RW1566 - The 15U RACK 19" cabinet is a professional, fully assembled wall-mounted solution designed to integrate CCTV, LAN, alarm systems, RTV and automation devices in indoor environments. The SPCC cold-rolled steel structure guarantees solidity and supports a static load of up to 70 kg , while the 5 mm tempered glass front door with lock protects the installed equipment. With external dimensions of 600 × 768 × 600 mm , it has adjustable RACK guides , dedicated ventilation openings and upper and lower channels for tidy cable management. The IP20 protection rating, the possibility of reversing the door opening direction and RoHS compliance make it suitable for professional network and security installations. Pulsar

Technical data sheet

Reference: RW1566

Brand: Pulsar

Manufacturer Object ( [id] => 37 [name] => Pulsar [description] =>

The company is a leader in Poland in this sector but is present in many countries in Asia and Europe, so much so that it is growing both in terms of number of sales and the number of new markets in which it is making its way. The quality of the products and the service provided to customers are the strong points that have made the Pulsar brand so successful. The company is attentive to the production process and to the development of new research methods in order to guarantee a service that always meets the needs of customers. Pulsar is constantly expanding the range of products offered, ranging from accessories for alarm systems to those for video surveillance systems. Among the proposals of Pulsar are: accessories for metal containers and for RACK power supplies and cabinets and accessories for cabinets.

[short_description] =>

Accessori impianti allarme Pulsar

Since 1994, Pulsar has been distinguished by the production of access controls and accessories and components for alarm systems and video surveillance systems.

[id_address] => [date_add] => 2019-06-07 15:19:24 [date_upd] => 2020-06-18 15:49:37 [link_rewrite] => pulsar [meta_title] => Alarm components Pulsar [meta_keywords] => Alarm components Pulsar, box pulsar [meta_description] => Pulsar is a manufacturer of components for alarm and active access control systems from 1994. Discover now the wide range of Pulsar accessories available online! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER


RW1566 | 15U 19" WALL-MOUNTED RACK CABINET

Dahua

The Pulsar RW1566 19" 15U RACK cabinet is a fully assembled wall-mounted solution, ideal for integrating CCTV, LAN, RTV, alarm and automation systems in indoor environments. Made of SPCC cold-rolled steel , it offers a robust structure with a static load of up to 70 kg and external dimensions of 600 × 768 × 600 mm . The 5 mm tempered glass front door with lock protects the equipment, while the adjustable RACK rails simplify installation. The equipment is completed by the upper ventilation holes , upper and lower cable channels, IP20 protection rating and RoHS compliance.

Main specifications:

  • Format: 19", 15U
  • Dimensions: 600 × 768 × 600 mm
  • Static load: up to 70 kg
  • Structure: SPCC steel
  • Door: 5mm tempered glass
  • Protection: IP20
  • Installation: Wall mounted
  • Certification: RoHS

Further details

✅ Static load :
The Pulsar RW1566 RACK cabinet supports a maximum static load of 70 kg , offering adequate capacity for the installation of CCTV, LAN, RTV, alarm systems and standard 19" professional devices .
✅ Structure:
The frame is made of SPCC cold-rolled steel , with 1.5mm rails and mounting plate and 1.2mm body and side panels; the 5mm tempered glass front door with lock ensures protection and easy access.
✅ Ventilation:
The top panel integrates 2 105 × 105 mm ventilation cutouts , designed to allow the installation of ventilation systems and promote correct thermal management of the equipment present in the 15U RACK .
✅ Mobility :
The RW1566 model is designed primarily for wall mounting and the PDF does not indicate wheels or specific handling systems; however, it does offer adjustable front and rear RACK rails and a reversible door that opens to the right or left , increasing the flexibility of installation and use.

Technical data sheet

MODEL RW1566
Mounting dimensions 19" x 15U x 447 mm
Dimensions 600 x 769 x 600 [+/-2 mm]
Supported weight 70kg
Lock front door – lock (RAZ25, same code)
side panel – Click (possibility of mounting the key lock – RAZB16)
Feasibility SPCC cold formed steel, 1.2mm, 1.5mm, RAL9004 (black), metallic
Protection grade EN60529 IP 20
Warranty 2nd year
Attention - possibility to move the door from left to right
