC (Back Light Compensation) is one of the 3 possible Steps in the management of images with Contrast, typical situations are (Entry or exit from car parks, Plates, Special lights, Entrances with shooting from inside out, etc.) the compensation of light is one of the most complex possible operations, the BLC function allows a discreet adaptation to these situations |
 | Protection level IP67 ( Dust / Immersion ) |
 | This camera has a built-in microphone |
 | This Camera Has 1 Alarm Output |
 | 12VDC power supply not included  |
 | This product is covered by a 24 month guarantee. |
