Ajax Superior Hub Hybrid 2 Black: Professional Hybrid Control Panel with Ethernet and Dual SIM

Ajax Superior Hub Hybrid 2 Black: Professional Hybrid Control Panel with Ethernet and Dual SIM

New

142514.369.BL1 # 142514 | Ajax Superior Hub Hybrid 2 , black version is an advanced hybrid control panel designed for medium to large security systems, capable of managing up to 250 wired and wireless devices with reliable communication via Ethernet and dual SIM 2G/3G/LTE. Thanks to the proprietary Fibre and Jeweller protocols, it guarantees fast, encrypted and tamper-resistant transmission, with support for automation and photo-verification scenarios. The hybrid design allows maximum installation flexibility, while redundant connectivity ensures operational continuity in any conditions. The control panel integrates anti-tamper systems, complete remote management and compatibility with up to 64 automatic scenarios for professional and scalable protection.

Technical Data Sheet


>> FREE AJAX STICKER SIGN


Reference: 142514.369.BL1

Brand: Ajax Systems

EAN: 4823114079511

Manufacturer Object ( [id] => 31 [name] => Ajax Systems [description] =>

Born in 2011, Ajax System produces alarm and fire systems with JEWELLER radio protocol, a wireless technolog that allows to connect with a few taps the detectors in the mobile app. The Ajax System security system is easy to install in your apartment, home or office. By choosing Ajax System, you get integrated protection that is easy to manage, tamper-resistant and responds instantly to attacks. Ajax  System devices are easy to be installed: just 15 seconds to connect the control panel to the detectors. They can also support third-party surveillance cameras, making Ajax System a singular security center.

[short_description] =>

Ajax SystemsAjax Systems

The alarm systems by Ajax System use a state-of-the-art wireless technology, thus making the devices very reliable and always connected. Ajax System detectors combine the best components with conceptual design.

[id_address] => [date_add] => 2019-01-15 15:51:16 [date_upd] => 2025-06-11 12:47:32 [link_rewrite] => ajax-systems [meta_title] => State-of-the-art alarm and fire systems - Ajax System [meta_keywords] => ajax system,ajax systems,system ajax ,ajax security system,ajax notification system [meta_description] => Alarm systems by Ajax System are innovative, reliable and user-friendly wireless devices. Find them all on Setik.biz [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

142514.369.BL1 | HYBRID CONTROL UNIT FOR MEDIUM-LARGE CONFIGURATIONS


Ajax

The Ajax Superior Hub Hybrid 2 Black, 142514.369.BL1, is an advanced hybrid control panel designed for medium to large security systems, capable of managing up to 250 devices between Fiber and Jeweller. Thanks to dual Ethernet and 2G/3G/LTE SIM connectivity, it guarantees always-on communications with automatic switching between networks and protocols protected by encryption. The system supports photo verification, intelligent automations and anti-sabotage functions such as tamper, short circuit detection and Fiber line monitoring. The black casing offers a professional design, while Jeweller, Wings and Fiber technologies ensure fast, secure and stable communications in any installation conditions. Ideal for installations requiring maximum reliability, scalability and complete remote management via app.

Main specifications:

- Supports up to 250 wired and wireless devices in any combination

- Dual communication via Ethernet and two 2G/3G/LTE SIMs

- Anti-sabotage functions: tamper, short circuit, fiber optic line break detection

- Photo verification support with up to 8 triggers per device

- Up to 64 automation scenarios for security and advanced home automation

- Quick setup with QR code and automatic scanning of up to 100 devices

- Battery life up to 60 hours with dedicated battery (optional)

- Elegant black design, IP40/IK06 certifications and ready for professional mounting

Further details

Wired Protocol:
The system uses the proprietary Fibra protocol, which ensures fast, encrypted communication between hubs and devices with a range of up to 2,000 m without additional power supplies. It supports Beam (radial), Ring, and Tree topologies, offering maximum installation flexibility and resilience even in the event of line failures.
Hybrid system :
The control panel manages up to 250 devices by combining wired and wireless technologies, allowing you to create a complete and scalable security system that integrates intrusion detection, fire detection, and automations in a single platform.
Wireless protocols :

