Dahua HD 2MP 2.8mm Dome Video Surveillance Camera - Audio - IP67

2MP 2Megapixel resolution, 2.8mm fixed lens and 2MP CMOS sensor - Smart IR illuminator 1 LED 30M
Day/Night (ICR), BLC, HLC, DWDR, privacy mask, BNC Video Output, IP67
Product details

- Suitable for outdoor and indoor environments
Technical data sheet
| Model | HAC-HDW1200TLM-S6 | ||||||||
| Room | |||||||||
| Image Sensor | 2 MP CMOS | ||||||||
| Effective Pixels | 1920(H)×1080(V) | ||||||||
| Pixel | 2MP | ||||||||
| Scanning System | Progressive | ||||||||
| Electronic Shutter Speed | PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s |
||||||||
| S/N Ratio | >65dB | ||||||||
| Min. Illumination | 0.01 lux@F2.0 (Color, 30 IRE) 0.001 lux@F2.0 (B/W, 30 IRE) 0 lux (Illuminator on) |
||||||||
| Illumination Distance | 30 m (98.4 ft) | ||||||||
| Illuminator On/Off Control | Car | ||||||||
| Illuminator Number | 1 (IR light) | ||||||||
| Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° |
||||||||
| Lens | |||||||||
| Lens Type | Fixed-focal | ||||||||
| Mount Type | M12 | ||||||||
| Focal Length | 2.8 mm | ||||||||
| Max. Openings | F2.0 | ||||||||
| Field of View | H: 83°; V: 48°; D: 105° | ||||||||
| Iris Type | Fixed iris | ||||||||
| Close Focus Distance | 0.7 m (2.30 ft) | ||||||||
| DORI Distance |
|
||||||||
| Video | |||||||||
| Frame Rate | CVI: 1080P@25/30fps; 720P@25/30fps; 720P@50/60fps; AHD: 1080P@25/30fps; 720P@25/30fps; TVI: 1080P@25/30fps; 720P@25/30fps; 720P@50/60fps; CVBS: 960H |
||||||||
| Resolution | 1080P (1920×1080); 960H (960×576/960×480) | ||||||||
| Day/Night | Auto(ICR)/Color/B/W | ||||||||
| BLC | BLC/HLC/DWDR | ||||||||
| WDR | DWDR | ||||||||
| White Balance | Auto; White balance area | ||||||||
| Gain Control | Car | ||||||||
| Noise Reduction | 3D NR | ||||||||
| Illumination Mode | Smart IR | ||||||||
| Mirror | Yes | ||||||||
| Privacy Masking | Off/On (8 area, rectangle) | ||||||||
| Certifications | |||||||||
| Certifications | CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
||||||||
| Port | |||||||||
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port | ||||||||
| Power | |||||||||
| Power Supply | 12V ±30% DC | ||||||||
| Power consumption | Max 3.2 W (12 VDC, IR on) | ||||||||
| Environment | |||||||||
| Operating Conditions | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) | ||||||||
| Strorage Conditions | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) | ||||||||
| Ingress Protection | IP67 | ||||||||
| Structure | |||||||||
| Casing | Metal dome+metal cover+plastic decorative ring | ||||||||
| Dimensions | Φ94.0 mm × 85.7 mm (Φ3.70" × 3.37") | ||||||||
| Net Weight | 0.33 Kg (0.73 lb) | ||||||||
| Gross Weight | 0.44 kg (0.97 lb) | ||||||||
| Installation | Wall mount; ceiling mount; vertical pole mount | ||||||||
Further details
![]() |
4 TECHNOLOGIES IN 1: This camera features 4 technologies in 1 : HDTVI / HDCVI / AHD / CVBS interchangeable.
Switch Technologies: DIP- switchable technologies |
![]() |
This camera features a resolution of 2Megapixel 2 MP 1080P FULL-HD 1/2.7" CMOS sensor |
![]() |
This camera is equipped with a 2.8mm fixed lens |
![]() |
Infrared illuminator with 1 LED and approximate maximum range of 30m |
![]() |
This camera features 1 BNC Video Output |
![]() |
Allows you to adapt the lens to Night/Day vision
|
![]() |
The IR CUT FILTER is a mechanical filter that allows for correct image display in daytime conditions. It filters out typical infrared frequencies, thus improving image quality. At night, the filter is removed as it is necessary to capture typical IR frequencies. ![]() |
![]() |
BLC (Back Light Compensation) is one of the 3 possible steps in the management of images with Contrast, typical situations are (Entrances or exits from parking lots, License plates, Special lights, Entrances with shots from the inside towards the outside, etc.) the light compensation is one of the most complex operations possible, the BLC function allows a discrete adaptation to these situations |
![]() |
The AGC is an integrated signal amplifier that allows vision even in critical conditions. It is automatic and requires no specific settings. |
|
Digital Defog |
|
![]() |
Protection level IP67 (Dust / Immersion) |
![]() |
12VDC power supply not included ![]() |
|
This product is covered by a 24 month warranty. |
