DAHUA 4IN1 MULTIFUNCTION TESTER - AUDIO TEST - 4.3 INCH TFT SCREEN - 8 KEYS

4in1 multi-function tester (HDCVI/AHD/TVI/CVBS ), with 4.3 inch TFT screen, 8 keys. 3 LED indicators.
Product details

- 4in1 Multifunction Tester (HDCVI/AHD/TVI/CVBS )
 - 4.3 inch TFT screen
 - 8 keys
 - 3 LED indicators
 - OSD menu and PTZ control
 - It supports ONVIF® and audio test
 - 1 audio input
 - 1 usb 1 micro-B
 - SR 485
 - 12V/1A DC power supply for the camera
 - Charging via USB
 - Compact and portable , designed with a detachable wrist strap

Data sheet
| model | PFM904 |
| System | |
| Operation System | Linux |
| Language | Multi-language interface |
| Operation Mode | Keyboard |
| Auto Standby/Shutdown | Yes |
| Keyboard Sound | Enable/disable |
| screen | 4.3" TFT screen, 480×272resolution |
| Keyboard |
 Control keyboard: 8 keys Others: power button  |
| LED Indicator Light | 3* 35lm lights |
| Update | Local update |
| Analog Video Test | |
| format | HDCVI; HDTVI; AHD; CVBS (NTSC; PAL) |
| Resolution |
 HDCVI: 2MP@25fps/30fps; 4MP@25fps/30fps; 5MP@20fps; 6MP@20fps; 4K@12.5fps/15fps HDTVI: 2MP@25fps/30fps; 4MP@25fps/30fps; 5MP@20fps AHD: 2MP@25fps/30fps; 4MP@25fps/30fps CVBS: NTSC; PAL  |
| Function Control | OSD display menus; PTZ |
| Video displays | live view |
| RS–485 Control | |
| Communication Protocol | More than 30 protocols such as Pelco-D/P, Samsung, Panasonic, Lilin, and Yaan |
| Baud rate | 150 bps; 300 bps; 600 bps; 1200 bps; 2400 bps; 4800 bps; 9600 bps; 19200 bps |
| Protection | |
| ESD |
 Air discharge: ±8KV Contact discharge: ±6KV  |
| Others | |
| Audio Test | 1 channel audio input test |
| Room Power Supply | 12V/1A DC power output to the camera |
| Certifications | |
| Certifications |
 EC: EN 55032 FCC: FCC Part 15 Subpart B  |
| Port | |
| Power | 1 power out, 12V/1A DC |
| Audio | 1 audio input |
| USB | 1 USB micro-B, charging/data |
| RS–485 | 1 |
| Power | |
| Charging | Micro USB 5V/1A |
| Battery | 2* 18650 lithium iron batteries, up to 14.8Wh, working about 8 hours |
| environment | |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
| Operating Humidity | 30%–95% (RH) |
| structure | |
| Appearance Color | Yellow |
| Dimensions | 125.0mm × 100.0mm × 65.0mm (4.92" × 3.94"× 2.56") (L × W × H) |
| Net Weight | 0.34kg (0.75lb) |
| Gross Weight | 0.74kg (1.63lb) |
