1U Cable Management Panel for 19" Rack Cabinets | RAOK-1P Plastic with 4-Point Fixing

1U Cable Management Panel for 19" Rack Cabinets | RAOK-1P Plastic with 4-Point Fixing

-58% New

The RAOK-1P 1U plastic horizontal cable management panel, ideal for 19" rack cabinets, allows for the neat and safe organization of horizontal cabling, preventing accidental damage. Made of SPCC cold-rolled steel with black plastic rings, it comes complete with M6 screws and cage nuts for four-point fastening. Perfect for indoor applications, it guarantees quality and durability with a 1-year warranty. Robust, functional design and RAL 9004 compliant for professional integration into IT and video surveillance systems.

Technical Data Sheet

Reference: RAOK-1P

Brand: Pulsar

Disponibilità: 1

Manufacturer Object ( [id] => 37 [name] => Pulsar [description] =>

The company is a leader in Poland in this sector but is present in many countries in Asia and Europe, so much so that it is growing both in terms of number of sales and the number of new markets in which it is making its way. The quality of the products and the service provided to customers are the strong points that have made the Pulsar brand so successful. The company is attentive to the production process and to the development of new research methods in order to guarantee a service that always meets the needs of customers. Pulsar is constantly expanding the range of products offered, ranging from accessories for alarm systems to those for video surveillance systems. Among the proposals of Pulsar are: accessories for metal containers and for RACK power supplies and cabinets and accessories for cabinets.

[short_description] =>

Accessori impianti allarme Pulsar

Since 1994, Pulsar has been distinguished by the production of access controls and accessories and components for alarm systems and video surveillance systems.

[id_address] => [date_add] => 2019-06-07 15:19:24 [date_upd] => 2020-06-18 15:49:37 [link_rewrite] => pulsar [meta_title] => Alarm components Pulsar [meta_keywords] => Alarm components Pulsar, box pulsar [meta_description] => Pulsar is a manufacturer of components for alarm and active access control systems from 1994. Discover now the wide range of Pulsar accessories available online! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


CLEARANCE SALE ×


 CLEARANCE SALE!
Take advantage of our must-see outing offers.
  Discover the promo >>

RAOK-1P | 1U Horizontal Plastic Cable Management Panel

Pulsar

The Pulsar RAOK-1P 1U horizontal cable management panel is designed to organize and protect cabling inside 19" rack cabinets, preventing accidental damage to cables. Made of cold-rolled steel with plastic rings, it allows for tidy and safe cable management for professional indoor installations.

Main specifications:

- Compatible with 19" RACK cabinets – 1U

- Dimensions: 482×44×68 mm (±2 mm)

- Material: 1.2mm SPCC steel + black plastic rings

- 4-point fixing with M6 screws and cages included

- Net weight 0.30 kg – for indoor use

- Warranty: 1 year from date of manufacture

Further details

High quality material:
The RAOK-1P panel is made of 1.2 mm SPCC cold-rolled steel, compliant with RAL 9004 standard, ensuring strength and durability. The cable grommets are made of durable black plastic, designed to offer flexibility in cable management without compromising the solidity of the structure .
Stable and safe 4-point attachment :
Thanks to the four-point fastening system on the front uprights of the RACK cabinets, the panel ensures a secure hold even with complex wiring. It comes complete with four M6 screws and cage nuts, facilitating professional installation without the need for additional accessories.
Compatibility with standard 19” cabinets :
Designed for horizontal mounting in 19" rack cabinets, the 1U panel (H=44 mm, W=482 mm, D=68 mm) is perfectly compatible with the most common network and video surveillance configurations. Ideal for indoor applications, it offers a tidy and secure solution for cable management.

Technical data sheet

MODEL RAOK-1P
Mounting dimensions W=19", H=1U
Dimensions W=482, H=44, D=68 D1=8 [mm, +/-2]
Net/gross weight 0.30 / 0.34 [kg]
Materials 1.2 mm cold-rolled steel (SPCC), RAL 90045
plastic rings, color: black
Use inside
Warranty 1 year from production date
Notes four-point fixing to the front RACK rails
4 M6 screws + cage nuts included
All our products are in conformity with the in force CE normative (read here). To ask for a copy of the certification fill out this form
