DS-PDD12P-EG2-WE 24GHz 12m Tri-X Wireless PIR and Microwave Detector with Pet Immunity 30kg - Hikvision

DS-PDD12P-EG2-WE 24GHz 12m Tri-X Wireless PIR and Microwave Detector with Pet Immunity 30kg - Hikvision

 
-35%

DS-PDT12P-EG2-WE - is a dual-technology wireless indoor detector that combines a PIR sensor and 24 GHz microwave for precise and reliable motion detection. It offers a range of up to 12 meters at a 90° angle , 84 detection zones and immunity to animals up to 30 kg at low sensitivity. It integrates front and rear tamper protection , digital temperature compensation and creep zone protection. The two-way Tri-X Wireless communication at 868 MHz uses AES-128 encryption and frequency hopping, with a range of up to 1.6 km in open field . Powered by 2 CR123A batteries , it guarantees a battery life of up to 5 years and can be configured remotely via APP. Hikvision

Technical Data Sheet

Reference: DS-PDT12P-EG2-WE

Brand: Hikvision

Manufacturer Object ( [id] => 42 [name] => Hikvision [description] =>

Since the year of its birth, its prestige has grown so much that in 2015 it will become the first global reality in security.

From 2016 Hikvision expands its market becoming Total Solution Provider for the entire security market. Thus it enters the world of intrusion detection and then approaches new technologies and intelligence at the service of mankind by dealing with IoT, Machine Vision, Robotics and Automotive systems. From security leader, Hikvision becomes with commitment, passion and competence a Hi-Tech company with a vision 4.0, always aiming high.

Setik is therefore honored to be a Hikvision distributor. We will, as always, offer the latest generation products and the appropriate technical and commercial support.

[short_description] =>

Videosorveglianza Hikvision

Hikvision was founded in 2001 with the aim of creating and developing complete professional video surveillance solutions, quickly becoming a leader in the security world.

[id_address] => [date_add] => 2020-03-26 09:28:09 [date_upd] => 2024-06-06 12:13:26 [link_rewrite] => hikvision [meta_title] => Security Hikvision [meta_keywords] => Hikvision, Security Hikvision [meta_description] => Hikvision was founded in 2001 and soon became a leader in the world of video surveillance. Discover now the products in the catalogue! [active] => 1 [webserviceParameters:protected] => Array ( [fields] => Array ( [active] => Array ( ) [link_rewrite] => Array ( [getter] => getLink [setter] => ) ) [associations] => Array ( [addresses] => Array ( [resource] => address [setter] => [fields] => Array ( [id] => Array ( [xlink_resource] => addresses ) ) ) ) ) [id_lang:protected] => 1 [id_shop:protected] => 1 [id_shop_list] => Array ( ) [get_shop_from_context:protected] => 1 [table:protected] => manufacturer [identifier:protected] => id_manufacturer [fieldsRequired:protected] => Array ( [0] => name ) [fieldsSize:protected] => Array ( [name] => 64 ) [fieldsValidate:protected] => Array ( [name] => isCatalogName ) [fieldsRequiredLang:protected] => Array ( ) [fieldsSizeLang:protected] => Array ( [meta_title] => 255 [meta_description] => 512 ) [fieldsValidateLang:protected] => Array ( [description] => isCleanHtml [short_description] => isCleanHtml [meta_title] => isGenericName [meta_description] => isGenericName [meta_keywords] => isGenericName ) [tables:protected] => Array ( ) [image_dir:protected] => /var/www/html/img/m/ [image_format:protected] => jpg [translator:protected] => [def:protected] => Array ( [table] => manufacturer [primary] => id_manufacturer [multilang] => 1 [fields] => Array ( [name] => Array ( [type] => 3 [validate] => isCatalogName [required] => 1 [size] => 64 ) [active] => Array ( [type] => 2 ) [date_add] => Array ( [type] => 5 ) [date_upd] => Array ( [type] => 5 ) [description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [short_description] => Array ( [type] => 6 [lang] => 1 [validate] => isCleanHtml ) [meta_title] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 255 ) [meta_description] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName [size] => 512 ) [meta_keywords] => Array ( [type] => 3 [lang] => 1 [validate] => isGenericName ) ) [classname] => Manufacturer [associations] => Array ( [l] => Array ( [type] => 2 [field] => id_manufacturer [foreign_field] => id_manufacturer ) ) ) [update_fields:protected] => [force_id] => ) 1
FIND INSTALLER