The system supports three advanced protocols:

  • Jeweller , for transmission of alarms, commands and events up to 2,000–3,000 m

  • Wings (TurboWings) , for fast sending of photos, logs and data packets

  • VoRF , which provides full-duplex audio communications and a range of up to 1,800 m in open terrain

Photo verification support:
It allows up to 8 triggers per device , activated by scenarios, alarms, schedules or specific events (masking, tamper, magnetometer), ensuring immediate visual analysis for a precise response to incidents.
Automation scenarios:
It supports up to 64 intelligent scenarios , triggered by alarms, schedules, environmental changes (temperature/humidity), Ajax buttons or CO₂ concentration, transforming the system into an advanced home automation environment.
Sabotage Resistance:
Equipped with a built-in tamper, short circuit detection, immediate recognition of fiber line breaks, and device authentication to prevent spoofing. The ring topology ensures operational continuity even in the event of physical outages.

Technical data sheet

142514.369.BL1
Compliance EN 50131 (Grade 3)
PD 6662:2017
Fiber communication technology
Wired connection U/UTP cat. 5 4x2x0.51 mm (24 AWG) cable, copper conductor
4x0.22mm signal cable copper conductor
Communication range Up to 2,000m
Up to 6,550 ft
With U/UTP cat. 5 4x2x0.51 mm (24 AWG) cable
Polling interval 12-300 s
Adjusted by a PRO or user with admin rights in Ajax app
Superior Jeweler communication technology
Communication range Up to 3,500 m
Up to 11,500 ft
Frequency bands 865.0 - 868.0 MHz
868.0 - 868.6 MHz
868.7-869.2 MHz
869.4 - 869.65 MHz
Each device supports these four bands
Wings, and VoRF communication technology
Wings communication range Up to 3,000 m
Up to 9,800 ft
In open space
VoRF communication range Up to 1,800m
Up to 5,900 ft
In open space
Frequency bands 866.0 - 866.5 MHz
868.0 - 868.6 MHz
868.7 - 869.2 MHz
905.0 - 926.5 MHz
915.85 - 926.5 MHz
921.0 - 922.0 MHz
Depence on the sales reaction
Maximum effective radiated power (ERP) < 25 mW
Power Supply
Main power supply type Type A
Operating AC voltage 100 - 240 V, 50/60 Hz
Up to 10W of mains power consumption
Fiber Line 24 V
The hub power connected devices
Operating DC voltage 10.5 - 15 V
From the backup battery with a capacity of 4, 7, or 9Ah (not included in the complete set)
Autonomous operation up to 60 hours
The 7 Ah backup battery can power a system of 30 wired devices for 60 hours, while wireless devices already operate on batteries
Communication channels
Ethernet 8P8C socket
up to 100 Mbps
Cellular networks 2 slots for micro-SIM
2G (GSM900 / DCS1800 (B3 / B8))
3G (WCDMA 850 / 900 / 2100 (B1 / / B5 B8))
4G/LTE (FDD B1 / B3 / B5 / B7 / B8 / B20)
Automatic switching between communication channels Up to min between SIM cards
Instantly between 4G, 3G and 2G networks within a SIM
Instantly between Ethernet and SIM
Power Supply
Ajax devices Up to 250
Wired and wireless devices in any combination
5 range extenders max
Fiber Lines 8 outputs
Ajax wired devices can be connected with 8 lines (1 line uses 1 output) or 4 rings (1 ring uses 2 output)
Ajax cameras or NVRs up to 36 NVRs
up to 224 cameras via Ajax NVRs
up to 492 standalone cameras
Users up to 200
Automatic scenarios up to 64
Security groups up to 25
Rooms up to 200
Control and user authorization System supports up to 200 access codes
Event log up to 1000 events
Alarm and events are saved on the volatile on-devices flash memory
Installation
Operating temperature - 10 °C to +40 °C
14°F to 104°F
Operating humidity up to 75%
Product appearance
Color Black
Dimensions 197 x 140 x 100 mm
7.28" x 3.90" x 1.69"
Weight 765 g
26.52 oz
Casing protection class IP40, IK06
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