DS-PDT12P-EG2-WE | WIRED DUAL-TECH DETECTOR

Hikvision

The Hikvision DS-PDD12P-EG2-WE is a dual-technology wireless detector designed for indoor protection, with combined PIR and 24 GHz microwave detection. It guarantees coverage of up to 12 meters with a 90° angle , 84 detection zones and immunity to animals up to 30 kg with low sensitivity. The two-way 868 MHz Tri-X Wireless technology ensures reliable communications up to 1.6 km in open field , protected by AES-128 encryption and anti-jamming frequency hopping. It integrates digital temperature compensation , creep-zone protection and front/rear tamper. Powered by 2 CR123A batteries offers a battery life of up to 5 years , with remote configuration via APP.

Main specifications:

  • Detection: PIR + 24 GHz microwave
  • Coverage: up to 12 m / 90°
  • Pet Immunity: up to 30 kg
  • Wireless: Tri-X 868 MHz bi-directional
  • Security: AES-128 + anti-jamming
  • Battery life: up to 5 years

Further details

✅ Detection Performance:
The detector combines a PIR (passive infrared) sensor and a 24 GHz microwave for dual-technology detection, offering coverage of up to 12 meters , a 90° detection angle and 84 zones . It supports three sensitivity levels ( High, Normal and Low ), detects movements from 0.3 to 2 m/s and integrates Pet Immunity up to 30 kg with low sensitivity, a 6500 lux white light filter, digital temperature compensation and creep-zone protection.
✅ Features :
The device integrates digital signal processing and sealed optics , designed to improve detection stability and reliability. Security is enhanced by front and rear tamper protection , while dedicated indicators allow you to check the ambient temperature and wireless signal strength .
✅ Interface:
The interface features a power switch with Power Up Enrollment function to facilitate the detector's association with the system. Multi-color LED indicators allow you to quickly identify the operating status: green for PIR , red for microwave , and blue for alarm .
✅ Transmission :
Communication uses 868 MHz RF two-way Tri-X Wireless technology, with a range of up to 1.6 km in open field . Transmission is protected by AES-128 encryption and anti-jamming Frequency Hopping technology, while pairing can be done via power on, Remote ID or QR Code .
✅ Power supply:
The detector is powered by 2 easily replaceable 3V CR123A batteries and guarantees up to 5 years of standby time , reducing the frequency of maintenance interventions and making it suitable for long-lasting wireless installations.

Technical data sheet

DS-PDT12P-EG2-WE
Detection Performance
Detection Method Passive Infrared; Microwave
Detection Range 12 m
Detection Angle 90°
Detection Zones 84
Detectable Speed 0.3～2m/s
Sensitivity High; Normal; Low
Pet Immunity 30Kg (only low sensitivity)
White Light Filter 6500lux
Microwave Frequency 24GHz(24.15～24.25GHz)
Digital Temperature Compensation Support
Creep Zone Protection Support
Features
Digital Processing Support
Sealed Optics Support
Tamper Protection Front
Environment Temperature Indicator Support
Signal Strength Indicator Support
Interfaces
Alarm Output Normally Closed
LED Indicator Green(PIR), Orange(Microwave), Blue(Alarm)
Transmission
Transmission Technology Tri-X Wireless
Transmission Method Two-Way RF Wireless
Transmission Frequency 868MHz
Transmission Security AES-128 Encryption
Transmission Range(Free Space) 1.6 km
Frequency Hopping Support
Enrolling Method Power up; Remote ID; QR Code
Electrical Characteristics
Standard Battery Life Up to 5 years (standby time)
Power Supply Battery Powered
Battery Type CR123A × 2
Typical Voltage 3V
General
Operation Temperature -10 °C to 55 °C (14 °F to 131 °F)
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Operation Humidity 10% to 90%
Dimensions (WxHxD) 65.5 mm × 103 mm × 48.5 mm
Weight 141 g
Mounting Height 1.8 m to 2.4 m
Mounting Method Wall
Application Scenario Indoor
Bracket Optional wall & ceiling accessory
